Description
The ABB KUC321AE HIEE300698R1 is a power supply module designed for industrial automation systems, particularly within ABB’s AC800F series distributed control systems (DCS). It serves as a critical component for power management in control cabinets, process control systems, and industrial enclosures, ensuring stable voltage supply to connected devices. Below is a detailed breakdown of its features, specifications, and applications:
Product Overview
- Function: Provides dual-output DC power (5.25V DC and 12V DC) with input voltage ranging from 21–26.4V DC. It supports high inrush current handling (16A AC for 10 seconds) and features thermal overload protection to prevent equipment damage.
- Design: Compact DIN rail-mountable module (60 mm × 33 mm × 43 mm) with IP20 dust protection and UL 94 V-0 flame-retardant housing, suitable for harsh industrial environments.
- Compatibility: Integrates seamlessly with ABB’s AC800F, AC800M, and 800xA automation platforms, as well as third-party systems requiring regulated DC power.
Technical Specifications
| Parameter | Value |
|---|---|
| Input Voltage | 21–26.4V DC |
| Output Voltage | 5.25V DC (3A) + 12V DC (3A) |
| Efficiency | >90% |
| Operating Temperature | -20°C to +70°C (non-condensing) |
| Weight | 1.05 kg |
| Certifications | CE, UL, CSA, EAC |
| Switching Capacity | 250V AC/10A (resistive), 120V AC/15A (resistive) |
| Inrush Current | 16A AC (10-second duration) |
| Connection | 2-pole terminal block (clamping torque: 0.5 N·m) |
Key Features
- Dual Power Output: Delivers precise 5.25V and 12V DC power for low-voltage control circuits, sensors, and actuators.
- Reliability: Built with a thermostatic bimetal sensor and snap-action contacts, ensuring >100,000 operating cycles with minimal maintenance.
- Safety: Includes thermal overload protection and contact resistance monitoring to prevent overheating and short circuits.
- Easy Integration: DIN rail mounting and color-coded terminals simplify installation in space-constrained control cabinets.
Applications
- Industrial Control Systems: Powers PLCs, HMIs, and fieldbus modules in manufacturing, oil & gas, and water treatment plants.
- Process Automation: Supports DCS platforms like ABB’s AC800F for real-time monitoring and control of critical processes.
- Power Distribution: Ensures stable power supply to switchgear, motor control centers, and renewable energy systems.
- Telecommunications: Used in outdoor shelters to maintain voltage stability for radios and networking equipment.
Installation & Maintenance
- Mounting: Install vertically on a 35 mm DIN rail in the upper section of enclosures, away from heat sources.
- Wiring: Connect using 2.5 mm² solid or 1.5 mm² stranded wires with 0.5 N·m torque for secure connections.
- Maintenance: Regularly inspect for dust accumulation and verify contact resistance (<10 mΩ). Replace if signs of fatigue are detected.
Warranty & Availability
- Warranty: 1-year warranty covering defects in materials and workmanship.
- Delivery: Spot inventory available in Xiamen, China, with 3-day delivery after payment.
- Local Support: ABB’s global network provides 24/7 technical assistance, including remote diagnostics and replacement parts.
Related Products
- ABB KTO011/KTS011: Thermostats for temperature regulation in enclosures.
- ABB ZR011: Combined temperature/humidity controller for advanced environmental monitoring.
- ABB PSR-SCP-24VDC Power Supply: Complementary power source for low-voltage applications.
Important Notes
- Compatibility Check: Verify voltage requirements and physical dimensions with your system’s specifications.
- Obsolete Models: The KUC321AE HIEE300698R1 may have newer revisions (e.g., HIEE300698R0001). Contact ABB or local suppliers (e.g., Xiamen-based vendors) for the latest availability.
- Technical Documentation: For detailed wiring diagrams and compliance standards, refer to ABB’s official datasheet or contact their support team.
