Complete Overview of ABB PFEA113-65 3BSE028144R0065 Tension Control Module
Product Overview
In harsh industrial environments with dust, moisture and liquid splashing, stable and reliable high-precision tension control places dual demands on the protection and performance of the controller. The PFEA113-65 3BSE028144R0065, a high-performance industrial tension control module from ABB’s Pressductor® series, is a premium control unit built for these demanding conditions.
As a flagship control node on ABB’s tension electronics platform, it integrates mature closed-loop control algorithms and powerful signal processing capabilities. It supports direct connection of 4 load cells, and up to 12 sensors via cascade expansion, providing a one-stop tension monitoring and control solution for complex modern production lines with multiple measuring points.
Backed by more than 70 years of ABB’s industrial automation expertise, this module features an IP65 sealed design that effectively resists dust, moisture and liquid spraying, ensuring stable operation even in rough workshop environments. It integrates Profibus‑DP, RS‑485, Modbus TCP and other industrial bus protocols, and can connect seamlessly to mainstream automation platforms such as ABB 800xA, Siemens SIMATIC and Rockwell ControlLogix for easy remote monitoring and data exchange.
In high-speed continuous production scenarios such as printing, film and metal processing, the PFEA113-65 maintains precise and stable tension control, avoiding common defects such as breakage, wrinkling and slack at the source, providing solid assurance for efficient and stable operation of modern industrial lines.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PFEA113-65 3BSE028144R0065 |
| Manufacturer | ABB (Switzerland) |
| Product Type | Industrial Tension Control Module |
| Input Channels | 4 load cell inputs (expandable to 12 via cascade) |
| Output Signals | 6 configurable analog outputs (0‑10V DC, 4‑20mA) |
| Power Supply | 24 V DC (operating range 18‑36V) |
| Power Consumption | 7.5 W |
| Measurement Accuracy | ±0.1% full scale |
| Response Time | <10 ms |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP65 (dustproof, splash-proof) |
| Communication Protocols | Profibus‑DP, RS‑485, Modbus TCP |
| Display Unit | 2×16 character multilingual display |
| Dimensions | 180mm × 120mm × 100mm |
| Weight | 1.9 kg |
| Installation | Wall-mounted or DIN rail mounting |
Key Features and Advantages
The core competitiveness of the PFEA113-65 lies in its high-precision measurement and fast-response control. It uses 16-bit ADC acquisition and advanced digital filtering algorithms, achieving a measurement accuracy of ±0.1% full scale and a response time of less than 10 milliseconds, keeping pace with high-speed production lines.
The module comes with a 2×16 multilingual display that shows real-time values of channels A, B, their sum and difference. Operators can monitor tension status and adjust key parameters directly without relying on a host computer. It features intelligent modes including constant tension, speed-synchronized tension and taper control, enabling automatic dynamic compensation during press acceleration or film roll changes, reducing material waste by more than 15% in practical applications.
Multi-protocol compatibility and strong expandability allow it to adapt easily to various complex systems. Full support for Profibus‑DP, Modbus TCP and other mainstream protocols minimizes cross-brand integration barriers and greatly reduces integration difficulty and cost. The module supports cascade connection of three units, accommodating up to 12 tension sensors, fully meeting the requirements of multi-point and multi-zone synchronous control on large production lines.
Reliability in harsh environments is another outstanding advantage. The IP65 fully sealed structure is designed for dusty, humid and sprayed industrial sites. The built-in self-diagnosis system monitors signal abnormalities, overloads, communication interruptions and other faults in real time, with alarms via 4 programmable digital outputs. All diagnostic data is uploaded to the bus for true predictive maintenance, effectively cutting unplanned downtime. The dual wall/DIN rail mounting method also allows flexible installation in space-limited cabinets or on-site locations.
Application Areas
The PFEA113-65 is widely and maturely applied in the printing and packaging industry, especially for high-speed gravure presses, flexographic presses and laminators.
On high-speed printing lines, it monitors film and paper tension in real time and dynamically adjusts unwinding and rewinding tension via closed-loop control, limiting register deviation to within ±0.1mm. After adoption by a large packaging enterprise, film tension fluctuation was stabilized within ±0.5%, production efficiency increased by more than 12%, and material waste was significantly reduced.
The textile dyeing and finishing industry is another major application. In yarn unwinding, weaving and dyeing processes, it precisely controls yarn tension and avoids breakage and increased hairiness. Used by a high-end textile company, yarn tension fluctuation was controlled within ±1%, greatly improving fabric first-pass yield and product consistency. On non-woven fabric lines, the module connects multiple sensors and communicates with PLC via Profibus‑DP for multi-station synchronous coordinated control.
It is also widely used in cable manufacturing and metal processing, ensuring uniform structure and qualified electrical performance in copper wire winding, cable stranding and metal strip rolling, effectively solving industry problems such as wire embedding and loose winding. In new material processing such as lithium battery electrode slitting and special film stretching, its high-precision control helps enterprises achieve breakthroughs in both quality and efficiency.
Related Products
PFEA113-20: Standard protection version, IP20, for inside control cabinets
PFEA112-65: Mid-range tension control module with 2 sensor inputs, for moderately complex scenarios
PFEA111-65: Basic tension controller with 2 inputs, for cost-sensitive applications
PFEA113-20 3BSE028144R20: Standard protection model, different part number, same functions
PFCL201C-10kN: Pillow-block magnetoelastic tension sensor, provides measurement signals for this module
PFTL101B-5.0kN: Horizontal load cell, 5kN range, for horizontal tension measurement
PFCA401: Advanced tension control unit with richer functions, for ultra-complex multi-sensor systems
PXUB 201: Isolation amplifier accessory for isolated analog output applications
PXKB 201: Relay board, DIN rail mounted, used with isolation amplifier
SD821/822/823: DC power supply modules, provide stable power for PFEA113-65
Installation and Maintenance
Pre-installation Preparation
Before installing the PFEA113-65, carefully read the product manual and safety specifications, and confirm that the on-site temperature, humidity and electromagnetic environment meet operational requirements. Prepare corresponding tools and cables, inspect the module for intact appearance and undamaged seals.
Avoid mounting near high-temperature sources, strong vibration and electromagnetic interference, and reserve sufficient space for heat dissipation and later maintenance.
Maintenance Recommendations
The PFEA113-65 uses a high-reliability industrial design and requires no complicated routine maintenance, but regular inspections further extend service life and ensure stable operation.
Inspect module status every 6 months using panel indicators and diagnostic software. Clean surface dust, maintain clear ventilation, and check cable and terminal tightness. Increase inspection frequency in dusty, corrosive environments to ensure intact sealing.
If control accuracy drops or communication abnormalities occur, troubleshoot with ABB official diagnostic tools first, and contact authorized service for professional calibration and repair if needed.
Product Warranty
ABB provides comprehensive quality assurance and global after-sales support for the PFEA113-65 3BSE028144R0065. All units undergo strict quality inspection and condition testing, complying with ABB’s global unified quality standards for long-term stable operation in harsh industrial environments.
The module carries a 12-month official warranty. ABB provides free repair and replacement for failures caused by material or workmanship defects during the warranty period. The professional technical team offers full-process support including installation, integration and fault diagnosis to ensure optimal equipment performance.
ABB also provides users with ongoing software updates, technical training and long-term spare parts supply. Its global service network ensures fast professional support for users worldwide. Choosing the PFEA113-65 means not only a high-performance tension control module, but also the solid backing of ABB’s 70+ years of industrial automation expertise and continuous technological innovation.
