Description

Product Overview

The ABB PS201PRE is a high-performance industrial fuse module designed for critical circuit protection in power distribution and automation systems. As part of ABB’s FERRAZ series, this module offers reliable overload and short-circuit protection, making it ideal for applications requiring robust electrical safety in harsh industrial environments. The PS201PRE features a compact design with high breaking capacity, ensuring compatibility with a wide range of industrial equipment, including motor control centers (MCCs), switchgear, and power distribution panels.

Technical Specifications

Parameter Name	Parameter Value
Product Model	ABB PS201PRE
Manufacturer	ABB
Product Type	Fuse Module (FERRAZ Series)
Rated Voltage	250 V AC/DC (standard), up to 690 V AC with derating
Rated Current	10–63 A (selectable via variants)
Breaking Capacity	100 kA (IEC 60269-1)
Fuse Type	High rupturing capacity (HRC) cartridge fuse
Protection Class	IP20 (dust protection)
Operating Temperature	-25°C to +65°C
Vibration Resistance	5–500 Hz, 5 g (IEC 60068-2-6)
Dimensions	100 mm × 60 mm × 80 mm
Weight	0.35 kg
Certifications	CE, UL 60269-1, cUL, ATEX Zone 2

Key Features and Advantages

Precision Circuit Protection

The ABB PS201PRE employs advanced HRC fuse technology to provide rapid fault interruption, minimizing downtime and equipment damage. Its selective tripping characteristics ensure that only the faulty circuit is isolated, maintaining power continuity to critical systems. The module supports a wide current range (10–63 A), accommodating diverse load requirements in industrial settings.

Robust Construction

Built with high-quality materials and conformal coating, the PS201PRE withstands extreme temperatures, vibrations, and corrosive environments. Its IP20 rating protects against dust ingress, while the compact design allows easy integration into space-constrained panels. The fuse module is also compatible with ABB’s S200 and F200 series circuit breakers, enhancing system flexibility.

Easy Installation and Maintenance

The PS201PRE features a plug-in design for quick replacement, reducing downtime during maintenance. The fuse cartridge is visible through a transparent window, enabling visual inspection of the fuse element without disassembly. ABB’s modular system allows seamless integration with other FERRAZ series components, simplifying inventory management and system expansion.

Application Areas

Power Distribution

Deployed in industrial switchgear and MCCs to protect transformers, cables, and control circuits from overloads and short circuits. The PS201PRE ensures safe operation in power-intensive environments, such as manufacturing plants and data centers.

Motor Control

Integrated into motor control circuits to safeguard against phase loss, overcurrent, and voltage fluctuations. Its high breaking capacity makes it suitable for protecting high-power motors in applications like conveyor systems and pumps.

Renewable Energy

Used in solar and wind power installations to protect inverters, batteries, and DC distribution systems. The module’s ATEX certification allows deployment in explosive atmospheres, ensuring compliance with safety standards in energy production.

Commercial Buildings

Supports electrical systems in office complexes and hospitals by protecting lighting, HVAC, and emergency power circuits. The PS201PRE’s reliable protection helps maintain uninterrupted operations in critical infrastructure.

Related Products

Model	Relationship/Use Case
FERRAZ F097203	Direct replacement fuse cartridge for PS201PRE.
S201P Series	Miniature circuit breakers for complementary overcurrent protection.
PS2/12	Lower-current variant (12 A) for small-scale applications.
CP-C.1 Power Supply	High-performance power supply often paired for integrated control systems.
S800 I/O System	Complementary I/O platform for modular automation systems.

Installation and Maintenance

Installation Preparation:
Mount the ABB PS201PRE on a DIN rail using standardized clips, ensuring proper alignment with adjacent components. Connect power inputs with 4 mm² stranded cables and secure terminals with torque wrenches (8 N·m). Use ABB’s System 800xA software to configure fault monitoring and diagnostic settings.

Maintenance Recommendations:
Conduct quarterly visual inspections to check for signs of thermal damage or loose connections. Replace fuses immediately after tripping, ensuring the correct rating (10–63 A) is selected for the application. Inspect the fuse window for discoloration, indicating potential degradation. ABB’s Extended Warranty Service (EWT) is available for extended coverage, providing peace of mind for mission-critical systems 17.

Product Assurance

ABB provides a 1-year standard warranty for the PS201PRE, covering manufacturing defects and material failures. Customers benefit from ABB’s Global Service Network, offering 24/7 technical support, rapid spare parts dispatch, and on-site maintenance. The module undergoes rigorous testing for thermal stability, vibration resistance, and electromagnetic compatibility to ensure compliance with international standards.
