1. Product Overview
The Beckhoff CX1100-0001 is a specialized Power Supply and I/O Interface module designed to serve as the foundation for CX-series Embedded PCs (specifically CX1010, CX1020, and CX1030). More than just a power source, this module acts as the vital link between the high-performance CPU and the standard Beckhoff Bus Terminals (K-Bus).
Equipped with a built-in 2×16 character display and four navigation keys, the CX1100-0001 allows for localized status monitoring and basic system diagnostics without the need for an external monitor. It ensures stable 24V DC power distribution to both the internal CPU electronics and the connected I/O slice modules, making it an indispensable component for DIN-rail mounted control systems.
Key Applications:
- Compact Control Systems: Powering CX-series PCs in space-constrained electrical cabinets.
- I/O Signal Management: Interfacing standard K-Bus terminals with the TwinCAT control logic.
- On-site Diagnostics: Using the integrated LCD to check IP addresses, system status, or error codes.
- Industrial Automation: Widely used in machine building, building automation, and assembly lines.
2. Technical Features
| Feature | Technical Specification |
| Input Voltage | 24 V DC (-15 % / +20 %) |
| I/O Interface | K-Bus (Standard Bus Terminals) |
| Max. Power Output | 2 A for K-Bus (to power I/O terminals) |
| Diagnostics Display | 2 x 16 characters, illuminated |
| Control Keys | 4-way navigation keys for display menu |
| Protection Class | IP20 |
| Operating Temp | 0°C to +55°C |
| Mounting | 35 mm DIN rail (Directly coupled to CPU) |
3. Procurement Process
- Technical Compatibility: We verify that the CX1100-0001 is the correct match for your CX-series CPU (CX1010/1020/1030).
- Formal Quotation: Receive a detailed quote including pricing, availability (New or New Surplus), and global shipping options.
- Order Confirmation: Finalizing quantities and shipping details.
- Sales Agreement: Issuance of a Proforma Invoice (PI) for secure payment processing.
- Secure Payment: Payment accepted via T/T (Bank Wire Transfer).
- Quality Inspection: 100% verification of the K-Bus connector pins, LCD functionality, and original Beckhoff factory seals.
- Shock-Proof Packaging: Professional industrial packaging to ensure the delicate LCD and electronics remain protected.
- Global Distribution: Expedited worldwide shipping via DHL, FedEx, or UPS.
4. Products Showcase (Photos & Video)
5. Related Models
- Beckhoff CX1100-0002 (Power supply with E-Bus interface for EtherCAT)
- Beckhoff CX1100-0003 (Power supply with E-Bus and K-Bus support)
- Beckhoff CX1020-0112 (CPU Basic Module)
- Beckhoff CX1900-0101 (Replacement battery for CX systems)
6. Warranty & After-Sales
- 12-Month Global Warranty: Full 1-year coverage against any electrical or functional failures.
- 100% Authenticity Guaranteed: We supply only genuine Beckhoff parts; no “compatible” or refurbished units without full disclosure.
- Expert Support: Guidance on TwinCAT 2/3 system configuration and K-Bus power budget calculations.
7. FAQ
Q: What is the difference between CX1100-0001 and CX1100-0002?
The CX1100-0001 is designed for the standard K-Bus (Bus Terminals), whereas the CX1100-0002 is designed for the high-speed E-Bus (EtherCAT Terminals). Make sure you check your I/O slice type before ordering!
Q: Can I use the display to set the IP address?
Yes, if your TwinCAT project is configured correctly, the display and keys on the CX1100-0001 can be used to navigate system menus and view/edit basic network settings like the IP address.
Q: Is the 24V power supply for the field devices included?
The module provides power to the internal electronics and the bus. Power for the field devices (contacts, sensors, etc.) must be fed separately into the power contacts of the Bus Terminals.
