Description
Product Overview
The ABB NTMP01 is a Multi-Function Processor Termination Unit designed for ABB’s Bailey INFI 90 and Symphony Harmony distributed control systems (DCS). Serving as a critical interface between Multi-Function Processors (MFPs) and field devices, the ABB NTMP01 enables seamless integration of analog/digital signals while delivering advanced signal conditioning, isolation, and diagnostic capabilities. With support for 4 analog inputs (4–20 mA DC), 4 analog outputs (1–5 V DC/4–20 mA DC), and two RS-232-C serial ports (one configurable as RS-485), this termination unit is ideal for applications requiring reliable connectivity in industrial automation environments 111.
Engineered with a modular design, the ABB NTMP01 supports compatibility with ABB’s IMMFP01/02/031 Multi-Function Processors and IICT03 Infi-Net to Computer Transfer Modules, allowing flexible expansion of communication and control capabilities. Its rugged IP20-rated enclosure with conformal coating ensures operation in harsh conditions, including extreme temperatures (-40°C to +70°C) and high electromagnetic interference (EMI) 614. By providing surge protection, signal filtering, and galvanic isolation, the ABB NTMP01 ensures accurate data transmission to DCS controllers, enhancing system stability and reducing downtime in mission-critical processes.
As part of ABB’s industrial automation portfolio, the ABB NTMP01 plays a pivotal role in modernizing control systems by enabling real-time monitoring and precise control of field devices. Its DIN rail mounting and hot-swappable design streamline installation and maintenance, making it a cost-effective solution for power generation, oil & gas, water treatment, and manufacturing sectors. With global technical support and a 12-month warranty, the ABB NTMP01 combines cutting-edge technology with ABB’s renowned reliability to meet the demands of industrial automation 311.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB NTMP01 |
| Manufacturer | ABB |
| Product Type | Multi-Function Processor Termination Unit |
| Input Channels | 4 analog (4–20 mA DC) |
| Output Channels | 4 analog (1–5 V DC/4–20 mA DC) |
| Communication Ports | 2 RS-232-C (1 configurable as RS-485) |
| Power Supply | 24 V DC ±10% (via DC/DC converter) |
| Physical Dimensions | 213.36 mm (W) × 233.68 mm (H) × 73.66 mm (D) 11 |
| Weight | 0.3 kg |
| Operating Temperature | -40°C to +70°C 6 |
| Humidity | 0–95% non-condensing |
| Mounting | 35 mm DIN rail or rack-mountable |
| Certifications | CE, UL 508, IEC 61131-2 (EMC) |
| Signal Isolation | 2500 V DC galvanic isolation |
Key Features and Advantages
Flexible Communication Architecture: The ABB NTMP01 provides two RS-232-C serial ports (one configurable as RS-485), supporting Modbus RTU and Profibus DP protocols for seamless integration with third-party devices like HMIs, printers, and sequential event recorders. This versatility allows hybrid control system configurations in legacy and modernized environments 614.
Rugged Industrial Design: Built with an IP20-rated enclosure and conformal coating, the ABB NTMP01 withstands dust, moisture, and EMI in harsh industrial environments. Its extended temperature range (-40°C to +70°C) makes it suitable for outdoor installations and high-temperature applications like power plants and chemical processing facilities 611.
Enhanced Reliability: The unit includes galvanic isolation and surge protection to prevent ground loops and electrical noise, ensuring stable data transmission. Diagnostic LEDs provide real-time status monitoring, allowing quick identification of signal loss, overrange conditions, or module faults 1416.
Modular System Integration: Compatible with ABB’s IMMFP01/02/031 Multi-Function Processors and IICT03 Infi-Net modules, the ABB NTMP01 seamlessly integrates with INFI 90 and Symphony Harmony systems. It also supports direct connection to II SAC 01 Analog Control Stations and NDCS 03 Digital Control Stations, enabling centralized process monitoring and control 1415.
Ease of Maintenance: Hot-swappable modules and screw-terminal connections simplify field wiring and replacement, minimizing downtime. The unit’s DIN rail mounting and compact design optimize space in control panels, while ABB’s Control Builder M software facilitates remote configuration and firmware updates 611.
Application Areas
Power Generation: The ABB NTMP01 monitors critical parameters in thermal power plants, such as steam turbine temperatures via thermocouples and boiler pressure/flow rates using 4–20 mA signals. Its redundancy support ensures reliable operation in emergency shutdown systems 1215.
Oil & Gas: In offshore platforms and refineries, the ABB NTMP01 processes analog outputs from smart transmitters to track wellhead conditions and manage pump motor currents. Its rugged design ensures durability in corrosive and high-vibration environments 1216.
Water Treatment: The unit converts pH sensor signals (1–5 V DC) to standardized 4–20 mA outputs for centralized SCADA monitoring. It also manages pump motor current measurements to optimize energy efficiency and detect equipment faults 715.
Manufacturing: In semiconductor and food processing plants, the ABB NTMP01 connects RTDs and vibration sensors to DCS controllers, enabling precise temperature profiling and predictive maintenance. Its digital outputs drive actuators and relays in automated production lines 1216.
Related Products
- IMMFP01/02/031: Multi-Function Processors directly compatible with the ABB NTMP01 for advanced control logic and data processing 14.
- IICT03: Infi-Net to Computer Transfer Module for integrating the ABB NTMP01 with legacy systems via Ethernet 14.
- II SAC 01: Analog Control Station for centralized process monitoring and control, supported by the ABB NTMP01 14.
- NDCS 03: Digital Control Station for discrete process automation, seamlessly integrated with the ABB NTMP01 14.
- NK TU 01: Field termination unit for mounting the ABB NTMP01 in 19” racks, ensuring organized cabling 3.
Installation and Maintenance
Installation Preparation:
- DIN Rail Mounting: Secure the ABB NTMP01 to a 35 mm DIN rail using included brackets, ensuring proper alignment with adjacent modules.
- Wiring: Connect field devices to the unit’s screw terminals, following ABB’s wiring diagrams for analog/digital signal polarity. Use shielded cables (e.g., NKAS01-15) to minimize EMI 1014.
- Configuration: Set communication protocols and signal ranges via DIP switches or through Control Builder M software. Verify loop power (24 V DC) and ground connections using front-panel LEDs 614.
Maintenance Recommendations:
- Hot-Swap Replacement: Replace faulty modules without system shutdown by disconnecting power, removing the old module, and inserting a new ABB NTMP01.
- Calibration: Perform annual signal accuracy checks using a multimeter, adjusting offsets as needed. ABB’s calibration tools ensure compliance with industry standards 1011.
- Firmware Updates: Regularly update firmware via Control Builder M to support new sensor types and enhance diagnostic features.
- ESD Protection: Use ABB’s Field Static Kit (e.g., part number 1948385A1) during handling to prevent electrostatic discharge damage 10.
Product Assurance
The ABB NTMP01 is backed by a 12-month warranty covering manufacturing defects, with extended warranties available for critical applications. ABB’s global service network provides 24/7 technical support for commissioning, troubleshooting, and custom integration. Stocked in ABB’s Xiamen and Singapore hubs, the ABB NTMP01 ensures fast delivery (3–5 days for Taiwan orders) and immediate replacement in case of emergencies 311.
With rigorous testing against EMC and environmental standards, the ABB NTMP01 delivers unmatched reliability in electrically noisy or extreme conditions. ABB’s commitment to quality and innovation makes it the preferred choice for industrial automation professionals seeking high-performance, future-proof solutions.
HS:7326909000
