Product Overview
ABB DSDP150 57160001‑GF is a dedicated pulse encoder input unit for ABB Advant Master S100 I/O system. It accepts 12 VDC pulse signals coming from encoders, pulse generators and flow transmitters, performs high‑speed pulse counting and frequency measurement, and transmits processed digital values to the DCS controller. This legacy board is widely used for retrofitting and spare‑part replacement on old‑generation ABB process control installations.
Series
Advant Master S100 I/O is ABB’s legacy modular DCS I/O family. It supplies various signal‑processing cards for process‑industry control, including analog, digital, pulse‑counting and special function modules, deployed in power, pulp‑paper and metallurgy sites.
Product Features
‑ Designed for 12 VDC pulse‑generator / encoder signal input, maximum input frequency up to 10 kHzABB Group‑ Real‑time pulse counting and frequency measurement for speed, position and flow‑signal processing‑ Standard S100 rack‑mount form factor, connects to system backplane bus‑ On‑board hardware circuit for signal filtering and noise suppression for industrial field interference‑ Status LED indicators for module diagnosis and fault troubleshooting‑ RoHS‑exempt legacy electronic assembly, only for existing system spare‑part replacement‑ Compact Euro‑card dimension for DCS cabinet installation
Product Parameters
| Item | Details |
|---|---|
| Part Number | DSDP150 / 57160001‑GF |
| Brand | ABB |
| Series | Advant Master S100 I/O |
| Product Type | Pulse Encoder Input Unit |
| Input Signal | 12 VDC pulse signal |
| Max Input Frequency | 10 kHzABB Group |
| Power Supply | System backplane power supply |
| Weight | 0.425 kgABB Group |
| Dimension(W×H×D) | 250 mm ×15 mm ×360 mmABB Group |
| Operating Temperature | ‑20℃ ~ +60℃ |
| Protection Class | IP20 (cabinet‑mount only) |
| Discontinued Status | Obsolete, spare‑part only |
| HS Code | 85389091 |
Product Specifications
- Installation: Installed inside Advant Master S100 I/O rack
- Storage temperature:‑40℃ ~ +85℃
- Relative humidity: 5‑95% non‑condensing
- Application note: Not for new‑project design, only for maintenance & retrofit of existing Advant‑based plants
Function
Collect pulse‑encoder / pulse‑generator field signals; execute pulse counting and frequency measurement; convert pulse signals into digital process variables for DCS controller; support rotation speed, position and flow‑rate calculation; provide module running‑state diagnosis.
Purpose
Special pulse‑acquisition I/O card for ABB Advant Master DCS, used to process encoder and pulse‑transmitter signals in process‑control sites.
Application Fields
‑ Thermal power plant DCS maintenance & retrofit‑ Pulp and paper process automation‑ Metallurgy heavy‑industry control systems‑ Legacy ABB Advant Master system spare‑part replacement‑ Flow‑meter pulse‑signal acquisition for chemical‑process plants
