ABB IPFLD24 Field Power Supply Module: The Stable Power Core for Industrial Control Systems
The ABB IPFLD24 is a field power supply module from the ABB Bailey series, built specifically for industrial automation and process control systems. It serves as an indispensable power supply unit in ABB’s INFI 90 and Symphony systems, tasked with delivering stable, reliable power to all kinds of field devices.
Powered by high-efficiency power conversion technology, this module maintains consistent, precise voltage output even in harsh industrial environments, easily meeting the power demands of various control equipment. For many plant retrofits and new system builds, the IPFLD24 has become a trusted choice among engineers for its steady performance.
As a key component of the Modular Power System III (MPSIII), the IPFLD24 supplies multiple power outputs to Harmony rack components and INFI 90 system parts. It supports a full range of DC voltage outputs — including 5VDC, 15VDC, -15VDC, 24VDC, 48VDC, and 125VDC — covering the diverse power needs of field devices. Its wide input voltage range also allows it to adapt to different grid conditions across regions and working scenarios, keeping the system running smoothly at all times.
Within the industrial automation architecture, the IPFLD24 takes on the critical job of safely distributing main power to every field control device. Its compact size and high efficiency make it perfect for space-limited installations, while still upholding ABB’s long-standing standards for reliability and durability.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IPFLD24 |
| Manufacturer | ABB |
| Product Type | Field Power Supply Module |
| Input Voltage Range | 100-240V AC / 120-370V DC (auto-ranging) |
| Output Voltage | 24V DC ±0.5V |
| Output Current | 10A continuous, 15A peak for 10 seconds |
| Efficiency | 95% |
| Dimensions | 120×140×85mm |
| Weight | 0.82kg |
| Operating Temperature | -20°C to +55°C |
| Mounting Method | DIN rail mounting |
| Protection Rating | IP20 |
| Protection Features | Overload, short circuit, overvoltage protection |
Key Features and Advantages
What makes the IPFLD24 stand out is its exceptional reliability and environmental adaptability. Its wide input voltage design automatically compensates for grid fluctuations, maintaining stable output even in industrial sites with unstable power — a huge advantage for retrofitting older facilities.
With up to 95% power conversion efficiency, the module cuts down energy waste and reduces long-term operating costs, while also lowering heat dissipation demands on site.
It performs reliably in tough conditions too. Operating smoothly from -20°C to +55°C and resisting vibration well, the IPFLD24 is built for long-term use in demanding environments like power plants and petrochemical facilities. Built-in overload, short circuit, and overvoltage protection act as a safety layer, preventing unexpected electrical faults and extending the life of connected equipment.
DIN rail mounting and a compact body simplify installation and save precious space in control cabinets. Clear LED status indicators let maintenance staff quickly check operation and diagnose issues, cutting down system downtime. These practical details make the IPFLD24 an ideal power solution for legacy system upgrades and modernization projects.
Application Fields
The ABB IPFLD24 is widely used across industries that demand highly reliable power.
In the power and energy sector, it provides stable power to control equipment in power plants and transmission/distribution systems, supporting grid safety and stable operation. Its strong vibration resistance makes it especially suitable for the high-vibration environments found in power plants.
In oil and gas, the IPFLD24 powers field instruments and control valves in hazardous areas. Its rugged construction and protection features stand up to corrosive environments and temperature changes, while stable output ensures accurate measurement and control of process parameters — critical for safety and quality in chemical production.
For municipal water services, it supports automation in water treatment and supply systems, powering sensors, actuators, and other field devices. In manufacturing automation, it delivers uninterrupted power to production line control equipment, keeping manufacturing processes continuous and reliable.
Related Products
IPFLD22: 22V DC power supply module, similar power output with different configuration
IPFLD48: 48V DC field power supply module, for field devices requiring higher voltage
IPFLD125: 125V DC power module, designed for high-power systems
IPSYS01: System power module, part of the same power system series as IPFLD24
P-HA-RPS-32000000: Power supply tray, providing 5VDC, ±15VDC, and 24VDC system outputs
PHARPSFAN03000: Fan assembly for cooling the power system
Installation and Maintenance
Pre-installation Preparation
Before installing the IPFLD24, confirm the installation environment meets temperature, humidity, and space requirements. The DIN rail must be securely mounted, and at least 15mm of clearance should be left on both sides of the module for heat dissipation. Use properly sized cables — such as 12AWG input wires — to minimize voltage drop and ensure stable power delivery.
Maintenance Recommendations
The IPFLD24 is designed for maintenance-free operation, but regular inspections help ensure long-term reliability. Monitor status using the on-board LED indicators and address any abnormalities promptly. Keep the area around the module well-ventilated, and avoid continuous operation above 55°C. Check connection terminals regularly to maintain secure electrical connections.
Product Assurance
ABB provides full quality assurance and technical support for the IPFLD24 field power supply module. The module carries CE and other international certifications, meeting strict industry standards for quality and safety. ABB’s global service network delivers professional technical consulting and maintenance, keeping the module performing at its best throughout its service life.
For the IPFLD24, ABB offers ongoing technical support and spare parts services to minimize user downtime. Rugged construction and high-quality components ensure long, reliable operation, reducing the total cost of ownership. ABB’s professional team can also develop customized power solutions to match the specific needs of different applications.
