Product Overview
The ABB LDMTR-01 63940135F is a high-performance motor control module designed by ABB, a global leader in industrial automation solutions. Engineered for critical applications, this module belongs to the INFI 90® OPEN system, a robust distributed control platform trusted in industries requiring precision and durability. Specifically tailored for brushless DC (BLDC) and BDH motors with Hall sensors and encoders, the ABB LDMTR-01 63940135F enables seamless integration with automation systems to deliver accurate motion control and real-time monitoring.
As a core component of the INFI 90® OPEN architecture, the ABB LDMTR-01 63940135F supports 16 isolated I/O channels, providing 24 VDC power supply and Modbus TCP/IP communication for efficient data exchange. Its advanced field-oriented control (FOC) algorithms ensure smooth motor operation, while the compact design (100 mm x 70 mm x 35 mm) and DIN rail mounting facilitate easy installation in control cabinets. The module’s wide operating temperature range (-20°C to +60°C) guarantees reliability in extreme industrial environments, making it ideal for medical technology, robotics, and energy management systems.
In industrial settings, the ABB LDMTR-01 63940135F acts as a critical interface between control systems and motor-driven equipment, converting digital commands into precise mechanical movements. Its self-diagnostic capabilities and fault isolation features enhance system uptime, while compliance with international safety standards (e.g., CE, UL) ensures regulatory compliance. Whether deployed in a pharmaceutical cleanroom or a high-speed manufacturing line, the ABB LDMTR-01 63940135F exemplifies ABB’s commitment to innovation and safety.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB LDMTR-01 63940135F |
| Manufacturer | ABB |
| Product Type | Motor Control Module (INFI 90® OPEN System) |
| Input Voltage | 24 VDC ±10% |
| Output Voltage | 24 VDC |
| I/O Channels | 16 Isolated Inputs/Outputs |
| Communication Protocol | Modbus TCP/IP |
| Control Algorithm | Field-Oriented Control (FOC) |
| Operating Temperature | -20°C to +60°C |
| Physical Dimensions | 100 mm x 70 mm x 35 mm |
| Weight | 1.45 kg |
| Mounting | DIN Rail (35 mm) |
| Certifications | CE, UL |
Key Features and Advantages
High-Precision Motor Control: The ABB LDMTR-01 63940135F employs advanced FOC algorithms to achieve smooth, responsive motor operation, reducing energy consumption and mechanical wear. This is particularly critical in applications requiring precise positioning, such as robotics and medical devices.
Flexible I/O Configuration: With 16 isolated I/O channels, the module supports direct integration with Hall sensors, encoders, and other field devices, enabling real-time feedback and control. This flexibility allows for seamless adaptation to diverse automation requirements.
Reliable Communication: Built-in Modbus TCP/IP support ensures efficient data exchange with higher-level control systems, facilitating remote monitoring and diagnostics. This feature is essential for Industry 4.0 applications and predictive maintenance strategies.
Robust Environmental Tolerance: Designed to withstand extreme temperatures and vibrations, the ABB LDMTR-01 63940135F is suitable for harsh industrial environments, including offshore platforms and chemical processing plants. Its IP65-rated enclosure provides protection against dust and water ingress.
Safety Compliance: Compliant with CE and UL standards, the module meets global safety requirements, ensuring regulatory compliance in industries such as pharmaceuticals and power generation. Its self-diagnostic capabilities further enhance operational safety by identifying faults before they escalate.
Applications
The ABB LDMTR-01 63940135F is widely used in industries where precision motor control and reliability are paramount:
- Medical Technology: Controlling syringe pumps, robotic surgical systems, and lab automation equipment to ensure accurate and safe operations.
- Robotics: Coordinating multi-axis robotic arms in manufacturing by providing precise motion control and collision avoidance logic.
- Industrial Automation: Managing conveyor systems, packaging machinery, and CNC machine tools to optimize production efficiency.
- Energy Management: Monitoring and controlling motor-driven equipment in renewable energy plants, such as wind turbines and solar tracking systems.
- Aerospace: Supporting ground testing of aircraft engines and actuators by delivering high-precision motion control.
In each scenario, the ABB LDMTR-01 63940135F acts as the backbone of the control system, enabling predictive maintenance, process optimization, and compliance with safety protocols.
Related Products
- ABB IMDSI12: A 16-channel digital input module supporting 24 VDC/48 VDC/125 VDC or 120 VAC inputs, suitable for diverse voltage requirements.
- ABB IMDSO12: A digital output module for controlling actuators and relays in safety-critical systems.
- ABB PM510V16: A controller module that integrates with the ABB LDMTR-01 63940135F to form a complete INFI 90® OPEN control system.
- ABB IMASI11: An analog input module for monitoring continuous signals like temperature and pressure.
- ABB IMASI13: Specialized for thermocouple inputs, offering direct compatibility with temperature sensors.
- ABB DSQC608: A robot controller module for ABB’s industrial robot systems, complementing the ABB LDMTR-01 63940135F in automated manufacturing environments.
- ABB IMDSI15: Supports 125 VDC/120 VAC inputs, designed for high-voltage industrial environments.
- ABB IMDSI02: A legacy module that can be replaced by the ABB LDMTR-01 63940135F with proper configuration.
These products complement the ABB LDMTR-01 63940135F in building scalable, redundant control systems tailored to specific industry needs.
Installation and Maintenance
Installation Preparation:
Ensure the control cabinet is properly grounded and ventilated to maintain the ABB LDMTR-01 63940135F’s operating temperature range. Use shielded cables for communication interfaces to minimize noise interference. The module’s DIN rail mounting allows for easy integration into standard industrial enclosures. Address configuration is performed via a 6-bit DIP switch (S1), with positions 3–8 setting the module’s address on the INFI 90® OPEN I/O bus.
Ensure the control cabinet is properly grounded and ventilated to maintain the ABB LDMTR-01 63940135F’s operating temperature range. Use shielded cables for communication interfaces to minimize noise interference. The module’s DIN rail mounting allows for easy integration into standard industrial enclosures. Address configuration is performed via a 6-bit DIP switch (S1), with positions 3–8 setting the module’s address on the INFI 90® OPEN I/O bus.
Maintenance Recommendations:
Regularly inspect the ABB LDMTR-01 63940135F for physical damage and ensure connections are secure. Clean the module’s surface with a dry cloth to prevent dust accumulation. Monitor diagnostic LEDs for PASS/FAULT status and review self-diagnostic reports generated by the INFI 90® OPEN system. Replace worn-out modules promptly to maintain system reliability. ABB offers comprehensive training and technical support to assist with troubleshooting and firmware updates.
Regularly inspect the ABB LDMTR-01 63940135F for physical damage and ensure connections are secure. Clean the module’s surface with a dry cloth to prevent dust accumulation. Monitor diagnostic LEDs for PASS/FAULT status and review self-diagnostic reports generated by the INFI 90® OPEN system. Replace worn-out modules promptly to maintain system reliability. ABB offers comprehensive training and technical support to assist with troubleshooting and firmware updates.
Product Warranty and Support
ABB provides a 1-year warranty for the ABB LDMTR-01 63940135F, covering defects in materials and workmanship. The company’s global network of certified technicians offers 24/7 technical support, including remote diagnostics and on-site assistance. Customers can access detailed documentation, software updates, and spare parts through ABB’s dedicated portal. With a focus on lifecycle management, ABB ensures long-term compatibility and performance for its products, even as industrial standards evolve.
