Product Overview
The ABB UFC718AE01 is a high-performance main circuit interface module engineered for critical industrial automation and power transmission systems. Designed as a bridge between control systems and power electronics, this module ensures seamless data exchange and power management in applications requiring precision and reliability. As part of ABB’s UFC series, the UFC718AE01 supports real-time monitoring, high-speed signal processing, and robust connectivity, making it ideal for demanding environments such as motor drives, renewable energy systems, and heavy machinery control.
The ABB UFC718AE01 is a high-performance main circuit interface module engineered for critical industrial automation and power transmission systems. Designed as a bridge between control systems and power electronics, this module ensures seamless data exchange and power management in applications requiring precision and reliability. As part of ABB’s UFC series, the UFC718AE01 supports real-time monitoring, high-speed signal processing, and robust connectivity, making it ideal for demanding environments such as motor drives, renewable energy systems, and heavy machinery control.
Key functionalities include high-speed data communication via Ethernet and RS-485 interfaces, enabling rapid transmission of operational parameters between the main circuit and control systems. Its power connection capabilities handle large currents up to 1A, ensuring stable power supply continuity in high-load scenarios like conveyor belts or industrial pumps. The module also features signal conversion and conditioning, adapting analog and digital signals to meet system requirements while filtering noise and surges. With an IP65-rated enclosure and operating temperature range of -20°C to +70°C, the UFC718AE01 withstands extreme conditions, including dust, moisture, and vibrations, common in oil refineries, steel mills, and outdoor wind farms.
The UFC718AE01 integrates seamlessly with ABB’s AC800M controllers and third-party PLCs, supporting protocols like Modbus RTU and PROFIBUS DP/PA for flexible system integration. Its modular design allows easy expansion, reducing installation complexity and cabinet space by up to 30% compared to traditional solutions. By enabling predictive maintenance and real-time diagnostics, the module enhances operational efficiency and minimizes downtime in smart manufacturing and energy management applications.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | UFC718AE01 |
| Manufacturer | ABB |
| Product Type | Main circuit interface module |
| Input Voltage | 85–132 V AC (47–63 Hz) |
| Output Current | 1 A max |
| Signal Isolation | 500 V DC (opto-isolated) |
| Communication Protocols | Ethernet, RS-485, Modbus RTU |
| Physical Dimensions | 185 mm × 80 mm × 54 mm |
| Weight | 0.35 kg |
| Operating Temperature | -20°C to +70°C |
| Protection Rating | IP65 (dust and water ingress) |
| Mounting | DIN rail (35 mm standard) |
| Warranty | 12 months |
Main Features and Advantages
High-Speed Data Handling: The UFC718AE01 supports Ethernet and RS-485 communication, enabling real-time data transmission between power electronic systems and control platforms. This ensures precise coordination of motor drives, inverters, and sensors in applications like robotic assembly lines and wind turbine control.
Robust Power Management: With a 1A output current capacity and surge protection, the module delivers stable power to field devices while safeguarding against voltage spikes. Its galvanic isolation (500 V DC) prevents ground loops and electromagnetic interference (EMI), critical for maintaining signal integrity in noisy industrial environments.
Wide-Range Compatibility: Seamlessly integrating with ABB’s AC800M controllers and third-party systems, the UFC718AE01 supports Modbus RTU and PROFIBUS DP/PA protocols. This flexibility allows retrofitting into legacy systems or upgrading to Industry 4.0 architectures for advanced analytics and remote diagnostics.
Rugged Industrial Design: Built with an IP65-rated enclosure and extended temperature range, the module excels in harsh conditions, including outdoor installations and washdown environments. Its compact DIN rail mount design optimizes cabinet space while ensuring easy installation and maintenance.
Advanced Signal Conditioning: Configurable input thresholds adapt to PNP/NPN sensors and dry contacts, while LED indicators provide real-time channel status. This simplifies troubleshooting and reduces mean time to repair (MTTR) in mission-critical applications.
Application Areas
Industrial Automation: The UFC718AE01 monitors motor drive status, conveyor belt sensors, and valve positions in automotive and electronics manufacturing. Its fast response time (<10 ms) supports high-speed processes, while signal isolation prevents interference from welding or machining operations.
Power Transmission: In elevators, cranes, and fans, the module ensures stable power delivery and precise motor control. Its wide voltage range (85–132 V AC) accommodates diverse power systems, while surge protection enhances reliability in fluctuating grid conditions.
Renewable Energy: Integrating with wind turbines and solar inverters, the UFC718AE01 manages grid synchronization and power conversion. Its IP65 rating and temperature resilience make it suitable for outdoor installations in extreme climates.
Process Control: In chemical plants and wastewater treatment facilities, the module coordinates pump statuses and emergency shutdown systems. Its rugged design and EMI resistance ensure reliable operation in corrosive or high-moisture environments.
Smart Factories: By transmitting real-time sensor data to analytics platforms via Ethernet/IP, the UFC718AE01 enables predictive maintenance and resource optimization. This aligns with Industry 4.0 initiatives to reduce downtime and improve operational efficiency.
Related Products
ABB UAC318AE | HIEE300744R1 | Placa Para Inversor
ABB UAC326AE | HIEE401481R0001 | UA C326 AE
ABB UAC383AE01 HIEE300890R0001 binary input board …
UAC389 | High voltage inverter module | HIEE410506P104
ABB UAC389AE01 | HIEE300888R0001 | UA C389 AE01
Installation and Maintenance
Installation Preparation:
- Verify the DIN rail is securely mounted and compatible with the UFC718AE01’s 35 mm standard. Use shielded cables for signal connections to minimize EMI.
- Connect 85–132 V AC power and field wiring via screw terminals, following the terminal block diagram in the user manual. Configure communication parameters (baud rate, address) via DIP switches or ABB’s System 800xA Workbench software.
Maintenance Recommendations:
- Regularly inspect the module for loose connections or physical damage. Clean the IP65-rated enclosure with a dry cloth to prevent dust accumulation, which could affect thermal performance.
- Monitor LED indicators for channel activity and communication status. Replace faulty modules promptly to maintain system reliability. Update firmware periodically to access new features and security patches via ABB’s global support network.
Product Assurance
ABB guarantees the UFC718AE01 for 12 months against defects in materials and workmanship. The module undergoes rigorous testing to meet international standards (IEC 61131-2, UL 508), ensuring safety and performance in critical applications. ABB’s regional support center in San Jose, CA, offers localized technical assistance, while global inventory ensures 3–5 day delivery post-payment.
For mission-critical operations, consider redundant configurations to mitigate downtime risks. ABB’s digital services, including predictive analytics and remote diagnostics, further enhance system reliability and efficiency.
