Product Overview
The ABB CI867A is a high – performance Ethernet communication module designed for industrial automation systems, belonging to the AC 800M controller family of ABB’s System 800xA1. It serves as a crucial communication interface, enabling seamless connection between the AC 800M controller and external Ethernet devices through the Modbus TCP protocol1. The module combines advanced communication technology with stable performance, supporting hot – swap and redundant settings, which ensures high availability and reliability of the system2. As a single – channel Ethernet unit, Ch1 of the CI867A supports full – duplex communication at a speed of 100 Mbps, capable of quickly and accurately transmitting large amounts of data1. In addition, it supports both master and slave functions, facilitating efficient device – to – device communication in complex industrial automation networks2.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CI867A |
| Manufacturer | ABB |
| Product Type | Communication Module |
| Communication Protocol | MODBUS TCP |
| Number of Channels | 1 channel |
| Transmission Speed | 10/100 Mbit/s (Ch1) |
| Module Redundancy | Yes |
| Hot Swap | Yes |
| Max Units on CEX Bus | 12 |
| Connector | RJ – 45 female (8 – pin) |
| Temperature, Operating | +5 to +55 °C (+41 to +131 °F) |
| Temperature, Storage | -40 to +70 °C (-40 to +158 °F) |
| Altitude | 2000 m according to IEC/EN 61131 – 2 |
| Protection Class | IP20 according to EN60529, IEC 529 |
| Width | 59 mm (2.3 in.) |
| Height | 185 mm (7.3 in.) |
| Depth | 127.5 mm (5.0 in.) |
Main Features and Advantages
- High Reliability: The CI867A supports redundant configuration and hot – swap functionality1. In the event of a module failure, the redundant module can take over immediately, minimizing system downtime. Hot – swap allows for module replacement without shutting down the system, ensuring continuous operation.
- High – Speed Data Transmission: With a single – channel Ethernet design and Ch1 supporting full – duplex communication at 100 Mbps, it can quickly and accurately transmit large volumes of data, meeting the real – time and accuracy requirements of industrial automation systems1.
- Strong Connectivity: It supports both master and slave functions, and each module can be connected to up to 70 slave devices and 8 master devices, enabling it to handle complex industrial automation network topologies with ease1.
- Wide Compatibility: The module is compatible with System 800xA 6.0.3.3, 6.1.1, and subsequent versions, ensuring seamless integration and stable operation within ABB’s automation system1.
Application Areas
The ABB CI867A is widely used in various industrial automation scenarios. In the manufacturing industry, it is used to connect production equipment, such as robots, conveyors, and CNC machines, to the central control system, enabling real – time monitoring and control of the production process. In the process industry, it can be used to connect field – based instruments, such as sensors and actuators, to the distributed control system (DCS), facilitating the collection and transmission of process data. In the power industry, it is applied to connect power generation equipment, power grid monitoring devices, and control systems, helping to improve the reliability and efficiency of power generation and distribution. Moreover, in smart building automation systems, the CI867A can be used to connect various subsystems, such as lighting, air – conditioning, and security systems, to achieve integrated management and intelligent control.
Related Products
- AI845 3BSE023675R1: An input module, which is often used in conjunction with the CI867A to collect analog input signals in industrial automation systems.
- AI835 3BSE008520R1: An 8 – channel thermocouple/mV analog input module, used to interface with temperature – sensing devices and provide temperature data to the control system.
- AI625 3BHT300036R1: A 4 – 20 mA sensor power supply module that can supply power to sensors and is related to the data acquisition and processing of the CI867A in industrial applications.
- AI05A: A 2 – channel isolated log input module, which can be used to input specific types of digital signals and is part of the overall signal – processing chain with the CI867A.
- AI04: A 16 – channel analog input module for Symphony Plus, often used in combination with the CI867A to handle a large number of analog input signals in complex automation systems.
Installation and Maintenance
Installation – preparation: Before installing the ABB CI867A module, ensure that the power supply is off and the working environment meets the requirements, with the temperature ranging from +5 to +55 °C and the altitude within 2000 m1. Check that the CEX – Bus is properly connected and that the Ethernet switch is configured correctly. Clean the installation location to prevent dust and debris from affecting the module’s operation.
Maintenance – advice: Regularly check the operating status of the CI867A module, including indicator lights and temperature. Clean the module’s surface regularly to prevent dust accumulation. If a problem is detected, refer to the product manual for troubleshooting or contact ABB’s technical support. During system upgrades, ensure that the module’s firmware is updated in a timely manner to ensure compatibility and performance.
Product Guarantee
ABB provides a high – quality guarantee for the CI867A product. The product comes with a one – year warranty from the date of purchase. During the warranty period, if there is a quality problem with the product, ABB will repair or replace it free of charge. ABB also offers comprehensive after – sales service and technical support, with a professional team available to provide technical advice and troubleshooting guidance to customers at any time, ensuring the stable operation of the product in industrial applications.
