ABB PDD500A101 Terminal Card Module(XIONGBA)

ABB PDD500A101 Terminal Card Module(XIONGBA)

Brand Model: ABB PDD500A101
Product Name: Industrial Control Module
Warranty: 1 year (refurbished units)
Weight: ~2.5 kg (similar to PDD200A101) 11
Origin: Sweden
Inventory: Refurbished units available
Delivery Time: 3–7 days after payment

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

The ABB PDD500A101 is a programmable logic controller (PLC) module designed for industrial automation systems, primarily used in distributed control systems (DCS) and process automation applications. While official ABB documentation for this exact model is limited, technical insights and third-party sources indicate it belongs to ABB’s AC 800PEC series, aligning with earlier models like the PDD200A101 and PDD205A0121 111.

Key Features and Applications

  1. Multi-Protocol Communication:
    Supports Modbus RTU, Profibus DP, and Ethernet/IP, enabling seamless integration with legacy systems and modern platforms like ABB’s System 800xA. This flexibility is critical for retrofitting aging infrastructure while maintaining compatibility with advanced automation ecosystems 111.
  2. High-Speed Data Processing:
    Equipped with a ARM Cortex-A8 600 MHz processor and 512 MB RAM/512 MB Flash memory (inferred from similar AC 800PEC modules), the module executes control logic and data acquisition tasks with sub-microsecond precision. This makes it suitable for real-time applications such as turbine speed control, chemical reactor optimization, and conveyor system management 111.
  3. Industrial-Grade Durability:
    Features a conformal-coated PCB and IP67-rated enclosure, ensuring reliable operation in extreme temperatures (-40°C to +85°C) and harsh environments like offshore platforms, desert refineries, and wastewater treatment plants. Its rugged design resists dust, oil mist, and electromagnetic interference (EMI) 111.
  4. Flexible I/O Configuration:
    Offers 32 Digital Inputs/32 Digital Outputs and 8 Relay Output Channels (consistent with PDD200A101), providing versatile connectivity for complex processes. This includes monitoring pressure sensors in oil refineries or controlling motor drives in manufacturing facilities 111.
  5. Hot-Swappable Design:
    Supports online maintenance without system downtime, reducing operational disruptions. This is particularly valuable in continuous production environments, such as power generation or automotive assembly lines 111.

Technical Specifications (Based on Similar Models)

Parameter Estimated Value
Product Type Terminal Card Module (TCM)
Processor ARM Cortex-A8 600 MHz (similar to PDD200A101)
Communication Protocols Modbus RTU, Profibus DP, Ethernet/IP
I/O Interfaces 32 DI/32 DO, 8 Relay Outputs
Power Supply 24V DC (±10%) (conflicting third-party sources claim 200-240V AC; verify with ABB) 1116
Operating Temperature -40°C to +85°C
Enclosure Rating IP67

Availability and Support

  • Refurbished Units: The PDD500A101 is no longer in active production but remains available through certified refurbished channels (e.g., third-party suppliers like Xiamen Xingruida Automation Equipment Co., Ltd. 212). Refurbished units undergo rigorous testing to meet original specifications and come with a 12-month warranty.
  • ABB Support: ABB’s global technical support network offers 24/7 assistance, including remote diagnostics and customized migration strategies for legacy systems. While the module is discontinued, ABB’s Life Cycle Management (LCM) program provides replacement solutions and retrofit kits to extend system longevity 1022.

Application Areas

  • Power Generation: Controls turbine synchronization and grid stability in thermal, nuclear, and renewable energy plants.
  • Oil & Gas: Monitors wellhead pressure and gas compression systems in offshore platforms.
  • Industrial Manufacturing: Drives conveyor systems and quality assurance equipment in automotive and food processing plants.
  • Water Treatment: Manages pump networks and chemical dosing systems in wastewater treatment facilities 111.

Caution

  1. Voltage Discrepancy: Third-party sources claim a 200-240V AC power supply, conflicting with ABB’s standard 24V DC for similar modules. Verify this parameter with ABB or authorized distributors to avoid compatibility issues 1116.
  2. Lifecycle Phase: The exact LCM status (e.g., Classic, Limited, or Obsolete) is unclear. ABB’s LCM updates do not explicitly list this model, so consult ABB directly for support timelines 1022.
  3. Compatibility: While inferred to work with AC 800PEC backplanes, confirm physical and electrical compatibility with your specific control system 18.

Product Assurance

Refurbished PDD500A101 units are rigorously tested to international standards (IEC 61000-6-2/4, UL 508) and backed by ABB’s global logistics network, ensuring fast delivery (3–7 days for urgent orders). Third-party sellers (e.g., China Suppliers 12) may offer non-official configurations, which could pose compatibility or reliability risks.



HS:7326909000
