ABB TU830V1 3BSE013234R1 is a high-performance termination unit specifically engineered for seamless integration with ABB’s AC800M control system and compatible I/O modules, serving as a critical interface for physical wiring termination, signal distribution, and protection in industrial automation environments. This robust unit provides a centralized connection point for field devices (sensors, actuators, switches) and ABB’s I/O modules, ensuring reliable signal transmission while simplifying wiring, maintenance, and troubleshooting—making ABB TU830V1 3BSE013234R1 an indispensable component for distributed control systems. As a core part of ABB’s I/O termination ecosystem, ABB TU830V1 3BSE013234R1 delivers enhanced signal integrity and component protection, bridging the gap between field wiring and control system hardware. Its design prioritizes ease of use, durability, and compatibility with ABB’s extended product portfolio, making ABB TU830V1 3BSE013234R1 suitable for both new installations and legacy system upgrades across diverse industrial sectors.
Technical Specifications
Parameter Name
Parameter Value
Product Model
ABB TU830V1 3BSE013234R1
Manufacturer
ABB
Product Type
I/O Termination Unit
Compatible Control Systems
ABB AC800M, System 800xA
Compatible I/O Modules
ABB AI810, AO810, DI810, DO810, and other AC800M I/O modules
Number of Termination Points
32 terminals (16 pairs for signal/instrumentation)
Simplified Wiring and Termination: ABB TU830V1 3BSE013234R1 features 32 clearly labeled screw terminals, enabling organized termination of field wiring for up to 16 I/O channels. This design reduces wiring complexity, minimizes human error during installation, and simplifies future modifications or expansions—saving time and labor costs for industrial operators.
Enhanced Signal Protection: Equipped with ±2 kV surge protection and short-circuit protection, ABB TU830V1 3BSE013234R1 shields sensitive I/O modules and control system components from voltage spikes, transients, and electrical faults common in industrial environments. This protection ensures uninterrupted signal transmission and extends the lifespan of critical automation hardware.
Seamless ABB Ecosystem Integration: Designed exclusively for ABB’s AC800M control system and System 800xA platform, ABB TU830V1 3BSE013234R1 works seamlessly with ABB’s range of analog and digital I/O modules. Its plug-and-play compatibility eliminates the need for custom adapters, ensuring consistent performance and reducing integration challenges for system designers and technicians.
Rugged and Durable Construction: Built to withstand harsh industrial conditions, ABB TU830V1 3BSE013234R1 features a robust plastic housing, wide operating temperature range (-20°C to +60°C), and resistance to vibration and shock. This durability ensures reliable operation in dusty, temperature-fluctuating environments such as factories, refineries, and power plants.
Facilitates Hot-Swapping: ABB TU830V1 3BSE013234R1 is designed to support hot-swapping of compatible ABB I/O modules, allowing for replacement or maintenance of I/O modules without powering down the entire control system. This feature minimizes unplanned downtime, enhancing operational continuity for mission-critical processes.
Application Fields
ABB TU830V1 3BSE013234R1 is a versatile termination unit tailored for distributed control systems across industries where reliable I/O wiring, signal protection, and easy maintenance are essential. In process manufacturing (chemical, pharmaceutical, and food and beverage), ABB TU830V1 3BSE013234R1 terminates wiring for temperature, pressure, and flow sensors, as well as control valves and actuators, ensuring accurate signal transmission for batch processing and quality control. The unit’s surge protection makes it ideal for oil and gas facilities, where it safeguards I/O modules from voltage transients in offshore platforms, refineries, and pipeline monitoring systems.
In power generation (coal-fired, gas, nuclear, and renewable energy plants), ABB TU830V1 3BSE013234R1 plays a key role in terminating wiring for auxiliary systems such as boiler controls, turbine sensors, and emissions monitoring devices, supporting efficient energy production and grid stability. Water and wastewater treatment plants rely on ABB TU830V1 3BSE013234R1 to terminate wiring for pump starters, level sensors, and flow switches, ensuring reliable operation of treatment processes and compliance with environmental regulations.
Manufacturing industries, including automotive, aerospace, and consumer goods, use ABB TU830V1 3BSE013234R1 in assembly lines and robotic workcells to terminate wiring for proximity sensors, limit switches, and actuators, simplifying maintenance and reducing downtime. Its compatibility with ABB’s AC800M system makes it a valuable asset for any application requiring organized, protected termination of I/O signals in distributed automation setups.
Related Products
ABB AC800M Controller (3BSE018107R1): Central processing unit of ABB’s distributed control system, designed to work seamlessly with ABB TU830V1 3BSE013234R1 for real-time control and data processing.
ABB DI810 Digital Input Module (3BSE004197R1): 16-channel digital input module, compatible with ABB TU830V1 3BSE013234R1 for discrete signal acquisition from field devices.
ABB DO810 Digital Output Module (3BSE004198R1): 16-channel digital output module, paired with ABB TU830V1 3BSE013234R1 for controlling actuators and switches in industrial processes.
ABB TU840V1 Termination Unit (3BSE013235R1): High-density termination unit (64 terminals), offering expanded capacity for large-scale applications requiring more connections than ABB TU830V1 3BSE013234R1.
ABB Control Builder M Software: Engineering tool specifically designed for configuring ABB TU830V1 3BSE013234R1, I/O modules, and the AC800M control system.
ABB AI810 Analog Input Module (3BSE028141R1): 8-channel analog input module, compatible with ABB TU830V1 3BSE013234R1 for capturing continuous process data (temperature, pressure, flow).
