ABB PM866 3BSE050200R1 AC800M Series CPU Module(XIONGBA)

ABB PM866 3BSE050200R1 AC800M Series CPU Module(XIONGBA)

Brand Model: ABB PM866 3BSE050200R1
Product Name: AC800M CPU Module
Weight: 1.2 kg
Origin: Sweden
Inventory: In stock
Delivery Time: 3–7 days after payment

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

The ABB PM866 3BSE050200R1 is a high-performance CPU module designed for industrial automation within ABB’s AC800M series. Built on a robust architecture, it offers advanced control capabilities and scalability for applications requiring reliable real-time processing. Below is a detailed overview based on verified specifications and application insights:

Technical Specifications

Parameter Name Parameter Value
Product Model ABB PM866 3BSE050200R1
Manufacturer ABB
Product Type AC800M Series CPU Module (General Industrial Control)
Processor MPC866, 133 MHz (32-bit RISC with error detection)
Memory 64 MB RAM (51.389 MB application space), 4 MB flash for firmware storage
Communication Interfaces 2 x RJ45 Ethernet (10 Mbit/s), 2 x RS-232C (COM3 with modem control)
Redundancy Support Hot standby redundancy (switchover ≤10 ms), dual power inputs
Power Supply 24 V DC (19.2–30 V DC wide-range input, 5.1 W typical consumption)
Operating Temperature +5°C to +55°C (standard), -20°C to +60°C with optional extended environment kit
Safety Certification ATEX Zone 2 (UL 60079-15), CE, UL, IEC 61131-2
Vibration Resistance 5–500 Hz, 0.2 g (IEC 60068-2-6)
Protection Class IP20 (conformal coating available for moisture resistance)
Dimensions 119 mm × 186 mm × 135 mm (4.7″ × 7.3″ × 5.3″)
Weight 1.2 kg (2.65 lbs)
Protocol Support MMS, IAC, Modbus TCP, Profibus DP (via optional communication modules)

Main Features and Advantages

  1. High-Speed Processing:
    The MPC866 processor enables rapid execution of complex control algorithms, with a performance of 0.09 ms per 1,000 boolean operations 15. This makes it suitable for applications requiring real-time data processing, such as manufacturing automation and energy management.
  2. Redundancy for High Availability:
    Supports hot-swappable CPU redundancy, ensuring seamless switchover within ≤10 ms to maintain system uptime 15. Redundant power inputs and communication interfaces further enhance reliability in critical environments.
  3. Flexible Communication:
    Equipped with dual Ethernet ports and RS-232C interfaces, the module supports integration with industrial networks (e.g., Modbus TCP, Profibus DP via optional CI867-eA modules) and third-party systems 1215. IEEE 1588 time synchronization ensures accurate coordination across distributed systems.
  4. Scalable Design:
    Compatible with the full range of S800 I/O modules and ABB’s 800xA system, allowing phased expansions and integration with existing infrastructure 1215. Its modular architecture reduces total cost of ownership.
  5. Rugged Reliability:
    Withstand harsh industrial conditions (vibration up to 0.2 g, wide temperature range) and optional conformal coating for dust/moisture protection 1215. ATEX certification permits use in explosive atmospheres (Zone 2).

Application Areas

  • Industrial Automation: Deployed in manufacturing lines for robotics, packaging, and material handling, leveraging high-speed processing and redundancy.
  • Energy Management: Used in power plants and renewable energy systems for grid integration, turbine control, and energy storage management.
  • Process Industries: Applied in chemical and pharmaceutical facilities for batch control and quality monitoring, ensuring compliance with industrial standards.
  • Transportation and Infrastructure: Manages metro systems, water treatment plants, and wastewater processes, offering compact design and easy DIN rail mounting.

Related Products

  1. PM866AK02: Redundant CPU kit with dual processors and extended communication capabilities.
  2. S800 I/O-eA Series: Extended-environment I/O modules (e.g., AI830-eA, DI830-eA) for harsh conditions.
  3. CI867-eA: Profibus communication module for high-reliability networks.
  4. TP830-eA: Enhanced baseplate with improved heat dissipation.
  5. 800xA System: Integrated automation software for configuration and monitoring.

Installation and Maintenance

  • Installation: Mount on a TP830 baseplate using DIN rail clips, ensuring secure grounding. For redundancy, connect TB852-eA terminators and configure dual Ethernet links 1215.
  • Maintenance: Quarterly inspections for dust accumulation; replace internal battery (4943013-6) annually. Use ABB’s Remote Diagnostics Tool for proactive monitoring of CPU health and firmware updates.

Product Assurance

  • Warranty: 1 year (defects in materials/workmanship).
  • Support: ABB’s global service network provides 24/7 technical assistance, including remote troubleshooting for complex configurations.
  • Delivery: Spot inventory available; typically ships within 3–7 business days 1516.



HS:7326909000
