Description

Brand Model: ABB DPW01
Product Name: Power Supply Module
Warranty: 1–2 years (varies by supplier)
Size: 4 cm (depth) × 21 cm (height) × 27 cm (width)
Weight: 1.48 kg
Origin: Sweden
Inventory: New surplus, refurbished, or used (available through industrial automation distributors)
Delivery Time: 3–10 days (global shipping via DHL/UPS)

Product Overview

The ABB DPW01 is a high-reliability power supply module designed for industrial automation systems, primarily supporting ABB’s Bailey INFI 90 distributed control system (DCS) and Hartmann & Braun Freelance 2000 platforms. It provides stable 24 VDC power for control modules, ensuring continuous operation in harsh industrial environments. With short-circuit, overload, and overvoltage protection, the DPW01 safeguards downstream devices from transient faults, critical for maintaining system integrity in applications like chemical processing, power generation, and automotive manufacturing.

Key features include a wide input voltage range (85–264 VAC), compact DIN rail-mountable design, and -25°C to +70°C operating temperature tolerance. The module supports redundant power configurations for mission-critical systems and integrates seamlessly with INFI 90’s backplane architecture, minimizing cabling complexity.

Technical Specifications

Parameter Name	Parameter Value
Product Model	DPW01 (variant P 3761158018181 supports 24 VDC/5 A output)
Manufacturer	ABB
Product Type	Power Supply Module for INFI 90 DCS/Hartmann & Braun systems
Input Voltage	85–264 VAC (universal)
Output Voltage	24 VDC
Output Current	1.3 A (standard) or 5 A (high-power variant)
Efficiency	≥85%
Protection Features	Short-circuit protection, overload protection, overvoltage protection
Operating Temperature	-25°C to +70°C (derating required above +50°C)
Certifications	CE-certified; compatible with RoHS directives
Physical Dimensions	4 cm × 21 cm × 27 cm (depth × height × width)
Weight	1.48 kg
Mounting	DIN rail or panel-mountable

Main Features and Advantages

High-Reliability Power Delivery:

Dual-Rail Output: Provides 24 VDC for logic and field devices, ensuring stable power distribution across INFI 90 racks.
Surge Suppression: Withstands 8 kV ESD and 2.5 kV surge events, critical for environments with frequent voltage fluctuations (e.g., welding shops, power plants).

Modular System Compatibility:

INFI 90 Ecosystem: Integrates with INFI 90’s IMM (Input/Output Multiplexer Modules) and PM (Process Modules), supporting scalable configurations from small panels to multi-rack systems.
Redundancy Support: Enables parallel power supply setups for high-availability systems, reducing downtime risk.

Wide Environmental Tolerance:

Harsh Conditions: Certified for operation in high humidity (5–95% RH) and dusty environments, suitable for food processing plants, wastewater treatment facilities, and offshore platforms.
Vibration Resistance: Withstands 5–500 Hz vibrations, ensuring long-term reliability in dynamic industrial settings.

Application Areas

Process Industries:

Chemical & Petrochemical: Powers reactor control modules and distillation column valves in SIL2-rated systems.
Pharmaceutical Manufacturing: Supports cleanroom HVAC systems and sterilizer chamber actuators, ensuring FDA/GMP compliance.

Power Generation:

Thermal Power Plants: Supplies power to turbine control systems and generator protection relays.
Renewable Energy: Manages solar inverter clusters and wind farm SCADA systems, enabling remote monitoring and predictive maintenance.

Industrial Automation:

Automotive Assembly: Drives robotic welding cell controllers and conveyor belt control modules.
Food & Beverage: Powers filling machine PLCs and packaging equipment in IP65-rated environments.

Installation & Maintenance

Installation:

Mount the DPW01 on a DIN rail with ≥50 mm air clearance for cooling.
Connect input power via terminal block (L/N/PE), ensuring proper grounding.
Link to INFI 90 backplane using ABB’s TU830v1 termination unit for power distribution.

Maintenance:

Use ABB’s System 800xA Condition Monitoring to track power consumption and voltage stability.
Clean dust from vents quarterly using compressed air (≤0.6 bar) to prevent overheating.
For redundant configurations, verify power supply redundancy status monthly using ABB’s diagnostic tools.

Product Guarantee

The DPW01 is covered by a 1–2 year warranty (new units) or 90-day warranty (refurbished units) against manufacturing defects. It complies with global safety standards (CE, RoHS) and environmental directives. ABB’s Service Portal offers firmware updates and technical bulletins, while regional service centers provide 24/7 support for urgent issues. For large-scale projects, ABB offers Commissioning Services to ensure optimal integration with existing systems.

With its robust design, wide input voltage range, and modular compatibility, the DPW01 is engineered for industrial applications requiring reliable power supply in non-hazardous environments.
