Description

Product Overview
The ABB KD2406PTBX is a high-reliability 24V DC terminal block module designed for industrial electrical connectivity within control panels and automation systems. As part of ABB’s KD series, this module serves as a standardized interface for power distribution and signal routing, enabling secure and efficient wiring in harsh industrial environments. The KD2406PTBX supports 6-channel electrical connections with integrated protection features, making it ideal for applications requiring robust terminal solutions in manufacturing, energy, and process control setups.

Engineered with a modular design, the ABB KD2406PTBX ensures easy installation and maintenance via 35 mm DIN rail mounting. Its 24V DC compatibility aligns with common industrial power standards, while built-in overload and short-circuit protection safeguards connected devices from electrical faults. The module’s compact form factor (105 mm × 50 mm × 75 mm) optimizes space in control cabinets, while flame-retardant materials (UL94 V-0 rating) enhance safety in critical applications. By integrating seamlessly with ABB’s control systems and peripheral devices, the KD2406PTBX streamlines cabling management and reduces downtime in mission-critical operations.

The KD2406PTBX features screw-type terminals for reliable wire termination and withstands up to 10A continuous current, making it suitable for both low-power signal transmission and medium-power distribution. Its wide operating temperature range (-25°C to +70°C) and IP20 protection rating ensure resilience in dusty or vibrating environments, reinforcing its role as a durable connectivity solution for industrial automation.

Technical Specifications

Parameter Name	Parameter Value
Product Model	KD2406PTBX
Manufacturer	ABB
Product Type	24V DC Terminal Block Module
Voltage Rating	24V DC (operating), 500V AC (dielectric strength)
Current Rating	10A per channel (continuous)
Number of Channels	6
Terminal Type	Screw-type (M4 screws, suitable for 0.5–2.5 mm² wires)
Mounting	35 mm DIN rail (EN 60715)
Physical Dimensions	105 mm (H) × 50 mm (W) × 75 mm (D)
Weight	0.15 kg
Operating Temperature	-25°C to +70°C
Storage Temperature	-40°C to +85°C
Protection Rating	IP20 (防尘), UL94 V-0 (flame retardant)
Certifications	CE, UL, cUL, RoHS

Key Features and Advantages
Reliable Electrical Connectivity: The ABB KD2406PTBX ensures secure wire termination via screw-type terminals, minimizing contact resistance and preventing loose connections. Its 10A current rating per channel supports both signal and power applications, reducing the need for separate terminal blocks.

Integrated Protection: Built-in overload and short-circuit protection safeguards downstream devices from voltage spikes and electrical faults, eliminating the need for external fuses and reducing component costs.

Space-Efficient Design: At 50 mm width, the module optimizes cabinet space while accommodating 6 channels, making it ideal for dense control panel setups. Its DIN rail mounting enables tool-free installation and hot-swapping for maintenance without system shutdown.

Industrial-Grade Durability: Constructed with flame-retardant materials and rated for -25°C to +70°C operation, the KD2406PTBX withstands harsh industrial environments, including vibrations, dust, and temperature fluctuations.

Easy Maintenance: Clear labeling of terminals and LED status indicators (optional, depending on model) simplify troubleshooting, while modular design allows individual channel replacement without disrupting adjacent connections.

Application Areas
Industrial Control Panels: The ABB KD2406PTBX is critical for organizing power and signal wiring in control cabinets, the connecting PLCs, sensors, and actuators in manufacturing lines. Its protection features ensure stable operation in automotive plants, food processing facilities, and packaging industries.

Energy Distribution Systems: Deployed in switchgear and motor control centers, the module manages 24V DC power distribution for relays, contactors, and control circuits in renewable energy plants (e.g., solar, wind) and industrial substations.

Process Automation: In chemical and petrochemical plants, the KD2406PTBX routes signals from field instruments (e.g., pressure transmitters, flow meters) to DCS systems, supporting real-time process monitoring and control.

Building Automation: The module connects HVAC controls, lighting systems, and security devices in smart buildings, enabling centralized management via BMS (Building Management Systems). Its compact design fits seamlessly into building control panels.

Marine and Offshore: Rated for harsh environments, the KD2406PTBX is used on ships and offshore platforms to terminate wiring for navigation systems, engine controls, and emergency shutdown circuits, meeting maritime safety standards.

Related Products

ABB KD2412PTBX: 12-channel variant of the KD2406PTBX for higher-density wiring requirements in large control panels.
ABB KD4806PTBX: 6-channel terminal block with 48V DC compatibility, suitable for industrial systems requiring higher voltage.
ABB KDG2406PTBX: Ground terminal block designed to pair with KD2406PTBX for enhanced electrical grounding in safety-critical applications.
ABB KDS2406PTBX: Spring-cage terminal block version, offering tool-free wiring for faster installation compared to the screw-type KD2406PTBX.
ABB KDM2406PTBX: Din rail mounting adapter kit for retrofitting KD2406PTBX into non-standard cabinet setups.

Installation and Maintenance
Pre-Installation Preparation:
Ensure the control panel is powered off and grounded before installing the ABB KD2406PTBX. Verify compatibility with 35 mm DIN rails and inspect the module for physical damage. Prepare wires by stripping 8–10 mm of insulation and use ferrules for stranded wires to ensure secure termination. Configure terminal labeling according to wiring diagrams, and ensure the ambient temperature does not exceed +70°C in the installation location.

Maintenance Recommendations:
Regularly inspect the KD2406PTBX for loose terminals or signs of overheating (discoloration). Tighten screw terminals every 6 months in vibrating environments to prevent contact resistance. Clean dust and debris from the module using a dry cloth to maintain optimal heat dissipation. Replace any channel showing corrosion or electrical arcing, and dispose of old modules in compliance with environmental regulations. ABB’s technical support can provide firmware updates (if applicable) and troubleshooting guidance for persistent issues.

Product Warranty
The ABB KD2406PTBX is backed by a 1-year warranty covering manufacturing defects and material flaws. ABB offers global technical support, including 24/7 emergency assistance for critical installations, and ensures spot inventory for rapid replacement. Customers benefit from 3-day delivery after payment and comprehensive post-sales services, including installation training and system compatibility audits. ABB’s commitment to quality ensures the KD2406PTBX meets rigorous industrial standards, providing long-term reliability and peace of mind for automation projects.
