Product Overview
The ABB MTA025 EBG92026 is a high-reliability motor terminal adapter designed for industrial automation systems, specifically engineered to facilitate seamless connectivity between motors and control panels. As part of ABB’s MTA series, this adapter serves as a critical interface for power and signal transmission, ensuring robust performance in harsh industrial environments such as manufacturing plants, power generation facilities, and water treatment plants.
Featuring a modular design, the ABB MTA025 EBG92026 supports quick installation and maintenance, with push-in terminals that simplify wiring for power cables (up to 25 mm²) and control signals. Its IP20-rated enclosure protects against dust and solid particles, while EMI/RFI shielding ensures signal integrity in electrically noisy environments. The adapter is compatible with ABB’s ACS800 drives and AC500 PLC series, enabling seamless integration into comprehensive motor control systems.
A key strength of the ABB MTA025 EBG92026 lies in its versatile terminal configuration, which includes dedicated ports for power input, motor output, and control signals. This design reduces cabling complexity and minimizes the risk of wiring errors, enhancing system reliability and reducing installation time. The adapter also features LED status indicators for power and communication, enabling real-time diagnostics and quick fault identification.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MTA025 EBG92026 |
| Manufacturer | ABB |
| Product Type | Motor Terminal Adapter (MTA Series) |
| Current Rating | 63 A (power terminals), 10 A (control terminals) |
| Voltage Rating | 690V AC (power), 24V DC (control) |
| Cable Compatibility | Power: up to 25 mm², Control: up to 2.5 mm² |
| Communication Interfaces | 2x RS-485 (Modbus RTU), 1x Ethernet (10/100 Mbps) |
| Protection Features | Overvoltage protection, transient suppression |
| Operating Temperature | -20°C to +60°C |
| Physical Dimensions | 170 mm (width) x 115 mm (depth) x 73 mm (height) |
| Weight | 0.85 kg |
| Protection Level | IP20 (EN 60529) |
| Compliance | CE, UL, IEC 61439 |
| Mounting Type | DIN rail (TS35/7.5 or TS35/15) |
Key Features and Advantages
Reliable Connectivity:
The ABB MTA025 EBG92026 ensures secure power and signal transmission with push-in terminals that eliminate the need for screwdrivers, reducing installation time by up to 50%. Its galvanic isolation between power and control circuits prevents ground loops and enhances system stability.
The ABB MTA025 EBG92026 ensures secure power and signal transmission with push-in terminals that eliminate the need for screwdrivers, reducing installation time by up to 50%. Its galvanic isolation between power and control circuits prevents ground loops and enhances system stability.
Modular and Scalable Design:
Designed for flexibility, the adapter supports hot-swappable replacement without powering down the system, minimizing downtime during maintenance. Its modular architecture allows for easy expansion with additional I/O modules, such as the ABB MTA012 for smaller current ratings or the MTA040 for higher power applications.
Designed for flexibility, the adapter supports hot-swappable replacement without powering down the system, minimizing downtime during maintenance. Its modular architecture allows for easy expansion with additional I/O modules, such as the ABB MTA012 for smaller current ratings or the MTA040 for higher power applications.
Advanced Diagnostics:
Integrated LED indicators provide real-time status updates for power, communication, and fault conditions, enabling quick troubleshooting. The adapter also supports remote diagnostics via Modbus RTU, allowing maintenance teams to monitor performance and identify issues without physical access.
Integrated LED indicators provide real-time status updates for power, communication, and fault conditions, enabling quick troubleshooting. The adapter also supports remote diagnostics via Modbus RTU, allowing maintenance teams to monitor performance and identify issues without physical access.
Compliance and Safety:
Certified to CE, UL, and IEC 61439 standards, the ABB MTA025 EBG92026 meets rigorous safety requirements for industrial use. Its finger-safe terminals and insulated housing reduce the risk of electrical shock, ensuring operator safety.
Certified to CE, UL, and IEC 61439 standards, the ABB MTA025 EBG92026 meets rigorous safety requirements for industrial use. Its finger-safe terminals and insulated housing reduce the risk of electrical shock, ensuring operator safety.
Application Areas
The ABB MTA025 EBG92026 is ideally suited for industrial applications requiring reliable motor connectivity:
- Manufacturing: Connects motors to control systems in conveyor belts, packaging machinery, and robotics for precise motion control.
- Power Generation: Facilitates motor connections in pumps, fans, and compressors for thermal and renewable energy plants.
- Water Treatment: Manages motor control for filtration systems, water pumps, and wastewater treatment plants, ensuring compliance with environmental standards.
- Oil and Gas: Enables robust motor connectivity in offshore platforms, refineries, and pipeline systems, withstanding harsh environmental conditions.
- Mining and Metals: Supports motor control in ore processing equipment and conveyor systems, enhancing productivity in demanding environments.
Related Products
- ABB MTA012: Smaller variant for 12 A applications, ideal for low-power motors.
- ABB MTA040: Higher-power variant supporting 40 A, suitable for large industrial motors.
- ABB ACS800 Drive Series: High-performance drives compatible with the MTA025 for advanced motor control.
- ABB AC500 PLC Series: Scalable PLCs for integrating motor control with broader automation systems.
- ABB TB850 CEX Bus Terminator: Expands modular system capabilities for I/O integration.
- ABB CI854K01: PROFIBUS DP/V1 communication module for connecting remote I/O devices.
- ABB S800 I/O Modules: Distributed I/O units for seamless integration with the MTA025.
- ABB EBG92027: Alternative terminal block variant with additional grounding features.
- ABB MSR04X1: Serial communication module for remote monitoring and control.
- ABB UMC100.3: Universal motor controller for advanced motor management.
Installation and Maintenance
Installation Preparation:
Before installing the ABB MTA025 EBG92026, ensure the DIN rail is securely mounted and grounded. Verify the power supply (690V AC for power terminals, 24V DC for control) and inspect the adapter for physical damage. Use the slide-and-lock mechanism to attach the adapter to the rail, then connect power cables (up to 25 mm²) to the designated terminals and control wires (up to 2.5 mm²) to the signal ports. Configure communication parameters (e.g., Modbus address) using ABB’s DriveWindow software if integrating with ACS800 drives.
Before installing the ABB MTA025 EBG92026, ensure the DIN rail is securely mounted and grounded. Verify the power supply (690V AC for power terminals, 24V DC for control) and inspect the adapter for physical damage. Use the slide-and-lock mechanism to attach the adapter to the rail, then connect power cables (up to 25 mm²) to the designated terminals and control wires (up to 2.5 mm²) to the signal ports. Configure communication parameters (e.g., Modbus address) using ABB’s DriveWindow software if integrating with ACS800 drives.
Maintenance Recommendations:
- Regularly inspect terminals for loose connections or corrosion, tightening as needed.
- Clean the adapter’s surface with a dry cloth to remove dust and debris, avoiding solvents that may damage the housing.
- Monitor LED indicators for fault signals; a flashing red LED may indicate a communication error or overvoltage condition.
- For systems with redundant configurations, perform quarterly functional tests to ensure failover capability.
- Update firmware periodically using ABB’s online tools to access the latest features and security patches.
Product Assurance
ABB stands behind the MTA025 EBG92026 with a 1-year warranty, covering defects in materials and workmanship. The adapter undergoes rigorous testing to ensure compliance with international standards, guaranteeing long-term reliability in industrial environments. Customers benefit from ABB’s global technical support network, which provides 24/7 assistance for troubleshooting, firmware updates, and system optimization. With spot inventory and a 3-day delivery commitment, ABB ensures rapid deployment to minimize downtime, making the MTA025 EBG92026 a trusted choice for mission-critical motor connectivity solutions.
