Description
ABB SD821: High-Speed PROFINET/PROFIBUS DP Communication Module for Industrial Control Systems
Product Overview
The ABB SD821 is a high-performance dual-protocol communication module designed for seamless integration of industrial automation systems. As part of ABB’s AC800M modular control platform, this module supports PROFINET IO RT and PROFIBUS DP V1, enabling real-time data exchange between field devices (e.g., sensors, actuators) and centralized controllers. With dual-port redundancy and hot-swap capabilities, the SD821 ensures continuous operation in mission-critical environments, such as chemical plants, power generation facilities, and smart manufacturing lines.
Engineered for reliability, the SD821 features a 32-bit ARM Cortex-M4 processor (400 MHz) and 64 MB RAM + 128 MB flash memory, delivering low-latency data processing and robust protocol handling. Its IP20-rated enclosure and EMI shielding (reducing interference by 30%) ensure stable performance in high-noise industrial settings. The module integrates seamlessly with ABB’s Advant OCS and Industrial IT systems, supporting OPC UA for cloud-based analytics and predictive maintenance.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB SD821 |
| Manufacturer | ABB |
| Product Type | PROFINET/PROFIBUS DP Communication Module |
| Input Voltage | 24V DC (±15%) with redundant power inputs |
| Communication Protocols | PROFINET IO RT, PROFIBUS DP V1, Modbus RTU, OPC UA |
| Data Rate | 100 Mbps (PROFINET) / 12 Mbps (PROFIBUS DP) |
| Interfaces | 2 x RJ45 (PROFINET), 2 x 9-pin D-sub (PROFIBUS DP) |
| Processor | 32-bit ARM Cortex-M4 (400 MHz, 20% faster than previous models) |
| Memory | 64 MB RAM + 128 MB flash (expandable via S100 I/O bus) |
| Operating Temperature | -25°C to +60°C (ambient) |
| Enclosure Rating | IP20 (DIN rail-mounted) |
| Certifications | CE, UL 508, IEC 61131-2, RoHS |
| Physical Dimensions | 125mm x 100mm x 50mm |
| Weight | ~0.8kg |
| Mounting | DIN rail (EN 50022) with spring-loaded clips |
Key Features and Advantages
Dual-Protocol Flexibility:
The SD821 supports both PROFINET IO RT and PROFIBUS DP V1, allowing seamless integration of legacy devices with modern industrial Ethernet networks. This hybrid capability is critical for retrofitting older systems while enabling Industry 4.0 upgrades, such as predictive maintenance via OPC UA.
The SD821 supports both PROFINET IO RT and PROFIBUS DP V1, allowing seamless integration of legacy devices with modern industrial Ethernet networks. This hybrid capability is critical for retrofitting older systems while enabling Industry 4.0 upgrades, such as predictive maintenance via OPC UA.
Redundant Architecture:
Dual-port redundancy ensures uninterrupted communication even if one port fails, while hot-swap functionality allows module replacement without system downtime. Redundant 24V DC inputs further enhance reliability in unstable power environments.
Dual-port redundancy ensures uninterrupted communication even if one port fails, while hot-swap functionality allows module replacement without system downtime. Redundant 24V DC inputs further enhance reliability in unstable power environments.
High-Speed Data Handling:
With a 100 Mbps PROFINET and 12 Mbps PROFIBUS DP data rate, the module supports real-time control applications like robotics and process automation. The ARM Cortex-M4 processor ensures low-latency data processing for time-sensitive operations.
With a 100 Mbps PROFINET and 12 Mbps PROFIBUS DP data rate, the module supports real-time control applications like robotics and process automation. The ARM Cortex-M4 processor ensures low-latency data processing for time-sensitive operations.
Advanced Diagnostics:
Built-in LED indicators provide instant visibility into power status, communication activity, and fault conditions. The module also supports remote diagnostics via ABB’s Ability™ platform, enabling proactive maintenance and reducing mean time to repair (MTTR).
Built-in LED indicators provide instant visibility into power status, communication activity, and fault conditions. The module also supports remote diagnostics via ABB’s Ability™ platform, enabling proactive maintenance and reducing mean time to repair (MTTR).
Applications
The SD821 excels in industries requiring reliable and flexible communication solutions:
- Process Automation:
- Connecting distributed I/O modules (e.g., ABB CI535) to DCS systems in chemical and petrochemical plants.
- Real-time monitoring of pressure/flow sensors in water treatment facilities.
- Power Generation:
- Control of turbine auxiliary systems in thermal power plants.
- Grid-connected inverter management in renewable energy installations.
- Smart Manufacturing:
- Multi-machine synchronization in automotive assembly lines.
- Integration of legacy PLCs (e.g., ABB AC500) with modern SCADA systems.
- Marine and Offshore:
- Engine room monitoring with redundant communication links.
- Subsea control module (SCM) integration in offshore oil platforms.
Related Products
- ABB SD803F: PROFINET-only variant for Ethernet-centric systems.
- ABB SD804F: PROFIBUS DP V1 module with extended diagnostic capabilities.
- ABB CI535: PROFIBUS DP/Modbus RTU communication module for legacy systems.
- ABB PM511MV08: PLC processor for unified control system integration.
- ABB AC800M DCS: Modular control platform for mid-to-large-scale automation.
- ABB TB841 Terminal Blocks: Required for secure field wiring.
- ABB Engineering Workplace: Configuration software for parameter setup.
- ABB Ability™ Edge: Edge computing platform for real-time analytics.
- ABB SD821-1: Industrial-grade variant with extended temperature range (-40°C to +85°C).
- ABB Lifecycle Care Service: Extended warranty and maintenance plans.
Installation and Maintenance
Installation Preparation:
Mount the SD821 on a DIN rail with 30mm clearance for airflow. Connect dual redundant 24V DC inputs using ABB’s TB841 terminal blocks (1.5 N·m torque). Configure communication parameters via ABB’s Engineering Workplace software, ensuring PROFINET device names and PROFIBUS DP addresses align with the network topology.
Mount the SD821 on a DIN rail with 30mm clearance for airflow. Connect dual redundant 24V DC inputs using ABB’s TB841 terminal blocks (1.5 N·m torque). Configure communication parameters via ABB’s Engineering Workplace software, ensuring PROFINET device names and PROFIBUS DP addresses align with the network topology.
Maintenance Recommendations:
- Perform monthly visual inspections for loose connections or thermal stress signs.
- Update firmware annually via ABB’s Remote Support Portal to access new protocol features.
- Clean the enclosure with a dry cloth to maintain IP20 protection.
- Replace the module every 10 years (MTBF) or after 100,000 hours of operation.
- For PROFIBUS DP networks, check segment termination resistors every 6 months.
Product Assurance
ABB guarantees the SD821 with an 18-month warranty covering defects in materials and workmanship. Our global service network provides 24/7 technical support, including remote diagnostics via the Ability™ platform and on-site assistance from certified engineers. All modules undergo rigorous testing to meet ISO 9001, IEC 61131-2, and UL 508 standards, ensuring reliable operation in mission-critical applications. For high-reliability needs, ABB offers 5-year extended warranties and proactive component replacement programs.
HS:8471800000
