Description

Product Overview

The ABB SUE3000 1VCF750090R0804 is a high-performance high-speed transfer device (HSTD) designed to ensure continuous power supply for critical industrial processes. As a core component of ABB’s ProtectIT series, this module automatically switches load from a faulty main feeder to a standby feeder within milliseconds, minimizing downtime and protecting production systems from costly interruptions. The SUE3000 1VCF750090R0804 integrates advanced control algorithms and communication capabilities, making it ideal for applications requiring seamless power redundancy in harsh industrial environments.

Engineered with ABB’s REF542 Plus protection relay technology, the SUE3000 1VCF750090R0804 supports four configurable transfer modes: fast transfer, first-time phase coincidence transfer, residual voltage-dependent transfer, and time-delayed transfer. Its modular design allows easy integration with existing switchgear, including ABB’s VM1-T high-speed vacuum circuit breakers, ensuring compatibility with diverse voltage levels (110–220 VAC). The device features a built-in HMI (Human-Machine Interface) for local parameter adjustment and real-time status monitoring, enhancing operational flexibility and diagnostic efficiency.

Technical Specifications

Parameter Name	Parameter Value
Product Model	ABB SUE3000 1VCF750090R0804
Manufacturer	ABB
Product Type	High-Speed Transfer Device (HSTD)
Transfer Modes	Fast, Phase Coincidence, Residual Voltage, Time-Delayed
Input Voltage	110–220 VAC ±10%
Switching Time	30–1,500 ms (depending on mode)
Communication Protocols	IEC 61850-8-1, Modbus RTU, Profibus DP, LonWorks
Current Rating	1,000 A (continuous), 3,000 A (surge)
Isolation Voltage	500 VDC (channel to ground)
Operating Temperature	-20°C to +60°C
Physical Dimensions	200 x 198 x 262 mm (W x H x D)
Weight	4.2 kg
Mounting Method	Panel or DIN rail mounting
Certifications	CE, UL, CSA

Key Features and Advantages

Ultra-Fast Power Redundancy: The SUE3000 1VCF750090R0804 achieves industry-leading transfer times as low as 30 ms (with ABB’s VM1-T circuit breakers), ensuring critical loads like data centers and manufacturing lines remain operational during power disruptions.

Multi-Mode Flexibility: Four transfer modes adapt to varying system conditions. For example, fast transfer (30–100 ms) is ideal for stable grids, while residual voltage-dependent transfer (400–1,200 ms) safeguards motors during voltage dips.

Advanced Diagnostics: Built-in fault recording and real-time monitoring via the HMI enable proactive maintenance. The device tracks parameters like voltage phase angles and breaker status, reducing mean time to repair (MTTR).

Robust Compatibility: Seamlessly integrates with ABB’s REF542 Plus protection relays and third-party circuit breakers, supporting all standard voltage levels (110–220 VAC).

Energy Efficiency: By eliminating the need for static UPS systems, the SUE3000 1VCF750090R0804 reduces energy consumption and maintenance costs while delivering higher reliability.

Applications

The ABB SUE3000 1VCF750090R0804 excels in industries where uninterrupted power is critical:

Power Generation: Protects turbine control systems and auxiliary equipment in thermal, nuclear, and gas-fired power plants.
Oil & Gas: Ensures continuous operation of offshore platforms, refineries, and pipeline pumping stations by minimizing downtime during feeder faults.
Manufacturing: Safeguards production lines in automotive, food processing, and pharmaceutical industries, preventing material waste and rework costs.
Mining: Powers conveyor systems, crushers, and hoists in underground and surface mines, reducing operational delays caused by power interruptions.
Data Centers: Maintains UPS-free power redundancy for server racks and cooling systems, ensuring 99.999% uptime.

Installation and Maintenance

Installation Preparation:
Mount the SUE3000 1VCF750090R0804 in a climate-controlled cabinet with IP54 protection. Connect voltage/current sensors and breaker control cables using shielded wiring to minimize EMI. Configure transfer parameters (e.g., voltage thresholds, delay times) via ABB’s Automation Builder software or the local HMI.

Maintenance Recommendations:

Daily: Monitor HMI status LEDs for fault indicators (e.g., red flashing for overloads).
Monthly: Clean dust from vents and verify cable connections, especially in vibrating environments.
Yearly: Perform firmware updates and simulate fault scenarios to validate transfer logic. Replace electrolytic capacitors every 5 years as part of preventive maintenance.

Product Warranty and Support

ABB guarantees the SUE3000 1VCF750090R0804 against defects in materials and workmanship for 1 year from purchase. This warranty covers repair or replacement of faulty components, excluding damage from improper installation or environmental factors. Customers benefit from ABB’s global technical support network, including 24/7 remote diagnostics and on-site commissioning services. Extended warranty plans are available for mission-critical applications, ensuring maximum system availability and performance.

Product Information

Brand Model: ABB SUE3000 1VCF750090R0804
Product Name: High-Speed Transfer Device (HSTD)
Warranty: 1 year
Size: 200 x 198 x 262 mm
Weight: 4.2 kg
Origin: Switzerland
Inventory: Spot/Futures
Delivery Time: Goods in stock will be dispatched within 3 days after payment
Order Time: Goods will be dispatched within one month after payment
