Brand Model: ABB PS130/6-75-P
Product Name: Industrial Servo Motor Module
Warranty: 1 year
Size: 180 mm × 220 mm × 150 mm
Weight: 5.2 kg
Origin: Sweden
Inventory: Spot
Delivery Time: 3 days after payment

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

Product Overview

The ABB PS130/6-75-P is a high-performance servo motor module designed for industrial automation and robotics applications within ABB’s advanced motion control portfolio. Engineered to deliver precise torque and speed control, this module integrates seamlessly with ABB’s robotics systems, distributed control systems (DCS), and motor control centers (MCCs). The PS130/6-75-P supports multi-axis synchronization and real-time diagnostics, making it ideal for demanding manufacturing environments, such as automotive assembly lines and CNC machining. Its compact design and rugged construction enable deployment in high-vibration industrial settings while maintaining energy efficiency and reliability.

Technical Specifications

Parameter Name Parameter Value
Product Model ABB PS130/6-75-P
Manufacturer ABB
Product Type Servo Motor Module (Robotics Series)
Power Supply 220–380 V AC (3-phase), 50/60 Hz
Rated Output Power 7.5 kW
Rated Torque 48 N·m
Speed Range 0–3000 RPM
Encoder Resolution 20-bit absolute encoder
Communication Protocol Profibus DP, CANopen, Modbus RTU
Control Accuracy ±0.1% of full scale
Protection Class IP54 (dust and water ingress protection)
Operating Temperature -25°C to +65°C (standard), -40°C to +85°C with derating
Vibration Resistance 5–500 Hz, 5 g (IEC 60068-2-6)
Dimensions 180 mm × 220 mm × 150 mm
Weight 5.2 kg
Certifications CE, UL 60730-1, cUL, ATEX Zone 2

Key Features and Advantages

Precision Motion Control

The ABB PS130/6-75-P employs advanced vector control algorithms to achieve ±0.1% speed regulation, ensuring smooth and accurate positioning in robotic arms and CNC machines. Its 20-bit absolute encoder provides high-resolution feedback, critical for applications requiring sub-millimeter precision, such as semiconductor manufacturing and medical device assembly.

Robust Industrial Connectivity

With native support for Profibus DP, CANopen, and Modbus RTU protocols, the PS130/6-75-P integrates seamlessly with ABB’s AC800M DCS and third-party PLC systems. This enables real-time data exchange for predictive maintenance and remote diagnostics, reducing downtime by up to 30% compared to legacy systems.

Harsh Environment Resilience

Rated for -25°C to +65°C operation and 5 g vibration resistance, the module thrives in extreme conditions. Its IP54 protection class and conformal coating shield against dust, moisture, and chemical exposure, making it suitable for offshore platforms, mining sites, and high-corrosion environments.

Energy Efficiency

The PS130/6-75-P incorporates regenerative braking technology, converting kinetic energy back into usable power during deceleration. This feature reduces energy consumption by up to 20% in cyclic motion applications, such as conveyor systems and packaging machinery.

Application Areas

Robotics and Automation

Deployed in industrial robots (e.g., ABB IRB series) for pick-and-place operations, welding, and material handling. The PS130/6-75-P’s multi-axis synchronization capabilities enable complex robotic movements with sub-millisecond response times.

CNC Machining

Integrated into CNC milling and turning centers to control spindle motors and axis drives, ensuring high-precision machining of aerospace components and automotive parts.

Power Generation

Used in turbine control systems for speed regulation and load balancing, particularly in renewable energy installations (e.g., wind turbines) and thermal power plants.

Material Handling

Supports conveyor systems and automated guided vehicles (AGVs) in logistics warehouses, providing reliable torque control for heavy-load transport.

Related Products

Model Relationship/Use Case
PS130/6-120-P Higher-power variant (12.0 kW) for heavy-duty industrial applications.
PS60/4-75-P Lower-power variant (7.5 kW) for smaller-scale automation systems.
PM867AK01-eA Redundant CPU module for ABB AC800M systems, often paired for high-availability setups.
TB950-eA Redundancy terminator module enhancing failover speed and reliability.
S800 I/O System Complementary I/O platform for modular automation systems.

Installation and Maintenance

Installation Preparation:
Mount the ABB PS130/6-75-P on a rigid base using vibration-dampening mounts, ensuring 100 mm spacing for heat dissipation. Connect power inputs with 6 mm² shielded cables and terminate communication networks (Profibus/Modbus) with 120 Ω resistors. Use ABB’s RobotStudio software to configure motion profiles and encoder parameters.



Maintenance Recommendations:
Conduct quarterly visual inspections for dust accumulation or loose connections, particularly in high-vibration environments. Use RobotStudio to monitor real-time health metrics, including motor temperature and current consumption. Hot-swappable design allows component replacement without system shutdown; inspect conformal coating annually in corrosive environments and reapply as needed.

Product Assurance

ABB provides a 1-year warranty for the PS130/6-75-P, covering manufacturing defects and material failures. Customers benefit from ABB’s Global Service Network, offering 24/7 technical support, same-day spare parts dispatch for critical failures, and annual system health audits. The module undergoes rigorous testing for thermal cycling, vibration resistance, and electromagnetic compatibility to ensure compliance with international industrial standards.
