ABB SE96920414 YPK112A: High-Performance Communication Module for Industrial Automation
Product Overview
The ABB SE96920414 YPK112A is a high-reliability communication module designed for ABB’s industrial automation systems, specializing in seamless data exchange between control devices in complex industrial environments. As a core component of ABB’s SDCS (Supervisor Drive Control System) and Advant OCS platforms, the SE96920414 YPK112A enables real-time communication between PLCs, HMIs, and field devices, ensuring precise coordination in applications such as process control, motor drives, and robotics.
Engineered with Modbus RTU/ASCII protocol support, the SE96920414 YPK112A features dual RS232/RS485 interfaces, allowing simultaneous connection to up to 32 slave devices with a communication rate of 9600–115200 bps 120. Its IP20-rated enclosure and -20°C to +55°C operating range make it suitable for harsh industrial conditions, while hot-swap functionality ensures minimal downtime during maintenance. The module integrates with ABB’s DriveWindow software for intuitive configuration and diagnostics, reducing commissioning time by up to 30%.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB SE96920414 YPK112A |
| Manufacturer | ABB |
| Product Type | Industrial Communication Module |
| Communication Protocols | Modbus RTU/ASCII, PROFIBUS DP (optional via expansion) |
| Interfaces | 2 x RS232/RS485 (configurable), 1 x Ethernet (optional) |
| Input Voltage | 24V DC (±15%) 15 |
| Data Rate | 9600–115200 bps 27 |
| Supported Slave Devices | Up to 32 |
| Operating Temperature | -20°C to +55°C |
| Enclosure Rating | IP20 (DIN rail-mounted) |
| Physical Dimensions | 252mm x 40mm x 273mm 20 |
| Weight | 1.44kg 20 |
| Certifications | CE, UL 508 (pending RoHS compliance) |
| Mounting | DIN rail (EN 50022) |
Key Features and Advantages
Multi-Protocol Flexibility:
The SE96920414 YPK112A supports Modbus RTU/ASCII as standard, with optional PROFIBUS DP or Ethernet connectivity via expansion modules, ensuring compatibility with legacy and modern automation systems. Its adaptive baud rate detection automatically synchronizes with connected devices, eliminating manual configuration errors 27.
The SE96920414 YPK112A supports Modbus RTU/ASCII as standard, with optional PROFIBUS DP or Ethernet connectivity via expansion modules, ensuring compatibility with legacy and modern automation systems. Its adaptive baud rate detection automatically synchronizes with connected devices, eliminating manual configuration errors 27.
Rugged Industrial Design:
With IP20 protection and a wide temperature range, the module withstands dust, vibrations, and extreme conditions common in manufacturing plants and mining operations. Dual-channel redundancy (optional) ensures uninterrupted communication in mission-critical applications like oil refineries and power generation 120.
With IP20 protection and a wide temperature range, the module withstands dust, vibrations, and extreme conditions common in manufacturing plants and mining operations. Dual-channel redundancy (optional) ensures uninterrupted communication in mission-critical applications like oil refineries and power generation 120.
Effortless Integration:
Seamless integration with ABB’s DriveWindow software allows users to configure protocols, monitor data flow, and troubleshoot remotely. The module’s plug-and-play design reduces installation time, while LED indicators provide real-time status feedback for quick diagnostics.
Seamless integration with ABB’s DriveWindow software allows users to configure protocols, monitor data flow, and troubleshoot remotely. The module’s plug-and-play design reduces installation time, while LED indicators provide real-time status feedback for quick diagnostics.
Cost-Effective Scalability:
By supporting up to 32 slave devices per port, the SE96920414 YPK112A minimizes hardware costs compared to single-device communication solutions. Its modular architecture enables easy expansion of I/O capabilities via ABB’s SDCS-FEX-2 fieldbus extension module 18.
By supporting up to 32 slave devices per port, the SE96920414 YPK112A minimizes hardware costs compared to single-device communication solutions. Its modular architecture enables easy expansion of I/O capabilities via ABB’s SDCS-FEX-2 fieldbus extension module 18.
Application Areas
The SE96920414 YPK112A excels in industries requiring reliable inter-device communication:
- Process Automation:
- Data exchange between PLCs and distributed I/O systems in chemical plants.
- Real-time monitoring of pump and valve status in water treatment facilities.
- Manufacturing:
- Coordination of robotic arms and conveyor systems in automotive assembly lines.
- Remote diagnostics of CNC machines in metalworking factories.
- Energy Sector:
- Integration of wind turbine SCADA systems with grid control centers.
- Communication between solar inverters and energy management platforms.
- Mining and Metals:
- Control of conveyor belts and crushers in mineral processing plants.
- Remote monitoring of underground equipment via RS485 networks.
Related Products
- ABB SDCS-PIN-4: PROFIBUS DP interface module for enhanced connectivity with the SE96920414 YPK112A.
- ABB SDCS-COM-8: Ethernet communication module for cloud-based monitoring and IIoT integration.
- ABB DrivesWindow: Software tool for configuring and troubleshooting the SE96920414 YPK112A.
- ABB SDCS-FEX-2: Fieldbus extension module for expanding I/O capabilities in modular systems.
- ABB SDCS-CON-2B: Drive control module compatible with the SE96920414 YPK112A for unified automation.
- ABB SDCS-AMI-1: Analog input module for sensor integration in process control.
- ABB SDCS-PIN-8: High-speed encoder interface for precision motion control applications.
- ABB ACS580-01: Low-voltage drive series optimized for use with the SE96920414 YPK112A.
- ABB SDCS-PIN-2: Serial communication interface for legacy system compatibility.
- ABB SDCS-AMC-CLAS2: Motor control module for synchronized drive system operation.
Installation and Maintenance
Installation Preparation:
- Mount the SE96920414 YPK112A on a DIN rail with 40mm clearance for airflow.
- Connect 24V DC power and RS232/RS485 cables using ABB’s TB841 terminal blocks (2.5 N·m torque).
- Configure communication parameters via ABB’s DriveWindow software, selecting Modbus RTU/ASCII mode and baud rate (e.g., 9600 bps) 27.
Maintenance Recommendations:
- Perform quarterly inspections for loose connections and thermal stress signs.
- Update firmware annually via ABB’s Drive composer Pro to access new protocol support.
- Clean the enclosure with compressed air to maintain IP20 protection.
- Replace electrolytic capacitors every 5–7 years to prevent voltage instability.
Product Assurance
ABB guarantees the SE96920414 YPK112A with a 1-year warranty covering defects in materials and workmanship. Our global service network provides 24/7 technical support, including remote diagnostics via the ABB Ability™ platform and on-site assistance from certified engineers. All modules undergo rigorous testing to meet CE and UL 508 standards, ensuring reliable performance in mission-critical applications. For high-reliability needs, ABB offers extended warranties and lifecycle management services.
