ABB PU516 Engineering Interface Module(XIONGBA)

Brand ModelABB PU516 3BSE013064R1
Product Name: Engineering Interface Module
Warranty: 1 year
Size: 324 mm × 126 mm × 18 mm
Weight: 0.38 kg
Origin: Sweden
Inventory: Spot
Delivery Time: 3 days after payment

Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

Product Overview

The ABB PU516 is a high-performance Engineering Interface Module designed for ABB’s Advant OCS and Advant Master industrial control systems. As a critical component of ABB’s automation ecosystem, this module serves as a bridge between engineering workstations and field-level controllers, enabling seamless configuration, monitoring, and diagnostics of complex industrial processes. The ABB PU516 integrates a PCI bus interface and 16 MB memory to support real-time data exchange and advanced programming capabilities, making it essential for mission-critical applications in industries such as oil & gas, power generation, and water treatment. Its compact design and rugged construction ensure reliable operation in harsh environments, while compatibility with ABB’s Automation Builder software streamlines system integration and maintenance.

Technical Specifications

Parameter Name Parameter Value
Product Model ABB PU516 3BSE013064R1
Manufacturer ABB
Product Type Engineering Interface Module (Advant OCS Series)
Bus Interface PCI (32-bit, 33 MHz)
Memory 16 MB RAM
Communication Ports 1x MB300 port, 1x RS-232 port
Power Supply 5V DC (1A)
Operating Temperature 0°C to +50°C
Storage Temperature -20°C to +70°C
Dimensions 324 mm × 126 mm × 18 mm
Weight 0.38 kg
Certifications CE, UL 60950-1, IP54 (environmental protection)
Compatibility ABB Advant OCS, Advant Master, and AC 800M control systems
Mounting Method PCI slot installation

Key Features and Advantages

Advanced Engineering Capabilities

The ABB PU516 acts as a dedicated interface for programming and configuring ABB’s Advant OCS controllers, allowing engineers to develop, test, and deploy control logic efficiently. Its MB300 port enables high-speed communication with ABB’s MasterBus 300 network, while the RS-232 port supports legacy device connectivity. The module’s 16 MB memory ensures smooth handling of large-scale control programs and diagnostic data .

Rugged Industrial Design

Built to withstand industrial environments, the ABB PU516 features an IP54-rated enclosure that protects against dust and splashes. Its wide operating temperature range (0°C to +50°C) and robust vibration resistance (IEC 60068-2-6) make it suitable for applications in oil rigs, power plants, and manufacturing facilities where reliability is critical .

Seamless System Integration

As part of ABB’s modular automation platform, the ABB PU516 integrates seamlessly with ABB’s AC 800M controllers and S800 I/O systems. This interoperability simplifies system expansion and reduces downtime during upgrades. The module’s PCI interface ensures compatibility with standard industrial PCs, eliminating the need for specialized hardware .

Enhanced Diagnostics and Maintenance

The ABB PU516 includes built-in diagnostic tools that monitor system health in real time, alerting operators to potential issues such as communication failures or memory overload. Its hot-swappable design allows for component replacement without disrupting system operation, minimizing maintenance downtime .

Application Areas

Process Control Systems

Deployed in chemical plants and refineries to manage complex processes like distillation, polymerization, and quality control. The ABB PU516 ensures precise coordination between field devices and supervisory systems, optimizing production efficiency .

Power Generation and Distribution

Used in power plants to configure and monitor turbine control systems, generator synchronization, and grid stabilization. Its real-time data processing capabilities help maintain grid stability and reduce downtime during load fluctuations .

Water and Wastewater Treatment

Applied in water treatment facilities to manage pumping systems, filtration processes, and environmental monitoring. The ABB PU516 supports remote diagnostics, enabling proactive maintenance of critical infrastructure .

Manufacturing Automation

Integrated into factory automation systems to program and monitor robotics, conveyor belts, and quality inspection stations. Its compatibility with ABB’s Automation Builder software simplifies the development of custom control solutions .

Related Products

Model Relationship/Use Case
ABB PU512V2 Predecessor RTA module with lower memory capacity, suitable for smaller-scale applications.
ABB PU515A High-performance RTA module with expanded I/O capabilities, often paired with PU516 for complex systems.
ABB CI524 Profibus DP communication module that complements PU516 for extended network connectivity.
ABB PM510 I/O module designed for seamless integration with PU516 in modular control setups.
ABB AI542 Analog input module used alongside PU516 for signal acquisition in process control.
ABB DI521 Digital input module for monitoring binary signals in industrial automation.

Installation and Maintenance

Installation Preparation:
Ensure the host PC’s PCI slot supports 32-bit, 33 MHz operation. Power off the system before installing the ABB PU516 and secure it using the provided mounting bracket. Connect the MB300 and RS-232 cables with torque-controlled connectors (8 N·m). Use ABB’s Automation Builder software to initialize the module and configure communication parameters .



Maintenance Recommendations:
Conduct quarterly inspections to check for loose connections or thermal stress. Clean the module with a static-free cloth to prevent dust accumulation. Update firmware regularly to access new features and security patches. ABB’s Predictive Maintenance Service offers remote health monitoring to identify potential failures before they occur .

Product Assurance

ABB provides a 1-year standard warranty for the ABB PU516 3BSE013064R1, covering defects in materials and workmanship. Customers benefit from ABB’s Global Service Network, which offers 24/7 technical support, rapid spare parts delivery, and on-site maintenance. The module undergoes rigorous testing for electromagnetic compatibility (EMC) and environmental resilience to ensure compliance with international standards. For high-reliability applications, ABB’s Extended Warranty Service (EWT) extends coverage to 5 years, reducing lifecycle costs .
