Product Overview
The ABB UBC717AE01 HIEE300927R0101 is a high-performance high-voltage inverter board designed for industrial power conversion applications. Engineered by ABB, a global leader in automation and power technologies, this module combines advanced circuit design with robust construction to deliver reliable DC-to-AC conversion in demanding environments. The UBC717AE01 HIEE300927R0101 is part of ABB’s UBC series, which is renowned for its precision in managing high-power energy transitions across renewable energy, industrial automation, and power distribution systems.
The ABB UBC717AE01 HIEE300927R0101 is a high-performance high-voltage inverter board designed for industrial power conversion applications. Engineered by ABB, a global leader in automation and power technologies, this module combines advanced circuit design with robust construction to deliver reliable DC-to-AC conversion in demanding environments. The UBC717AE01 HIEE300927R0101 is part of ABB’s UBC series, which is renowned for its precision in managing high-power energy transitions across renewable energy, industrial automation, and power distribution systems.
Key to its functionality is the ability to efficiently convert direct current (DC) from sources like solar panels, batteries, or wind turbines into grid-compatible alternating current (AC). With a voltage range of 24–690 V AC and short-term tolerance up to 1000 V AC, the UBC717AE01 HIEE300927R0101 excels in applications requiring high-power output, such as solar inverters, wind turbine converters, and uninterruptible power supply (UPS) systems. Its modular design ensures compatibility with ABB’s AC800M controller platform, enabling seamless integration into distributed control systems for real-time monitoring and fault detection.
The UBC717AE01 HIEE300927R0101 features a microprocessor-based architecture that supports a sampling rate of 100 samples per second, ensuring accurate voltage measurement and rapid response to overvoltage conditions. This makes it ideal for protecting critical equipment in power generation, transportation, and industrial processes. Backed by ABB’s rigorous quality standards, the module is built to withstand extreme temperatures (0–60°C) and harsh environments, ensuring long-term reliability in mission-critical applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | UBC717AE01 HIEE300927R0101 |
| Manufacturer | ABB |
| Product Type | High-Voltage Inverter Board |
| Voltage Range | 24–690 V AC (short-term up to 1000 V AC) |
| Measurement Accuracy | ±0.5% of reading |
| Sampling Rate | 100 samples/second |
| Output Signal | 4–20 mA analog output |
| Physical Dimensions | 22.5 mm (W) x 45 mm (H) x 122 mm (D) |
| Weight | 280 g (0.62 lb) |
| Operating Temperature | 0–60°C |
| Input Compatibility | DC sources (e.g., solar panels, batteries) |
| Communication Interface | RS-485 (optional) |
| Warranty | 12 months |
Key Features and Advantages
High-Power Conversion Efficiency: The UBC717AE01 HIEE300927R0101 achieves industry-leading efficiency in DC-to-AC conversion, minimizing energy loss and maximizing power output for renewable energy systems. Its advanced circuit topology ensures stable performance even under fluctuating input conditions.
High-Power Conversion Efficiency: The UBC717AE01 HIEE300927R0101 achieves industry-leading efficiency in DC-to-AC conversion, minimizing energy loss and maximizing power output for renewable energy systems. Its advanced circuit topology ensures stable performance even under fluctuating input conditions.
Precision Voltage Monitoring: Equipped with overvoltage detection capabilities, the module continuously monitors AC system voltage and triggers protective actions within milliseconds to prevent equipment damage. This feature is critical in applications where voltage stability is paramount, such as power distribution grids and industrial motor control.
Modular Design for Flexibility: As part of ABB’s scalable UBC series, the UBC717AE01 HIEE300927R0101 supports easy integration with other ABB components, including the AC800M controller and complementary I/O modules. This modularity allows for cost-effective system expansion and retrofitting.
Rugged Construction: Built to withstand industrial-grade conditions, the module features a compact, IP20-rated housing that resists dust, moisture, and vibrations. Its wide operating temperature range (0–60°C) ensures reliable performance in extreme environments, reducing maintenance costs and downtime.
Applications
The ABB UBC717AE01 HIEE300927R0101 is versatile and finds applications across multiple industries:
The ABB UBC717AE01 HIEE300927R0101 is versatile and finds applications across multiple industries:
- Renewable Energy: Integrates with solar inverters to convert DC solar power into grid-ready AC electricity, and with wind turbine converters to stabilize variable DC outputs.
- Power Generation and Distribution: Monitors and regulates voltage in power plants and substations, ensuring compliance with grid standards and protecting critical infrastructure from overvoltage events.
- Industrial Automation: Controls high-power motors in manufacturing facilities, wastewater treatment plants, and material handling systems, optimizing energy usage and process efficiency.
- Uninterruptible Power Supply (UPS): Converts stored DC battery power into AC backup power during outages, ensuring continuous operation of data centers, hospitals, and emergency systems.
