Brand Model: ABB PP836 3BSE042237R1
Product Name: Industrial HMI Panel
Origin: Sweden
Inventory: In stock
Delivery Time: 2–7 days after payment

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

The ABB PP836 3BSE042237R1 is a 6.5-inch industrial HMI panel designed for compact automation systems, serving as a cost-effective human-machine interface for monitoring and controlling industrial processes. It belongs to ABB’s Panel 800 Series and is optimized for applications requiring intuitive operation in harsh environments. Below is a detailed overview based on verified specifications and application insights:

Technical Specifications

Parameter Name Parameter Value
Product Model ABB PP836 3BSE042237R1
Manufacturer ABB
Product Type Industrial HMI Panel (Panel 800 Series)
Display 6.5-inch TFT-LCD with 640 × 480 resolution (LED backlight, 50,000-hour lifespan)
Touch Technology Resistive touchscreen (finger/stylus input)
Processor Embedded 32-bit RISC processor (similar to Intel Atom N270 in PP836A variant)
Memory 64 MB DRAM (for runtime operations)
Communication Interfaces 1 × RS-422 serial port, 1 × USB 2.0 (for diagnostics/configurations)
Power Supply 24 V DC (19.2–30 V DC wide-range input, 5 W typical consumption)
Operating Temperature 0°C to +50°C (standard), -20°C to +70°C storage temperature
Safety Certification CE, UL (UL 61010-2-201), CSA (non-hazardous locations), IP66/IP65 front panel protection
Vibration Resistance 5–500 Hz, 0.2 g (IEC 60068-2-6)
Dimensions 202 mm × 152 mm × 6 mm (front panel), mounting depth 57 mm
Weight 0.9 kg
Protocol Support Modbus RTU, Profibus DP, ABB Symphony Plus integration

Key Features and Advantages

  1. Compact Rugged Design:
    The die-cast aluminum housing with IP66/IP65 front panel protection ensures durability in dusty, wet, or high-vibration environments. It supports extended temperature ranges (-20°C to +70°C) and conformal coating for moisture resistance .
  2. Intuitive User Interface:
    The 6.5-inch TFT display offers clear visibility in low-light conditions, while the resistive touchscreen enables precise control with gloves or stylus. The Panel Builder software provides a Windows-based environment for developing multi-language interfaces and customizing process visualizations .
  3. Flexible Connectivity:
    Equipped with RS-422 and USB ports, the PP836 integrates seamlessly with ABB’s AC800M controllers and third-party PLCs. It supports Modbus RTU and Profibus DP for data exchange with field devices and SCADA systems. Optional Ethernet connectivity is available in the PP836A variant (3BSE042237R2) 11.
  4. Scalable Configuration:
    Configurable via ABB’s Panel Builder tool, the PP836 supports up to 1,000 tags and 150 alarm items, making it suitable for small to medium-sized automation systems. Its modular design allows phased expansions with additional I/O modules .
  5. Cost-Effective Performance:
    Priced at $715–$2,176 (China market), the PP836 offers a balance between functionality and affordability. It is ideal for applications where full-scale HMIs are unnecessary but reliable local control is required 6.

Application Areas

  • Manufacturing:
    Monitoring conveyor systems, packaging machines, and quality control stations in discrete manufacturing.
  • Energy Management:
    Supervising solar inverters, small-scale wind turbines, and microgrid components.
  • Water/Wastewater:
    Controlling pump stations, filtration units, and chemical dosing systems in decentralized treatment plants.
  • Transportation:
    Managing traffic lights, tunnel ventilation, and access control in smart city infrastructure .

Installation and Compatibility

  • Mounting:
    Panel-mount design with cutout dimensions of 182 mm × 142 mm. Supports DIN rail or wall mounting with optional brackets.
  • Wiring:
    Requires 24 V DC power and shielded cables for RS-422/USB connections. Redundant power inputs are available for critical applications.
  • Software Integration:
    Configured using Panel Builder (compatible with Windows 7/10), which includes pre-built templates for alarm management, trending, and user access control. Supports integration with ABB’s 800xA System via OPC UA .
  • Compatibility:
    Works with ABB’s S800 I/O modules and third-party devices via protocol gateways. Hot-swappable components simplify maintenance without system downtime.

Product Assurance

  • Warranty: 1–2 years (varies by supplier).
  • Support: ABB’s global service network provides 24/7 technical assistance, firmware updates, and spare parts availability.
  • Delivery: Typically ships within 2–5 business days from stock (China suppliers), 5–10 days for U.S. distributors 6.

Pricing and Availability

  • Unit Price: $715–$2,176 (China market), $999–$2,500 (U.S. market).
  • Redundant Kit: Includes dual panels and cables, priced at ~¥6,999.
  • Lead Time: 2–3 days for in-stock items; 4–6 weeks for custom configurations.

Comparison with Related Models

Model Key Difference
PP825 12-inch TFT display, higher resolution (800 × 600), Intel Celeron M processor
PP825A 5.7-inch CSTN display, lower cost, fewer protocol options
PP836A 10.4-inch display, multi-touch support, Ethernet connectivity (3BSE042237R2)

Product Documentation

  • User Manual: Covers installation, configuration, and troubleshooting (Document ID: 3BSE049346R301).
  • Datasheet: Technical specifications and environmental ratings.
  • Application Notes: Guides for integrating with 800xA and Symphony Plus systems.



HS:7326909000
