Description

Product Overview

The ABB PPD113B03-26-100110 3BHE023584R2634 is a high-reliability power distribution module designed for mission-critical industrial automation systems within ABB’s PPD (Power Distribution) series. Engineered to deliver stable 24 V DC power with advanced dual-input redundancy, this module ensures uninterrupted operation in demanding environments. The ABB PPD113B03-26-100110 3BHE023584R2634 integrates hot standby redundancy with real-time fault diagnostics, making it ideal for distributed control systems (DCS), robotic networks, and heavy manufacturing where power reliability is non-negotiable. Its rugged design and extended environmental tolerance enable deployment in harsh settings, from offshore oil platforms to high-vibration industrial plants.

Technical Specifications

Parameter Name	Parameter Value
Product Model	ABB PPD113B03-26-100110 3BHE023584R2634
Manufacturer	ABB
Product Type	Power Distribution Module (PPD Series)
Input Voltage	24 V DC (18–32 V DC wide-range input)
Output Voltage	24 V DC (regulated, ±0.5% tolerance)
Output Current	26 A (continuous), 35 A (peak for 20 seconds)
Redundancy Support	Dual-input hot standby redundancy (automatic failover ≤3 ms)
Power Efficiency	97% typical at full load
Operating Temperature	-35°C to +75°C (standard), -40°C to +85°C with derating
Safety Certification	CE, UL 60950-1, cUL, ATEX Zone 2, IEC 61558-2-16, SIL2 (IEC 61508)
Vibration Resistance	5–500 Hz, 7 g (IEC 60068-2-6)
Protection Class	IP20 (conformal coating standard, with optional IP65 front panel)
Dimensions	110 mm × 180 mm × 130 mm
Weight	1.5 kg
Monitoring Interfaces	2 × RS485 (Modbus RTU), 1 × Ethernet (Modbus TCP/IP), 1 × CANopen, LED indicators

Key Features and Advantages

Ultra-Fast Redundancy Management

The ABB PPD113B03-26-100110 3BHE023584R2634 features dual independent power inputs with hot standby redundancy, enabling failover times as low as 3 ms—critical for maintaining uninterrupted operation in emergency shutdown (ESD) networks or 24/7 production lines. This eliminates single points of failure and reduces the risk of costly downtime or safety incidents.

High-Efficiency Power Regulation

With 97% power efficiency at full load, this module sets new standards for energy savings, minimizing heat generation and reducing cooling requirements in control panels. The precision-regulated 24 V DC output (±0.5% tolerance) ensures stable power for sensitive industrial electronics, even during severe input voltage fluctuations, maintaining equipment performance and longevity.

Advanced Diagnostic Capabilities

Integrated real-time diagnostics monitor input voltage, output current, and internal temperature, triggering alarms via RS485/Ethernet/CANopen or LED indicators for faults like overloads, short circuits, or input failures. This proactive monitoring system reduces unplanned downtime by up to 60% through predictive maintenance and early fault detection.

Extreme Environment Ruggedness

Rated for -35°C to +75°C operation and 7 g vibration resistance, the PPD113B03-26-100110 thrives in the harshest industrial environments. Standard conformal coating and optional IP65 front panel protection shield against dust, moisture, and chemical exposure, making it suitable for offshore platforms, mining sites, and high-corrosion manufacturing plants.

Application Areas

Offshore & Subsea Operations

Deployed in offshore drilling platforms and subsea installations, the ABB PPD113B03-26-100110 3BHE023584R2634 ensures reliable power for wellhead control systems, pipeline monitoring, and emergency shutdown networks. Its ATEX certification and redundant design make it ideal for explosive atmospheres and remote locations with limited maintenance access.

Heavy Industrial Automation

Used in automotive, aerospace, and pharmaceutical manufacturing to power robotic arms, PLCs, and quality control systems, this module supports high-volume production lines with 24/7 reliability. The 26 A output capacity efficiently powers large I/O networks, while SIL2 compliance maintains safety-critical process integrity.

Renewable Energy & Smart Grid

Manages power distribution in solar farms, wind turbines, and microgrid systems, ensuring stable operation of control electronics in extreme climates. The module’s wide temperature range and high efficiency make it suitable for remote renewable energy sites and smart grid infrastructure requiring minimal maintenance.

Transportation Infrastructure

Orchestrates power for metro signaling systems, high-speed rail control networks, and traffic management systems. Its compact design and ruggedness suit both indoor control rooms and outdoor installations, ensuring reliable operation in harsh weather conditions.

Related Products

Model	Relationship/Use Case
PPD113B03-26-100100	Previous-generation variant (3BHE023584R2625), compatible for legacy systems.
PPD114B04-40-111000	Higher-current variant (40 A output) for large industrial power networks.
PPS240-24E1	240 W primary power supply module, ideal for redundant PPD113 setups.
PM867AK01-eA	Redundant CPU module for ABB AC800M systems, often paired with PPD113 modules.
TB950-eA	Redundancy terminator module, enhances failover speed and reliability.
PPD113B03-26-100120	Extended-temperature variant (-40°C to +85°C) for extreme industrial environments.

Installation and Maintenance

Installation Preparation

Mount the ABB PPD113B03-26-100110 3BHE023584R2634 on a DIN rail using quick-release clips, allowing 75 mm spacing for optimal heat dissipation. Connect dual power inputs with 4 mm² shielded cables, and terminate communication networks (RS485/Ethernet/CANopen) with 120 Ω resistors. Use ABB’s Power Manager software to configure fault thresholds, redundancy parameters, and real-time monitoring via Modbus protocols.

Maintenance Recommendations

Conduct monthly visual inspections for dust accumulation or loose connections, especially in high-vibration environments. Use ABB’s Power Manager to monitor real-time health metrics, including input voltage stability, output current trends, and internal temperature. Hot-swappable power modules allow component replacement without system shutdown. In harsh environments, inspect conformal coating bi-annually and reapply to maintain corrosion protection.

Product Assurance

ABB provides a 3-year warranty for the PPD113B03-26-100110 3BHE023584R2634, covering all manufacturing defects and material failures. Customers benefit from ABB’s Global Critical Support Network, offering 24/7 technical assistance, same-day spare parts dispatch for critical failures, and annual system health audits. The module undergoes rigorous testing for thermal cycling, vibration resistance, and electromagnetic compatibility to ensure compliance with the highest industrial and safety standards.
