Bently Nevada 140734-05 | 3500/64M Pressure Monitor Card | MRO Urgent Spares

Bently Nevada 140734-05 | 3500/64M Pressure Monitor Card | MRO Urgent Spares

Original price was: $1,450.00.Current price is: $1,200.00.

  • Description: 3500/64M 4-Channel Dynamic Pressure Monitor Module
  • Brand/Manufacturer: Bently Nevada (Baker Hughes Asset Performance)
  • Chassis Platform: 3500 Machinery Protection System
  • Part Number (P-Number): 140734-05
  • Signal Input Matrix: 4 Independent Dynamic Pressure Transducer Inputs (High-Temp Charge/IEPE)
  • Core Measured Variable: Bandpass Dynamic Pressure Peak-to-Peak / Direct Waveform
  • Signal Conditioning: 10-Pole High-Slope Digital Filtering Array
  • Warranty: 12 Months Factory-Level Performance Protection
  • Condition: 100% Brand New & Original Factory Sealed
  • Country of Origin: USA
  • Net Weight: 0.82 kg (1.80 lbs)
Get a Quote
Categories: , SKU: 140734-05 Brand:
  • Need Help?
  • +86 13313703791
  • +86 13313703791
  • seren@ymgkplc.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

1. Product Overview

The Bently Nevada 140734-05 is a high-performance 4-Channel Dynamic Pressure Monitor Module engineered to serve as the primary defensive shield against unstable combustion anomalies within advanced industrial turbomachinery. Sliding into a single slot on the front plane of the standard 3500 Machinery Protection System, this processing module continuously accepts raw, high-frequency voltage waveforms generated by specialized high-temperature pressure transducers mounted inside gas turbine combustor wrappers.

By tracking one key measured variable per channel—bandpass dynamic pressure—the 140734-05 isolates the destructive acoustics of lean-premix combustion systems. Utilizing the 3500 Rack Configuration Software, users can program advanced digital filtering strategies. It features a Low Mode 10-pole filter (200 dB/decade attenuation) and a High Mode 6-pole filter paired with dual 50/60 Hz line-rejection notch filters. This allows engineers to trap narrow-band pressure pulsations while discarding unrelated industrial background noise before driving crucial machine trip alerts.

Key Applications:

  • Industrial Gas Turbine Combustors: Mitigating high-tonnage acoustic resonance and “humming” in heavy-duty low-NO_x power generation turbines.
  • Aeroderivative Jet Engine Retrofits: Monitoring dynamic pressure surges across compact, fast-ramping power-peaking enclosures.
  • Centrifugal Compressor Surging Loops: Identifying boundary-layer fluid separation and blade pass frequencies within heavy hydrocarbon processing lines.
  • Hydroelectric Penstock Tracking: Recording destructive low-frequency hydraulic ram phenomena and water-hammer pressure pulses.



2. Technical Features

Feature Technical Specification
Product Model 140734-05 (3500/64M High-Integrity Combustion Dynamic Protection Core)
Mechanical Footprint Full-height front-panel card secured via standard industrial thumb captive screws
Input Density 4 concurrent, fully separated sensor tracking channels processing data loops simultaneously
Power Consumption Energy-efficient design pulling a typical 7.7 Watts to reduce internal chassis thermal loads
Transducer Supply Volt Supplies stable -24 Vdc power profiles directly to external field charge amplifiers
Signal Isolation Index High galvanic separation preventing cross-channel electrical crosstalk or stray ground loop noise
Diagnostic Tracing Path Instant fault mapping to front panel LEDs to pinpoint sensor open-circuits or “Not OK” states
Structural Ruggedization Built with protective conformally coated PCB elements to resist coastal humidity profiles



3. Commercial Procurement Protocol

  1. Transducer Interfacing Check: Our technical team cross-checks your current field charge-amplifiers and pressure sensor scale factors to confirm total software map compatibility with the 140734-05.
  2. Commercial Quotation Issuance: You receive an itemized proposal outlining quantity-based price scaling, immediate warehouse allocation status, and priority global shipping lead-times.
  3. Trade & Sanction Screening: Immediate tracking of essential dual-use export classification numbers (ECCN) and verification of international end-user certification clearance.
  4. Proforma Invoice Transmission: Official corporate Proforma Invoices (PI) are delivered within hours to satisfy internal procurement audits and accelerate capital approval.
  5. Secure Financial Settlement: standard billing pathways handled securely via corporate-verified global Telegraphic Transfer (T/T wire channels).
  6. Pre-Dispatch Functional Audit: Every module undergoes rigorous physical checks verifying backplane contact gold-pads are flawless and recording unique firmware revision numbers.
  7. Premium Industrial Sealing: Vacuum-packed in multi-layer anti-static (ESD) foil barriers and surrounded by custom-fit high-density foam within rigid outer cardboard boxing.
  8. Express Courier Dispatch: Sourced items are immediately handed over to premium air freight couriers (DHL Express, FedEx, UPS) with live tracking coordinates.



4. Visual Product Showroom

5. Related Fleet Spares Systems



6. Warranty Protection & Continuous Supply Assurances

  • Extended 12-Month Supplier Warranty: Comprehensive 1-year swap-out or repair warranty shielding your operation against component or processing defects under normal use.
  • Authenticity Guarantee: We supply only authentic, original factory-branded parts to protect the structural specifications of your plant panels.
  • Consistent Logistics Tracking: Provision of automated shipping notification routes and complete customs declaration sheets for reliable delivery.



7. FAQ

Q: What is the primary operational difference between Low Mode and High Mode on the 140734-05?

Low Mode is optimized for low-frequency combustion pulsations (5 Hz to 4 kHz) and employs an ultra-steep 10-pole filter to prevent overlapping frequencies from causing false alarms. High Mode stretches the tracking envelope up to 14.75 kHz, which is essential for capturing blade pass frequencies and acoustic variations inside aero-derivative turbines.

Q: Can the front panel buffered outputs be used for external standalone data loggers?

Yes. The front face of the 140734-05 features four independent, short-circuit protected coaxial buffered outputs. This allows technicians to plug a portable dynamic signal analyzer directly into the active monitor rack to capture raw pressure waveforms without interrupting the primary safety protection loops.

Q: What is the function of Cascade Mode (1 > ALL) on this module?

When Cascade Mode (1 > ALL) is enabled via the configuration software, a single dynamic pressure transducer input wired into Channel 1 is automatically distributed across all four internal processing channels. This allows you to apply four completely different bandpass filter settings to a single physical sensor location.
