Description
ABB CM772F 3BDH000368R0001 is a high-performance PROFIBUS DP Master Communication Module designed for industrial automation systems, specifically engineered to enable seamless integration of PROFIBUS DP protocol within ABB’s Advant 800xA distributed control system (DCS) architecture. As a critical component of the Advant 800xA platform, this module serves as a bridge between field devices, PLCs, and higher-level control systems, ensuring reliable data exchange across complex industrial networks. With its advanced protocol support, rugged design, and compatibility with ABB’s AC 800F and Freelance systems, the CM772F 3BDH000368R0001 is ideal for applications requiring high-speed, deterministic communication in harsh industrial environments.
The module supports PROFIBUS DP V1 protocol, making it compatible with a wide range of PROFIBUS-compliant devices such as sensors, actuators, and drives. It features dual 9-pin D-sub connectors for redundant PROFIBUS DP communication, allowing both single and redundant network configurations to minimize downtime. Designed for industrial resilience, the CM772F 3BDH000368R0001 operates reliably across a wide temperature range (-40°C to +70°C) and complies with CE, UL, and CSA certifications, ensuring compatibility with global standards. Its compact form factor (152 mm width × 76 mm height × 152 mm depth) and hot-swap capability further enhance its suitability for space-constrained control cabinets. The module also supports GSDML (General Station Description Markup Language) files for easy device configuration, streamlining integration with third-party PROFIBUS DP slaves.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CM772F 3BDH000368R0001 |
| Manufacturer | ABB |
| Product Type | PROFIBUS DP Master Communication Module |
| Communication Protocol | PROFIBUS DP V1 |
| Interface Type | 2× 9-pin D-sub (PROFIBUS DP A/B channels) |
| Power Supply | DC 24V (±10%), 8-12W power consumption |
| Operating Temperature | -40°C to +70°C |
| Protection Class | IP20 (suitable for indoor control cabinets) |
| Redundancy Support | Dual PROFIBUS DP channels for redundant communication |
| Certifications | CE, UL, CSA |
| Physical Dimensions | 152 mm (width) × 76 mm (height) × 152 mm (depth) |
| Weight | 0.3 kg |
Main Features and Advantages
PROFIBUS DP V1 Compliance: The ABB CM772F 3BDH000368R0001 supports PROFIBUS DP V1, enabling advanced features such as cyclic and acyclic data exchange, device diagnostics, and parameterization. This makes it suitable for demanding applications requiring real-time control and monitoring, such as process automation and machine control.
Redundant Communication: Built with dual PROFIBUS DP channels, the module ensures continuous operation even in the event of a single-point failure. This redundancy is critical for applications where downtime is unacceptable, such as power generation and petrochemical plants. The module’s hot-swap capability allows for maintenance without disrupting system operation, reducing downtime during upgrades or repairs.
Industrial Compatibility: The module is compatible with ABB’s Advant 800xA, AC 800F, and Freelance systems, as well as third-party PROFIBUS DP devices via GSDML files. This flexibility reduces the need for multiple communication gateways, simplifying system architecture and lowering costs.
Ease of Use: The CM772F 3BDH000368R0001 is configured via ABB Control Builder M software, which supports GSDML files for PROFIBUS DP slave setup. Its plug-and-play design and online firmware updates minimize downtime during system upgrades, while the compact form factor and tool-free installation reduce deployment complexity.
Rugged Design: Engineered for industrial environments, the module withstands extreme temperatures, humidity, and electromagnetic interference (EMI). Its IP20 protection class ensures reliable operation in indoor control cabinets, while the rugged enclosure meets the demands of harsh industrial settings.
Application Areas
Process Automation: The ABB CM772F 3BDH000368R0001 plays a pivotal role in petrochemical, pharmaceutical, and food & beverage plants, connecting field devices like valves, analyzers, and drives to the Advant 800xA DCS. Its PROFIBUS DP V1 support enables real-time data exchange for precise process control and optimization.
Power Generation: In power plants, the module integrates intelligent electronic devices (IEDs), such as protection relays and meters, into a centralized control system. Its redundant communication capabilities ensure reliable grid stability and efficient energy management.
Machine Automation: For manufacturing lines, the CM772F 3BDH000368R0001 connects PLCs, robots, and sensors via PROFIBUS DP, enabling high-speed coordination for motion control and assembly processes. Its deterministic communication ensures synchronization between devices with microsecond-level precision.
Oil & Gas: In offshore platforms and refineries, the module supports the integration of distributed I/O systems, SCADA systems, and safety-related devices. Its rugged design and wide temperature range make it suitable for harsh offshore environments.
Water & Wastewater Treatment: The module facilitates the integration of pumps, actuators, and flow meters into a unified control system, ensuring efficient monitoring and operation of water treatment plants. Its redundancy capabilities enhance system reliability in critical infrastructure applications.
Related Products
- CM772F A3 3BDH000368R0001: An enhanced version of the CM772F 3BDH000368R0001 with extended temperature range and additional diagnostic features, suitable for extreme industrial environments.
- CI868K01-eA: An Ethernet/IP communication module for multi-protocol integration, often used alongside the CM772F in hybrid network architectures.
- AI835 3BSE008520R1: A thermocouple input module for temperature monitoring, complementing the CM772F in energy and HVAC systems.
- AC 800M CPU Modules: Central processing units that work with the CM772F to execute control logic and manage communication traffic in Advant 800xA systems.
- DO820 3BSE008514R1: A digital output module for controlling actuators, often paired with the CM772F in process automation.
Installation and Maintenance
Installation Preparation:
Ensure the power supply is disconnected and the environment meets the CM772F 3BDH000368R0001’s operating requirements (temperature: -40°C to +70°C; altitude: ≤2000m). Mount the module on a DIN rail using the TP867 baseplate (required for AC 800M systems), ensuring secure PROFIBUS DP and power connections. Configure the module via ABB Control Builder M, assigning PROFIBUS DP addresses and protocol settings according to the network topology.
Ensure the power supply is disconnected and the environment meets the CM772F 3BDH000368R0001’s operating requirements (temperature: -40°C to +70°C; altitude: ≤2000m). Mount the module on a DIN rail using the TP867 baseplate (required for AC 800M systems), ensuring secure PROFIBUS DP and power connections. Configure the module via ABB Control Builder M, assigning PROFIBUS DP addresses and protocol settings according to the network topology.
Maintenance Advice:
Regularly inspect the module’s status indicator lights to detect 异常. Clean dust from the surface to maintain optimal thermal performance. For firmware updates, use the online upgrade feature to avoid system downtime. In case of persistent errors, consult the troubleshooting guide or contact ABB’s technical support for assistance. Replace the module if physical damage or irreparable faults occur, ensuring compatibility with the CM772F A3 or other related products.
Regularly inspect the module’s status indicator lights to detect 异常. Clean dust from the surface to maintain optimal thermal performance. For firmware updates, use the online upgrade feature to avoid system downtime. In case of persistent errors, consult the troubleshooting guide or contact ABB’s technical support for assistance. Replace the module if physical damage or irreparable faults occur, ensuring compatibility with the CM772F A3 or other related products.
Product Guarantee
ABB stands behind the CM772F 3BDH000368R0001 with a 1-year warranty covering defects in materials and workmanship. The module undergoes rigorous testing to ensure compliance with industry standards, and ABB’s global support network provides prompt technical assistance for installation, configuration, and repairs. By choosing the CM772F 3BDH000368R0001, customers gain access to ABB’s decades of expertise in industrial automation, ensuring long-term reliability and performance.
