Description
ABB S3N 3P 150A: High-Performance Molded Case Circuit Breaker for Industrial Power Protection
Product Overview
The ABB S3N 3P 150A is a robust molded case circuit breaker (MCCB) designed for critical power distribution applications in industrial, commercial, and infrastructure settings. As part of ABB’s S3N series, this three-pole (3P) breaker provides reliable protection against overloads, short circuits, and ground faults, ensuring safe and efficient operation in low-voltage systems up to 690V AC6. With a 150A rated current and 50kA short-circuit breaking capacity (Icu), the ABB S3N 3P 150A is ideal for demanding environments such as manufacturing plants, data centers, and power generation facilities.
Featuring a thermal-magnetic trip unit, the ABB S3N 3P 150A offers adjustable overload protection (Ir) and short-circuit protection (Im), allowing precise customization to match specific load requirements25. Its compact design (170 x 108 x 107 mm) and DIN rail mounting compatibility enable easy integration into standard control panels, while the IP20-rated enclosure safeguards against dust and accidental contact5. The breaker’s self-diagnostic LED indicators provide real-time status feedback, simplifying maintenance and reducing downtime.
Compliant with IEC 60947-2 and UL 489 standards, the ABB S3N 3P 150A ensures global interoperability and meets the highest safety requirements for mission-critical applications. Its modular design supports optional accessories such as auxiliary contacts, shunt trip coils, and communication modules, enhancing flexibility for advanced monitoring and automation10.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB S3N 3P 150A |
| Manufacturer | ABB |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Rated Current | 150A |
| Rated Voltage | 690V AC |
| Short-Circuit Breaking Capacity (Icu) | 50kA (N-type) |
| Overload Protection (Ir) | 0.7–1.0 x In (adjustable) |
| Short-Circuit Protection (Im) | 5–10 x In (adjustable) |
| Number of Poles | 3P |
| Mounting | DIN rail (EN 50022) |
| Physical Dimensions | 170 x 108 x 107 mm |
| Weight | ~1.2 kg |
| Operating Temperature | -5°C to +60°C |
| Certifications | IEC 60947-2, UL 489, CE |
| Accessories | Auxiliary contacts, shunt trip coils, communication modules |
Key Features and Advantages
High Reliability: The ABB S3N 3P 150A combines a thermal-magnetic trip unit with 50kA short-circuit breaking capacity, ensuring rapid fault interruption and protection against catastrophic failures7. Its IP20-rated enclosure and robust construction withstand harsh industrial environments, including temperature extremes and voltage fluctuations5.
Adjustable Protection: Users can fine-tune Ir (overload) and Im (short-circuit) settings via the front-panel dial, adapting the breaker to specific load profiles. This flexibility reduces the need for custom hardware solutions and minimizes downtime during system adjustments25.
Modular Design: The breaker supports a wide range of optional accessories, such as auxiliary contacts for remote status monitoring, shunt trip coils for remote tripping, and communication modules for integration with SCADA systems. This modularity enhances system scalability and diagnostic capabilities10.
Easy Maintenance: Built-in LED indicators display trip status (overload, short circuit) and operational health, streamlining troubleshooting. The breaker’s DIN rail mounting allows quick replacement without rewiring, reducing maintenance time and costs5.
Global Compliance: Certified to IEC 60947-2 and UL 489, the ABB S3N 3P 150A meets international safety standards, ensuring seamless integration into global power distribution networks25.
Applications
The ABB S3N 3P 150A excels in industries requiring reliable circuit protection and precise load management:
- Industrial Manufacturing: Protecting motors, pumps, and conveyor systems in automotive plants, chemical facilities, and food processing lines.
- Data Centers: Ensuring uninterrupted power supply to critical IT infrastructure, including servers and cooling systems.
- Power Generation: Safeguarding generators, transformers, and switchgear in thermal, hydroelectric, and renewable energy plants.
- Commercial Buildings: Providing overload protection for HVAC systems, lighting circuits, and elevators in office towers and shopping complexes.
- Mining: Managing high-power equipment in underground and surface mining operations, including crushers and ventilation systems14.
By integrating with ABB’s Emax 2 circuit breakers and i-bus® control systems, the ABB S3N 3P 150A enables predictive maintenance and real-time energy monitoring, optimizing operational efficiency and reducing lifecycle costs.
Related Products
- ABB S3N 3P 100A: Lower current rating (100A) for less demanding applications, suitable for small-scale industrial processes.
- ABB S3N 4P 150A: Four-pole version for three-phase systems with neutral conductors, ideal for commercial and residential power distribution.
- ABB Emax 2 E2.2: High-performance MCCB with advanced digital trip units, offering enhanced diagnostic and communication capabilities.
- ABB i-bus® Communication Module: Enables integration with ABB’s building automation systems for remote monitoring and control.
- ABB Shunt Trip Coil: Allows remote tripping of the S3N 3P 150A via external signals, critical for emergency shutdown systems10.
Installation and Maintenance
Installation Preparation:
- Verify the power supply matches the ABB S3N 3P 150A’s 690V AC requirements and ensure proper grounding to prevent electrical interference.
- Mount the breaker on a DIN rail within the switchboard, following IEC standards for mechanical stability.
- Connect cables to the M6 screw terminals, tightening to 8 N·m torque to ensure secure connections5.
Maintenance Recommendations:
- Regularly inspect LED indicators to identify fault conditions. Replace faulty breakers immediately to maintain system integrity.
- Clean the breaker’s surface periodically to remove dust and debris, ensuring optimal thermal performance in high-temperature environments.
- Perform annual calibration checks using ABB’s Trip Unit Testing Kit to verify Ir and Im settings accuracy12.
Product Assurance
ABB guarantees the ABB S3N 3P 150A with a 1-year warranty covering defects in materials and workmanship. Our global support network provides 24/7 technical assistance, including remote diagnostics and on-site service. All breakers undergo rigorous testing to meet ISO 9001 standards, ensuring consistent performance across diverse industrial applications. For mission-critical projects, ABB offers extended warranties and lifecycle management services to maximize system longevity and reliability1012.
HS:8517699000
