Description
Product Overview
The ABB MVME162-010A is a high-performance VMEbus processor module designed for industrial automation and control systems. Originally developed by Motorola (now under Emerson), this module is engineered for mission-critical applications requiring robust computing power and reliable communication in harsh environments. It features a 25 MHz MC68LC040 or MC68040 microprocessor with 8KB cache and memory management unit (MMU), supporting real-time operating systems (RTOS) like VxWorks and QNX.
As part of the MVME162 series, the module offers 32-bit addressing and multiprocessing capabilities, making it suitable for complex control tasks in industries such as oil and gas, power generation, and transportation. Its VMEbus interface ensures compatibility with a wide range of industrial I/O modules and peripherals, while hot-swap functionality minimizes downtime during maintenance.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Processor | MC68LC040 (32-bit, 25 MHz) or MC68040 (with FPU) |
| Memory | 1–8 MB parity-protected DRAM, 512 KB battery-backed SRAM, 1 MB flash memory |
| Communication | 2x EIA-232/530 serial ports, optional SCSI and Ethernet interfaces |
| Expansion | 4x MVIP IndustryPack slots for additional I/O or communication modules |
| Power Supply | +5V DC (4.75–5.25V), +12V DC (10.8–13.2V) |
| Current Consumption | 1.5A (5V), 0.3A (12V) |
| Operating Temperature | -40°C to +85°C |
| Physical Dimensions | 233.4 mm (width) x 160 mm (height) x 23.3 mm (depth) |
| Compliance | CE, UL, IEC 61000-6-4 (EMC) |
| Mounting Type | VMEbus double-height card (9U form factor) |
| Data Logging | Real-time clock with battery backup |
| Isolation | Galvanic isolation for serial ports (1.5 kV) |
Key Features and Advantages
High-Performance Processing:
The MVME162-010A supports 32-bit VMEbus addressing and multiprocessing, enabling real-time control and data processing in applications like SCADA systems and robotics. Its MC68040 variant includes a floating-point unit (FPU) for complex calculations in scientific and industrial contexts 28.
The MVME162-010A supports 32-bit VMEbus addressing and multiprocessing, enabling real-time control and data processing in applications like SCADA systems and robotics. Its MC68040 variant includes a floating-point unit (FPU) for complex calculations in scientific and industrial contexts 28.
Rugged Industrial Design:
With -40°C to +85°C operating temperature and IP65/IP66 protection (when enclosed), the module withstands extreme temperatures, vibrations, and electromagnetic interference. Its galvanic isolation safeguards signal integrity in high-noise environments 28.
With -40°C to +85°C operating temperature and IP65/IP66 protection (when enclosed), the module withstands extreme temperatures, vibrations, and electromagnetic interference. Its galvanic isolation safeguards signal integrity in high-noise environments 28.
Flexible Expansion:
The 4x MVIP IndustryPack slots allow seamless integration of additional I/O modules (e.g., analog/digital I/O, CANbus), expanding system capabilities without replacing the processor. This modular design reduces upfront costs and simplifies future upgrades 28.
The 4x MVIP IndustryPack slots allow seamless integration of additional I/O modules (e.g., analog/digital I/O, CANbus), expanding system capabilities without replacing the processor. This modular design reduces upfront costs and simplifies future upgrades 28.
Legacy System Compatibility:
Designed for VMEbus-based systems, the MVME162-010A serves as a drop-in replacement for older Motorola modules, ensuring compatibility with legacy industrial equipment. ABB’s Extended Warranty Service extends support for aging systems 24.
Designed for VMEbus-based systems, the MVME162-010A serves as a drop-in replacement for older Motorola modules, ensuring compatibility with legacy industrial equipment. ABB’s Extended Warranty Service extends support for aging systems 24.
Hot-Swap Capability:
The module supports hot-swappable replacement without system shutdown, minimizing downtime during maintenance. Front-panel LEDs provide real-time diagnostics for quick fault identification 28.
The module supports hot-swappable replacement without system shutdown, minimizing downtime during maintenance. Front-panel LEDs provide real-time diagnostics for quick fault identification 28.
Application Areas
The ABB MVME162-010A excels in high-reliability industrial applications:
- Oil and Gas: Controls offshore platforms and refineries, ensuring uninterrupted operation in explosive atmospheres.
- Power Generation: Manages SCADA systems in thermal and hydroelectric plants, optimizing grid stability.
- Transportation: Integrates with railway signaling systems and motor control units for mass transit.
- Manufacturing: Enables real-time monitoring and control of robotics and conveyor systems in automotive plants.
- Aerospace: Supports avionics and flight control systems requiring high computational density.
Related Products
- ABB AC500 PLC Series: Scalable PLCs for integrating with MVME162-010A in distributed control systems.
- ABB ACS800 Drives: High-performance drives compatible with the MVME162-010A for motor control.
- ABB S800 I/O Modules: Distributed I/O units for seamless VMEbus integration.
- Motorola MVME167: Higher-performance variant with faster processor and expanded memory.
- ABB CI854K01: PROFIBUS DP module for connecting remote I/O devices.
Installation and Maintenance
Installation Preparation:
- Power and Cabling: Verify +5V and +12V DC power supplies. Connect serial cables to the rear DB-25 connectors. Use the module’s keying mechanism to ensure correct alignment in the VMEbus backplane 28.
- Configuration: Set processor type (MC68LC040/MC68040) and memory size via DIP switches. Configure serial ports (baud rate, parity) using ABB’s Tribuild software if integrating with PLCs.
Maintenance Recommendations:
- Routine Checks: Inspect power connectors for corrosion. Clean dust using a dry cloth, avoiding solvents.
- LED Monitoring: Use front-panel LEDs to monitor power, processor activity, and fault status. Replace faulty modules immediately.
- Firmware Updates: Regularly update firmware to address security vulnerabilities. ABB’s global technical support network offers 24/7 assistance 23.
- Redundancy Testing: Perform quarterly switchover tests for redundant configurations to ensure failover functionality.
Product Assurance
ABB guarantees the MVME162-010A with a 1-year warranty, covering defects in materials and workmanship. The module undergoes rigorous testing to meet international safety standards, ensuring long-term reliability in industrial environments. Customers benefit from ABB’s global technical support network, offering 24/7 assistance for troubleshooting and firmware updates. With limited stock and 5–20-day delivery commitments, ABB ensures rapid deployment to minimize downtime 30.
For localized support, ABB’s service centers in Kaohsiung, Taiwan provide on-site maintenance and repairs, leveraging ABB’s global expertise to address regional customer needs 32.
This combination of high-performance computing, rugged design, and responsive service makes the ABB MVME162-010A a trusted choice for mission-critical industrial control applications.
