Description
. Many products are not yet available. Please contact us to learn more about them
. In case of any inconsistency between the product model and the displayed picture, the model shall prevail. For specific product pictures, please contact us and we will take photos of the goods for confirmation
. We share multiple warehouses around the world, so please understand that it may take several hours to accurately return it to you. Of course, we will respond to your concerns as soon as possible
- Model: ABB 3BSE081636R1 (PM862K02)
- Brand: ABB (Switzerland-Sweden)
- Series: AC 800M High-Performance Controller Series
- Core Function: Redundant process control CPU for critical DCS applications. Condition: New Surplus, not refurbished.
- Type: Controller Module (CPU)
- Key Specs: 2x Ethernet Ports (CN1, CN2) | Redundancy Supported | ControlIT/Firmware V5.x Compatible
The ABB PM862K02 (3BSE081636R1) serves as the central processing unit for the AC 800M series, designed specifically for high-availability redundant control systems in demanding industrial environments. This controller manages complex logic execution and communication across distributed I/O networks, making it a staple in power generation and oil refining sectors.Unlike standard single CPUs, the PM862K02 features dual Ethernet ports and specialized firmware support for seamless switchover during primary module failures. Its architecture minimizes process disruption, offering a reliable solution for plants where even milliseconds of downtime result in significant production losses. We stock verified surplus units to bridge the gap between discontinued manufacturing lines and new procurement lead times.
Key Technical Specifications
| Parameter Name | Specification Value |
|---|---|
| Part Number | 3BSE081636R1 |
| Product Type | PM862K02 Processor Module |
| Processor Speed | 32-bit RISC, 66 MHz |
| Memory Capacity | 32 MB RAM (User Memory) |
| Communication Ports | 2 x Ethernet (10/100 Mbps), 2 x Serial (RS-232/485) |
| Redundancy Support | Yes (High Availability configuration) |
| Supported Protocols | Modbus TCP, OPC, ControlIT, FTP |
| Power Consumption | Approx. 12 W (at 5 V DC) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Certification | CE, UL, CSA, Ex (Zone 2) |
Recommended Spares & Stocking Advice
As a Spare Parts Inventory Manager, I classify the ABB PM862K02 as an A-Class Critical Item due to its role as the system brain and the increasing lead time variability from original manufacturers. Here is my strategic recommendation for your inventory:
- Primary Controller (PM862K02):
- Recommended Qty: 1–2 units per site (Buffer stock).
- Purchasing Notes: Treat this as an insurance policy. Do not wait for a failure to source. Given the lifecycle stage of the AC 800M series, prioritize “New Surplus” with verified firmware versions over refurbished units to avoid early-life failures.
- Est. Lead Time: 4–10 weeks for new orders; immediate availability for verified surplus stock.
- Redundant Sync Cable & Termination Units:
- Recommended Qty: 2 sets.
- Purchasing Notes: Often overlooked. If the sync cable fails, redundancy is lost even if the CPU works. Keep these as consumable spares.
- Est. Lead Time: 2–4 weeks.
- Compact Flash Memory Card (if applicable for logging):
- Recommended Qty: 1 unit.
- Purchasing Notes: Ensure compatibility with the specific firmware revision running on your plant floor. Mismatched card types can cause boot loops.
- Est. Lead Time: 1–2 weeks.
Strategic Insight: For facilities running older ControlIT versions, execute a Last-Time-Buy analysis immediately. Vendor consolidation agreements often fail to cover obsolete firmware dependencies. I recommend cross-site sharing protocols if you operate multiple plants; pooling two units for three sites reduces carrying costs while maintaining coverage for catastrophic failures. Always verify the firmware version (e.g., V5.0.2 vs V5.1.0) before deployment to prevent communication timeouts with existing I/O modules.
