Description
ABB DTCC901B 61430001-FU Main Processor Unit Product Description
Product Overview
ABB DTCC901B 61430001-FU is the core main processor unit custom-designed for ABB’s 800xA system, specifically developed for industrial automation and process control applications. It acts as the “brain center” of the 800xA system, integrated with a high-performance processor that delivers robust computing power and ultra-fast response speeds. This hardware foundation enables it to effortlessly handle complex control and data processing tasks, while supporting multitasking and parallel operation to enhance the overall efficiency and flexibility of the control system. As a key core component of the ABB 800xA system, this module undertakes the critical responsibility of coordinating and managing all types of on-site control tasks, serving as the backbone for the efficient and stable 24/7 operation of the entire industrial automation control system.
This main processor unit adopts advanced electronic technology and a rugged hardware design, enabling it to maintain top-tier operational performance even in harsh industrial environments with temperature fluctuations and strong electromagnetic interference. In addition, the DTCC901B 61430001-FU supports CPU redundancy configuration, which greatly improves system availability for critical industrial applications, and it holds official EMC certification, ensuring reliable electromagnetic compatibility in complex on-site environments. Its streamlined structural design and user-friendly operation logic make it highly adaptable to a variety of industrial scenarios, including manufacturing plants, process control systems and energy management projects, consistently providing users with stable and reliable industrial control solutions.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | DTCC901B 61430001-FU |
| Manufacturer | ABB |
| Product Type | Main Processor Unit |
| Supply Voltage | 24V DC |
| Power Consumption | ≤5W |
| Communication Protocols | MODBUS RTU, Ethernet, Serial Communication, Fieldbus |
| Operating Temperature | -20°C to +70°C |
| Operating Humidity | 0% to 95% RH non-condensing |
| Response Time | ≤1ms |
| Input Voltage Range | DC 12V to 24V |
| Mounting Method | DIN Rail Mounting |
| Certifications | EMC Certification |
Key Features and Advantages
ABB DTCC901B 61430001-FU features a range of outstanding strengths that make it a leading choice in the industrial automation control field, with high-performance processing capability as its core advantage. The built-in high-end processor delivers powerful computing capacity and millisecond-level fast response, easily handling the complex control algorithms and large-volume data processing required in modern industrial production—this is precisely the processing power demanded by high-end industrial automation systems. Its native support for multitasking and parallel operation further boosts system efficiency and flexibility, perfectly meeting the stringent requirements of modern industrial automation for fast and precise control.
CPU redundancy support is another major competitive advantage of this module, a design that effectively prevents system downtime caused by single-point failures and ensures the uninterrupted operation of critical industrial applications. It is equipped with a rich set of communication interfaces, including Ethernet, serial communication and fieldbus, allowing seamless connection and communication with various on-site devices, subsystems and industrial networks, and building a smooth data transmission channel for the entire control system. Official EMC certification enables it to resist various electromagnetic interferences common in industrial sites, maintaining stable and reliable operation in complex electromagnetic environments.
Furthermore, its compact structural design and ultra-low power consumption (≤5W) are significant benefits for on-site applications: the small form factor saves valuable installation space in control cabinets, while low power consumption effectively reduces the overall energy consumption of the control system. All these excellent features combine to make the DTCC901B 61430001-FU a reliable core processing solution for a variety of industrial automation control scenarios.
Application Fields
ABB DTCC901B 61430001-FU offers extensive application value across the entire industrial automation landscape, with particularly remarkable performance in the manufacturing industry. In modern manufacturing plants, it is used for the centralized monitoring and precise control of production line equipment such as machine tools, conveyors and robotic systems, acting as the core brain to drive full production line automation and improve overall production efficiency. In the energy sector, it is integrated into the management systems of power generation and distribution facilities including wind turbines, solar panels and thermal power plants, optimizing the operation logic of energy facilities to ensure their efficient and stable power generation and supply.
The process industry is also a key application area for this main processor unit. It is widely used in the real-time monitoring and closed-loop control of critical production processes such as chemical reaction systems, oil and gas pipelines and water treatment plants, where its fast response and high computing accuracy ensure the safety and stability of continuous production processes. In building automation, it can serve as the core control unit for commercial and residential building systems, unifying the management of HVAC, lighting and security systems and greatly improving the intelligent management level of buildings. Beyond these core sectors, it is also well-suited for all industrial scenarios requiring highly reliable central control and high-speed data processing, demonstrating exceptional environmental adaptability and operational reliability in practical applications.
Related Products
DTCC901A: The previous generation processor unit of the same series with mature and stable performance, ideal for upgrade and transformation projects of old system equipment
DTCC902B: Enhanced main processor unit with higher computing capacity and more extended functions, designed for high-complexity industrial control scenarios
CI854AK01: ABB dedicated communication interface module, highly compatible with DTCC901B for expanding the system’s external communication capabilities
PM803F: ABB industrial controller, serving as the supplementary control unit of the system to share the processing load of the main processor
AI810: ABB analog input module, paired with DTCC901B to expand the system’s analog signal acquisition capability
DI810: ABB digital input module, adding more digital signal processing channels for the control system
DO810: ABB digital output module, providing additional control output points to drive more on-site execution devices
CI830: ABB industrial communication interface module, specially used to enhance the system’s overall networking and remote communication capabilities
Installation and Maintenance
Pre-installation Preparation
Prior to installing the ABB DTCC901B 61430001-FU, the primary and most critical step is to fully disconnect the power supply of the entire control system to eliminate potential electrical safety hazards, and prepare all matching installation tools and connection accessories in advance. During installation, strictly follow the operational requirements in ABB’s official technical documentation to securely mount the module on the standard DIN rail, and conduct repeated checks to ensure all power and communication connections are correct and reliable. Since this module is equipped with a variety of communication interfaces, special attention should be paid to the wiring of Ethernet and serial ports—standard and reliable wiring here is the foundation for smooth data communication between the module and other on-site devices.
Maintenance Recommendations
To maintain the optimal performance of the DTCC901B 61430001-FU over the long term, it is recommended to regularly check the module’s overall operating status and on-board indicator lights—these lights are the most direct way to judge the real-time working state of the module and its internal components. In dusty industrial environments, clean the module’s ventilation areas with a dry, soft brush on a regular basis to prevent dust accumulation from blocking the heat dissipation channel and causing abnormal operating temperatures.
Although the module features high industrial reliability and stability, a comprehensive functional test every year is advisable to verify that all computing, communication and control functions operate normally and accurately. All maintenance and debugging operations of the module shall be performed by professionally trained technical personnel, and only ABB genuine recommended spare parts shall be used for any replacements—this is the simplest and most effective way to ensure the module’s compatibility with the entire 800xA system and the stability of subsequent operations.
Product Assurance
ABB provides a comprehensive range of product quality assurance and professional after-sales service support for the DTCC901B 61430001-FU main processor unit. Every module undergoes rigorous multi-procedure testing and inspection before leaving the factory, and only products that fully meet ABB’s stringent global high-quality standards are delivered to customers. This main processor unit comes with a 12-month quality warranty starting from the official shipment date, providing solid quality protection for users during the initial usage phase.
ABB’s professional technical support team is on standby to offer one-on-one technical consultation and accurate fault diagnosis services for users, helping to resolve various technical problems and on-site application issues encountered during module use, and ensuring users can fully utilize all product functions. The company is committed to a rapid response mechanism for technical support and spare parts supply, relying on its global after-sales service network and spare parts supply system to minimize equipment downtime caused by module faults and reduce the corresponding production losses for customers. Furthermore, ABB’s technical team will continuously provide targeted technical support and performance optimization suggestions for this product throughout its entire life cycle, ensuring the DTCC901B 61430001-FU maintains optimal operating performance in different application stages.
