ABB DSTK150 Flat Cable Assembly(XIONGBA)

Description

Product Overview

Technical Specifications

Main Features and Advantages

• High-Density Signal Routing: The DSTK150’s 64-pin to 40-pin connector design supports simultaneous transmission of multiple signals (e.g., analog inputs, digital outputs), reducing cabling complexity in high-density I/O racks 15.
• EMI/RFI Protection: Shielded construction minimizes interference from high-voltage equipment, ensuring stable signal integrity in electrically noisy environments like industrial plants 17.
• Flexible Installation: The flat cable design allows easy routing through confined spaces, while the Euro Con connectors provide secure, vibration-resistant connections 16.
• Wide Compatibility: Works seamlessly with ABB’s S100 I/O modules (e.g., DSAI 160K03 analog input modules, DS DI 110K06 digital input modules) and Safeguard 400 safety controllers, enabling scalable automation solutions 15.
• Reliable Performance: Tested to withstand extreme temperatures (-25°C to +85°C) and mechanical stress, ensuring long-term durability in harsh industrial settings 15.

Application Areas

• Power Generation: Connects turbine control systems, generator monitoring modules, and grid synchronization equipment in thermal and renewable energy plants.
• Oil and Gas: Supports signal transmission between wellhead sensors, pipeline valves, and distributed control systems (DCS) in offshore platforms and refineries.
• Manufacturing: Enables communication between robotic arms, CNC machines, and PLCs in automotive and electronics production lines.
• Safety-Critical Systems: Integrates with ABB’s Safeguard 400 to ensure fail-safe operation in emergency shutdown (ESD) panels and hazardous area applications 15.

Related Products

• ABB S100 I/O Modules: Modular I/O system for analog/digital signal acquisition, including DSAI 130K03 (16-channel analog input) and DS DO 115K02 (32-channel digital output), compatible with the DSTK150 15.
• ABB Safeguard 400 Series: Safety controllers and I/O modules for critical applications, requiring DSTK150 for prefabricated cable connections in redundant systems 15.
• ABB TU810/TU812: Terminal units for mechanical mounting and signal termination, used alongside the DSTK150 in S800 I/O systems 4.

Installation and Maintenance

1. Route the DSTK150 cable between the I/O module and terminal unit, ensuring proper strain relief.
2. Secure the Euro Con 96-40P connectors to the respective devices, verifying pin alignment to prevent damage.
3. Use cable ties or clips to organize the flat cable and minimize EMI exposure.

• Regularly inspect connectors for corrosion or 松动. Clean dust from the cable sheath using a dry cloth.
• Replace damaged cables immediately to avoid signal degradation. ABB offers extended warranty plans for mission-critical applications 15.

Product Guarantee and Availability

• Warranty: 1-year manufacturer’s warranty against defects in materials and workmanship.
• Inventory: Typically available in stock for rapid dispatch (3–5 business days after payment).
• Origin: Manufactured in Switzerland, with global technical support from ABB.
• Compliance: RoHS-exempt, suitable for environmentally conscious projects 15.
