ABB KTS011 DIN Rail-Mounted Thermostat

Product Overview
The ABB KTS011 is a compact, DIN rail-mounted thermostat designed for precise temperature regulation in industrial enclosures, control cabinets, and electrical systems. Engineered with a normally open (NO) snap-action contact, this module activates cooling systems or signal devices when ambient temperatures exceed the setpoint, making it ideal for environments requiring active thermal management. As part of ABB’s industrial automation portfolio, the KTS011 supports a wide temperature adjustment range (-10°C to +50°C) with ±4K switching hysteresis, ensuring stable operation with minimal temperature fluctuations . Its thermostatic bimetal sensor guarantees >100,000 operating cycles, while the IP20-rated housing (UL 94 V-0 plastic) provides protection against dust and mechanical impacts. The module’s 60 mm × 33 mm × 43 mm dimensions and 35 mm DIN rail mounting simplify installation in space-constrained environments, with color-coded temperature dials for quick visual verification of setpoints.

Key technical features include a high switching capacity (250V AC/10A resistive) and compatibility with both AC and DC power supplies, enabling seamless integration into diverse industrial setups. The KTS011 also incorporates safety mechanisms such as thermal overload protection and contact resistance monitoring, ensuring long-term reliability even in harsh conditions. By maintaining optimal temperatures in enclosures, this thermostat helps prevent component degradation, reduce energy consumption, and extend the lifespan of connected equipment.

Key Features and Advantages
Precision Cooling Control: The KTS011’s normally open contact design ensures fans or cooling systems activate precisely when temperatures exceed the setpoint, making it ideal for maintaining optimal conditions in enclosed electronic systems. Its wide temperature adjustment range (-10°C to +50°C) suits diverse applications, from industrial machinery to outdoor telecom shelters .

Rugged Durability: Built with a UL 94 V-0 plastic housing and IP20 protection, the KTS011 withstands harsh environments, including vibrations, dust, and temperature extremes (-45°C to +80°C). The snap-action contact design ensures reliable operation over >100,000 cycles, minimizing maintenance requirements .

Easy Installation and Configuration: The module’s DIN rail mount and color-coded temperature dial enable rapid setup, while the 2-pole terminal block supports secure wiring for solid or stranded cables. No additional tools or software are required for basic operation, reducing commissioning time .

Safety and Reliability: The KTS011 includes thermal overload protection and contact resistance monitoring to prevent equipment damage. Its normally open (NO) configuration ensures cooling systems remain inactive until the setpoint is reached, enhancing safety in critical systems .

Energy Efficiency: By activating cooling only when necessary, the KTS011 reduces energy waste and extends the lifespan of connected components. Its hysteresis-controlled switching minimizes actuator wear, further enhancing operational efficiency .

Application Areas
Industrial Control Cabinets: The KTS011 regulates fan activation in control panels, preventing overheating of sensitive components like PLCs and drives in high-temperature environments.
Telecommunications Equipment: Used in outdoor telecom shelters to maintain stable temperatures for radios, batteries, and networking devices, ensuring uninterrupted service.
Power Distribution Systems: Monitors and controls cooling fans in switchgear and substations, protecting against thermal stress in high-voltage environments.
Food and Beverage Processing: Safeguards temperature-sensitive storage areas, such as cold rooms and packaging lines, by activating cooling systems to prevent spoilage.
Renewable Energy Systems: Installed in wind turbine nacelles and solar inverters to manage thermal loads, ensuring reliable performance in extreme weather conditions.

Installation and Maintenance
Pre-Installation Preparation:
Mount the ABB KTS011 vertically on a 35 mm DIN rail in the upper section of the enclosure, away from heat sources. Verify power supply compatibility (24-72V DC or 120/250V AC) and secure wiring connections using 2.5 mm² solid or 1.5 mm² stranded wires. Adjust the temperature dial to the desired setpoint (e.g., 30°C for typical industrial applications).

Maintenance Recommendations:
Regularly inspect the module for dust accumulation and ensure vents are unobstructed. Clean the housing with a dry cloth and check for loose connections. Replace the thermostat if contact resistance exceeds 10 mΩ or if the bimetal sensor shows signs of fatigue. ABB recommends firmware updates every 2 years to access enhanced safety features.

Product Warranty
The ABB KTS011 is backed by a 1-year warranty covering defects in materials and workmanship. ABB’s global support network provides 24/7 technical assistance, including remote diagnostics and replacement parts. With spot inventory availability, customers benefit from 3-day delivery after payment, ensuring minimal downtime for critical installations. ABB’s commitment to quality ensures the KTS011 meets rigorous industrial standards, providing long-term reliability for mission-critical thermal management applications.
