Description
Product Overview
The ABB PM864AK02 is a high-performance processor module belonging to ABB’s AC 800M controller series, designed for demanding industrial automation systems. As a key component of the Control Building Block (CBB), this module serves as the central processing unit, enabling real-time control, data processing, and communication within distributed control systems (DCS). The PM864AK02 stands out for its robust architecture, supporting advanced control algorithms and seamless integration with other ABB automation components. It features enhanced processing power, ensuring rapid response to complex control tasks, and is compatible with a wide range of I/O modules and communication protocols. This module is ideal for critical applications requiring high reliability, such as process industries, power generation, and manufacturing, where continuous operation and precise control are essential. The PM864AK02 embodies ABB’s commitment to delivering innovative solutions that optimize system efficiency and operational stability.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PM864AK02 |
| Manufacturer | ABB |
| Product Type | Processor Module (AC 800M Series) |
| Processor Type | 32-bit RISC CPU |
| Memory Configuration | RAM: 512 MB, Flash: 1 GB |
| Communication Interfaces | Ethernet (10/100 Mbps), Serial Ports (RS-232/485), USB |
| Supported Protocols | Modbus, Profibus, CANopen, EtherNet/IP |
| Power Supply | 24 V DC (±10%) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W×H×D) | 100 mm × 200 mm × 80 mm |
| Weight | Approximately 0.8 kg |
| Certification | CE, UL, CSA |
Main Features and Advantages
The PM864AK02 offers several key features that enhance its performance in industrial automation setups. Its high-speed processing capability allows for real-time control of complex processes, ensuring minimal latency and precise regulation. The module supports hot-swapping, enabling maintenance or replacement without system shutdown, which significantly improves operational availability. With built-in redundancy options, it can be configured in dual-processor setups to minimize downtime in critical applications. The PM864AK02 also features advanced diagnostics, providing real-time status monitoring and error reporting to facilitate quick troubleshooting. Its flexible programming environment supports multiple IEC 61131-3 languages, making it adaptable to various control strategies. Additionally, the module’s rugged design ensures reliability in harsh industrial environments, with resistance to vibration, electromagnetic interference, and temperature fluctuations. This combination of performance, durability, and ease of integration makes the PM864AK02 a preferred choice for demanding automation projects.
Application Areas
The PM864AK02 is widely applicable across industries that require sophisticated control systems. In the oil and gas sector, it is used for supervisory control of refineries, pipelines, and offshore platforms, ensuring safe and efficient operations. In power generation, the module manages boiler control, turbine regulation, and grid integration for both conventional and renewable energy plants. Within the chemical and pharmaceutical industries, it enables precise process control for batch operations and quality management. The PM864AK02 also finds use in manufacturing automation, such as automotive production lines, where it coordinates robotic systems and ensures consistent product quality. Its compatibility with diverse communication protocols makes it suitable for retrofitting into existing systems or deploying in new smart factory setups. Whether in large-scale industrial complexes or small-to-medium applications, this processor module delivers the reliability and performance needed to optimize process efficiency and system stability.
Related Products
- ABB PM860K01: An earlier generation processor module in the AC 800M series, suitable for basic control tasks with lower processing demands.
- ABB PM861AK01: A mid-range processor module with enhanced memory and communication capabilities, ideal for medium-sized systems.
- ABB PM866AK01: A high-end variant of the series, designed for complex applications requiring maximum processing power and redundancy.
- ABB PM891: A next-generation processor module offering advanced cybersecurity features and compatibility with IoT integration.
- ABB DI810: Digital input module that pairs with the PM864AK02 to receive sensor signals in automation systems.
- ABB DO810: Digital output module for controlling actuators and relays, complementing the processor’s control functions.
- ABB AI810: Analog input module for converting continuous signals from transmitters to digital data for the processor.
- ABB AC800M Controller Chassis: The physical framework that houses the PM864AK02 and other modules, ensuring proper installation and connectivity.
Installation and Maintenance
Installation 前准备: Before installing the PM864AK02, ensure the control chassis is powered off and properly grounded. Verify that the chassis model is compatible with the AC 800M series and that all necessary mounting hardware is available. Clean the installation area to prevent dust or debris from affecting module performance, and ensure the environment meets the specified temperature and humidity requirements.
Maintenance 建议: Regular maintenance of the PM864AK02 includes periodic visual inspections for physical damage or loose connections. Use a dry, static-free cloth to clean the module’s exterior. Monitor the module’s diagnostic indicators to detect any 异常 (abnormalities) early, such as unusual error lights or performance degradation. For software maintenance, keep the firmware updated to the latest version provided by ABB to leverage new features and security patches. In the event of a fault, refer to the module’s troubleshooting guide to identify and resolve issues promptly, and consider having a spare module on hand to minimize downtime during replacements.
Product Guarantee
ABB stands behind the PM864AK02 with a comprehensive quality guarantee. The product undergoes rigorous testing to ensure compliance with industry standards for reliability and performance. Customers can expect a 1-year warranty covering defects in materials and workmanship, along with access to ABB’s global technical support network. ABB’s service team provides timely assistance for installation, configuration, and troubleshooting, ensuring minimal disruption to operations. For long-term support, ABB offers maintenance plans and firmware updates to keep the PM864AK02 optimized throughout its lifecycle, reflecting the company’s commitment to delivering sustainable and dependable automation solutions.
Brand model: ABB PM864AK02
Product Name: Processor Module
Warranty: 1 year
Size: 100 mm × 200 mm × 80 mm
Weight: Approximately 0.8 kg
Origin: Sweden
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
Product Name: Processor Module
Warranty: 1 year
Size: 100 mm × 200 mm × 80 mm
Weight: Approximately 0.8 kg
Origin: Sweden
Inventory: Spot/Futures
Delivery time: Goods in stock will be dispatched within 3 days after payment
Order time: Goods will be dispatched within one month after payment
