Description

The ABB PP882 3BSE069275R1 is a 12.1-inch high-performance industrial HMI panel designed for advanced automation systems, offering superior visualization, robust connectivity, and rugged durability. As part of ABB’s Panel 800 Series (Version 6.2), it combines intuitive operation with cutting-edge technology, making it suitable for complex industrial environments. Below is a detailed analysis based on verified specifications and application insights:

Technical Specifications

Parameter Name	Parameter Value
Product Model	ABB PP882 3BSE069275R1
Manufacturer	ABB
Product Type	Industrial HMI Panel (Panel 800 Series)
Display	12.1-inch TFT-LCD with 1280 × 800 resolution (LED backlight, 50,000-hour lifespan)
Touch Technology	Resistive touchscreen (finger/stylus input, 1 million touch operations)
Processor	Intel Atom 1.1 GHz embedded processor
Memory	1 GB DDR2 RAM (for runtime operations)
Storage	1.4 GB internal SSD + microSD card slot (SDHC supported)
Communication Interfaces	2 × 10/100/1000 Ethernet (RJ45), 3 × USB 2.0, 2 × RS-232/422/485 serial ports
Power Supply	24 V DC (18–32 V DC wide-range input, 6.0 W typical consumption)
Operating Temperature	-10°C to +60°C (standard), -20°C to +70°C storage temperature
Safety Certification	CE, UL (UL 61010-2-201), CSA, IP65 front panel protection
Vibration Resistance	5–500 Hz, 0.7 g (IEC 60068-2-6)
Dimensions	340 mm × 242 mm × 79 mm (front panel), mounting depth 57 mm
Weight	3.11 kg
Protocol Support	Modbus RTU, Profibus DP, Ethernet/IP, OPC UA, ABB Symphony Plus integration

Key Features and Advantages

High-Resolution Visualization:
The 12.1-inch TFT-LCD display with 1280 × 800 resolution ensures clear visibility of complex process data, while the LED backlight provides consistent performance in low-light conditions. The resistive touchscreen supports gloved operation and stylus input, critical for harsh industrial environments 7.
Enhanced Processing Power:
Equipped with an Intel Atom 1.1 GHz processor, the PP882 delivers faster data processing and multitasking capabilities compared to earlier Panel 800 models (e.g., PP877 with ARM9 400 MHz). This makes it suitable for applications requiring real-time analytics and advanced HMI functionality 7.
Expanded Connectivity:
With dual Gigabit Ethernet ports, three USB 2.0 ports, and dual serial ports, the PP882 integrates seamlessly with ABB’s AC800M controllers and third-party PLCs. It supports OPC UA for secure data exchange with cloud-based systems, enabling Industry 4.0 applications 7.
Rugged Industrial Design:
The die-cast aluminum housing with IP65 front panel protection withstands dust, water, and high vibrations. Its extended operating temperature range (-10°C to +60°C) and conformal coating for moisture resistance make it suitable for outdoor or extreme industrial settings 7.
Scalable Configuration:
Configurable via ABB’s Panel Builder 6.2 software (compatible with Windows 7/10), the PP882 supports up to 4,000 tags and 4,000 alarm items. Its modular design allows phased expansions with additional I/O modules, ideal for large-scale automation systems 6.
Cost-Effective Performance:
Priced at $3,000–$5,000 (global market), the PP882 balances high-end performance with affordability. It is optimized for applications requiring advanced visualization and connectivity without the complexity of full-scale HMIs 7.

Application Areas

Manufacturing:
Monitoring conveyor systems, robotics, and quality control stations in discrete manufacturing.
Energy Management:
Supervising solar farms, wind turbines, and microgrid components with real-time data analytics.
Water/Wastewater:
Controlling large-scale pump stations, filtration units, and chemical dosing systems in centralized treatment plants.
Marine/Offshore:
Managing navigation systems, engine control, and environmental monitoring in maritime applications 1.

Installation and Compatibility

Mounting:
Panel-mount design with cutout dimensions of 324 mm × 226 mm. Supports VESA 75 × 75 mounting for wall or DIN rail installation 6.
Wiring:
Requires 24 V DC power and shielded cables for RS-422/USB connections. Redundant power inputs are available for critical applications.
Software Integration:
Configured using Panel Builder 6.2, which includes pre-built templates for alarm management, trending, and user access control. Supports integration with ABB’s 800xA System via OPC UA for advanced data analytics 2.
Compatibility:
Works with ABB’s S800 I/O modules and third-party devices via protocol gateways. Hot-swappable components simplify maintenance without system downtime.

Product Assurance

Warranty: 1–2 years (ABB standard), 365 days for replacement parts from third-party suppliers 1314.
Support: ABB’s global service network provides 24/7 technical assistance, firmware updates, and spare parts availability.
Delivery: Typically ships within 2–5 business days from stock (China suppliers), 5–10 days for U.S. distributors 7.

Pricing and Availability

Unit Price: $3,000–$5,000 (global market).
Redundant Kit: Includes dual panels and cables, priced at ~¥15,000.
Lead Time: 2–3 days for in-stock items; 4–6 weeks for custom configurations.

Comparison with Related Models

Model	Key Difference
PP877	10.4-inch display, lower resolution (640 × 480), ARM9 processor
PP881	10.1-inch display, 1024 × 600 resolution, ARM9 processor
PP882	12.1-inch display, 1280 × 800 resolution, Intel Atom processor
PP886R	15.4-inch ruggedized panel, certified for hazardous environments

Product Documentation

User Manual: Covers installation, configuration, and troubleshooting (Document ID: 3BSE069462-600 Rev D) 18.
Datasheet: Technical specifications and environmental ratings (Document ID: 3BSE069275R1) 21.
Application Notes: Guides for integrating with 800xA and Symphony Plus systems.

HS:7326909000
