ABB S-113H 3BHB018008R0003: High-Performance Digital Input/Output Module for Industrial Automation

Product Overview

The ABB S-113H 3BHB018008R0003 is a high-reliability digital input/output (I/O) module designed for distributed control systems (DCS) and programmable logic controllers (PLCs), with a focus on industrial automation and process control applications. As part of ABB’s 800xA control system, this module delivers precise signal handling and seamless integration with ABB’s advanced automation platforms, making it ideal for industries such as oil & gas, power generation, and manufacturing.

Featuring 32 configurable I/O channels (expandable from 8 to 32), the ABB S-113H 3BHB018008R0003 supports both digital inputs and outputs, enabling real-time monitoring and control of field devices like sensors, actuators, and valves. Its 24V DC power supply ensures stable operation in harsh industrial environments, while the Ethernet and serial communication interfaces facilitate integration with third-party systems and SCADA platforms . The module’s compact design (160 x 80 x 60 mm) and DIN rail mounting compatibility allow for easy installation in space-constrained control cabinets.

Compliant with IEC 61131-3 programming standards, the ABB S-113H 3BHB018008R0003 offers flexible configuration options, including input filtering and output signal conditioning. Its diagnostic capabilities, such as channel-level fault detection and status indicators, minimize downtime and simplify maintenance. With a 1500Hz output frequency and 40-point I/O capacity, this module balances high-speed performance with scalability, making it suitable for both small-scale applications and large industrial complexes .

Technical Specifications

Parameter	Value
Product Model	ABB S-113H 3BHB018008R0003
Manufacturer	ABB
Product Type	Digital Input/Output Module
I/O Channels	32 configurable (8–32)
Input Voltage Range	24V DC ±10%
Output Voltage	24V DC
Output Frequency	1500Hz
Communication Interfaces	Ethernet, RS-485
Resolution	12-bit
Response Time	<5 ms
Operating Temperature	-25°C to +70°C
Physical Dimensions	160 x 80 x 60 mm
Weight	~0.8 kg
Mounting	DIN rail (EN 50022)
Compliance	IEC 61131-3, CE, UL

Key Features and Advantages

Flexible Configuration: The ABB S-113H 3BHB018008R0003 allows users to configure each channel as either digital input or output, adapting to diverse control requirements. Input filtering (programmable 1–100 ms) reduces noise interference, while output signal conditioning ensures reliable actuation of field devices .

High Reliability: Built with industrial-grade components, the module withstands extreme temperatures (-25°C to +70°C) and voltage fluctuations (24V DC ±10%). Its self-diagnostic features monitor channel integrity and report faults via LED indicators, enabling proactive maintenance and minimizing downtime .

Seamless Integration: As part of ABB’s 800xA control system, the module supports OPC UA and Modbus protocols, ensuring compatibility with ABB’s AC 800M controllers and third-party software. This integration simplifies system design and reduces engineering effort .

Scalability: With 32 configurable channels, the module is suitable for both small-scale applications (e.g., HVAC control) and large industrial processes (e.g., power plant automation). Its compact size allows for dense I/O packing, optimizing cabinet space .

Safety Compliance: The ABB S-113H 3BHB018008R0003 meets IEC 61131-3 standards for industrial control systems, ensuring safe and reliable operation in critical environments such as chemical plants and oil refineries .

Applications

The ABB S-113H 3BHB018008R0003 excels in industries requiring precise control and real-time monitoring:

Oil & Gas: Monitoring pressure sensors and actuating valves in wellheads and pipelines to prevent leaks and optimize production.
Power Generation: Controlling turbine speed and generator output in thermal and hydroelectric plants, ensuring grid stability.
Manufacturing: Automating assembly lines through sensor-based quality control and robotic arm coordination.
HVAC Systems: Regulating temperature, humidity, and airflow in commercial buildings and industrial facilities .
Mining: Managing conveyor belts, crushers, and ventilation systems in underground and surface mines.

By integrating with ABB’s 800xA system, the module enables predictive maintenance and remote diagnostics, enhancing operational efficiency and reducing lifecycle costs.

Installation and Maintenance

Installation Preparation:

Verify the power supply matches the ABB S-113H 3BHB018008R0003’s 24V DC requirements and ensure proper grounding to prevent electrical interference.
Mount the module on a DIN rail within the 800xA system chassis, following IEC standards for mechanical stability.
Connect shielded cables to the I/O terminals, ensuring proper termination to minimize noise ingress .

Maintenance Recommendations:

Regularly inspect diagnostic LEDs to identify faulty channels. Replace defective modules immediately to maintain system integrity.
Perform firmware updates using ABB’s Engineering Workplace software to access the latest features and security patches.
Clean the module’s surface periodically to remove dust and debris, ensuring optimal thermal performance in high-temperature environments .

Product Assurance

ABB guarantees the ABB S-113H 3BHB018008R0003 with a 1-year warranty covering defects in materials and workmanship. Our global support network provides 24/7 technical assistance, including remote troubleshooting and on-site service. All modules undergo rigorous testing to meet ISO 9001 standards, ensuring consistent performance across diverse industrial applications. For mission-critical projects, ABB offers extended warranties and lifecycle management services to maximize system longevity and reliability.
