Description
ABB MVR 0.44-10KA
Product Overview:
The ABB MVR 0.44-10KA is a high-performance motor protection and control module designed for industrial automation systems. It serves as a critical interface for motor connectivity, combining power distribution, signal conditioning, and safety features in a compact form factor. This module is engineered to handle harsh industrial environments, including manufacturing plants, power generation facilities, and water treatment plants, where reliability and precision are paramount.
Product Overview:
The ABB MVR 0.44-10KA is a high-performance motor protection and control module designed for industrial automation systems. It serves as a critical interface for motor connectivity, combining power distribution, signal conditioning, and safety features in a compact form factor. This module is engineered to handle harsh industrial environments, including manufacturing plants, power generation facilities, and water treatment plants, where reliability and precision are paramount.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MVR 0.44-10KA |
| Manufacturer | ABB |
| Product Type | Motor Protection Module (MPM Series) |
| Rated Voltage | 440V AC (0.44kV) |
| Rated Current | 10kA (short-circuit breaking capacity) |
| Frequency | 50/60 Hz |
| Protection Features | Overload protection, short-circuit protection, phase loss detection |
| Control Interfaces | 2x RS-485 (Modbus RTU), 1x Ethernet (10/100 Mbps) |
| Mounting Type | DIN rail (TS35/7.5 or TS35/15) |
| Physical Dimensions | 170 mm (width) x 115 mm (depth) x 73 mm (height) |
| Weight | 0.85 kg |
| Compliance | CE, UL, IEC 61439 |
| Operating Temperature | -20°C to +60°C |
Key Features and Advantages
Reliable Motor Protection:
The ABB MVR 0.44-10KA provides comprehensive motor protection with selectable trip characteristics (e.g., thermal overload, short-circuit) and phase monitoring to prevent damage from unbalanced loads. Its high breaking capacity (10kA) ensures safe operation in high-risk environments .
The ABB MVR 0.44-10KA provides comprehensive motor protection with selectable trip characteristics (e.g., thermal overload, short-circuit) and phase monitoring to prevent damage from unbalanced loads. Its high breaking capacity (10kA) ensures safe operation in high-risk environments .
Modular and Scalable Design:
Designed for flexibility, the module supports hot-swappable replacement without system downtime, reducing maintenance costs. Its modular architecture allows integration with ABB’s ACS800 drives and AC500 PLC series, enabling seamless expansion of motor control systems .
Designed for flexibility, the module supports hot-swappable replacement without system downtime, reducing maintenance costs. Its modular architecture allows integration with ABB’s ACS800 drives and AC500 PLC series, enabling seamless expansion of motor control systems .
Advanced Diagnostics:
Integrated LED indicators and remote monitoring via Modbus RTU offer real-time insights into motor status, fault conditions, and energy consumption. This facilitates predictive maintenance and minimizes downtime .
Integrated LED indicators and remote monitoring via Modbus RTU offer real-time insights into motor status, fault conditions, and energy consumption. This facilitates predictive maintenance and minimizes downtime .
EMC Compliance:
The module features EMI/RFI shielding to ensure signal integrity in electrically noisy environments, complying with EN 61000-6-2 (industrial immunity) and EN 61000-6-4 (emission) standards .
The module features EMI/RFI shielding to ensure signal integrity in electrically noisy environments, complying with EN 61000-6-2 (industrial immunity) and EN 61000-6-4 (emission) standards .
Application Areas
The ABB MVR 0.44-10KA is ideally suited for industrial applications requiring robust motor protection and control:
- Manufacturing: Conveyor belts, packaging machinery, and robotics.
- Power Generation: Pumps, fans, and compressors in thermal and renewable energy plants.
- Water Treatment: Filtration systems and wastewater processing.
- Oil and Gas: Offshore platforms and pipeline systems.
- Mining and Metals: Ore processing equipment and conveyor systems .
Related Products
- ABB MTA025 EBG92026: Motor terminal adapter for power and signal connectivity.
- ABB ACS800 Drive Series: High-performance drives for advanced motor control.
- ABB AC500 PLC Series: Scalable PLCs for integrating motor control with broader automation systems.
- ABB S800 I/O Modules: Distributed I/O units for seamless system expansion.
- ABB CI854K01: PROFIBUS DP/V1 communication module for remote I/O integration.
Installation and Maintenance
Installation Preparation:
- Power and Cabling: Verify 440V AC power supply and connect motor cables (up to 25 mm²) to the designated terminals.
- Configuration: Set trip parameters (e.g., motor rated current) using ABB’s DriveWindow software or front-panel DIP switches.
- Mounting: Attach the module to a DIN rail using the slide-and-lock mechanism .
Maintenance Recommendations:
- Routine Checks: Inspect terminals for loose connections or corrosion.
- LED Monitoring: Use front-panel LEDs to identify faults (e.g., overcurrent, phase loss).
- Firmware Updates: Periodically update firmware via ABB’s online tools to access new features and security patches.
- Redundancy Testing: For critical applications, test redundant configurations quarterly to ensure failover capability .
Product Assurance
ABB guarantees the MVR 0.44-10KA with a 1-year warranty, covering defects in materials and workmanship. The module undergoes rigorous testing to meet international safety standards, ensuring long-term reliability. Customers benefit from ABB’s global technical support network, offering 24/7 assistance for troubleshooting and system optimization. With spot inventory and 3–5-day delivery commitments, ABB ensures rapid deployment to minimize downtime .
For localized support, ABB’s service centers in Kaohsiung, Taiwan provide on-site maintenance and repairs, leveraging ABB’s global expertise to address regional customer needs .
This combination of high reliability, advanced diagnostics, and responsive service makes the ABB MVR 0.44-10KA a trusted choice for mission-critical motor protection in industrial environments.
