Product Overview
The ABB CI854BK01 is a PROFIBUS-DP/V1 communication interface module designed for industrial automation systems, providing high-speed, reliable connectivity between distributed control systems (DCS) and field devices. As part of ABB’s AC 800M series, this module serves as a critical component in process control applications, enabling seamless integration of remote I/O, drives, and intelligent devices with higher-level automation platforms.
The CI854BK01 supports PROFIBUS DP-V1 protocol with 9.6–12,000 kbit/s transmission speeds, ensuring real-time data exchange for precise control and monitoring. Its dual-port architecture enables line redundancy, while master redundancy (via two CI854BK01 modules) enhances system reliability in mission-critical environments 6. The module features a compact design (59 mm x 185 mm x 127.5 mm) and DIN rail mounting, facilitating easy installation in space-constrained control cabinets. With an operating temperature range of +5°C to +55°C and IP20 protection rating, the CI854BK01 is suitable for use in harsh industrial settings, including power generation, oil/gas processing, and water treatment plants 6.
Engineered for flexibility, the CI854BK01 is compatible with ABB’s System 800xA 6.0.3.2 and later, supporting integration with S800 I/O subsystems and third-party devices. Its hot-swappable capability allows module replacement without system downtime, minimizing maintenance disruptions. The module includes built-in surge protection and EMC compliance, ensuring stable performance in electrically noisy environments 6.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CI854BK01 |
| Manufacturer | ABB |
| Product Type | PROFIBUS-DP/V1 Communication Interface Module |
| Communication Protocol | PROFIBUS DP-V1 |
| Transmission Speed | 9.6–12,000 kbit/s |
| Ports | 2 x RS-485 (DB9 female connectors) |
| Line Redundancy | Yes |
| Master Redundancy | Yes (requires two CI854BK01 modules) |
| Power Supply | 24 V DC ±10% |
| Power Consumption | Typ. 190 mA |
| Operating Temperature | +5°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP20 |
| Dimensions | 59 mm (W) x 185 mm (H) x 127.5 mm (D) |
| Weight | 700 g (including baseplate) |
| Compliance Standards | CE, ROHS, IEC 61131-2 |
Main Features and Advantages
- High-Speed PROFIBUS Connectivity: The CI854BK01 delivers 12 Mbit/s data transfer for real-time control of field devices, including drives, sensors, and PLCs. Its PROFIBUS DP-V1 support enables advanced diagnostics and parameterization, reducing troubleshooting time 6.
- Redundancy for Critical Operations: Dual-port line redundancy and master redundancy (via two CI854BK01 modules) ensure continuous operation in applications where downtime is unacceptable, such as power generation and oil/gas production 6.
- Scalable Integration: Seamlessly integrates with ABB’s S800 I/O series and AC 800M controllers, supporting up to 12 units on the CEX bus. This scalability allows cost-effective expansion of automation systems 6.
- Hot-Swap Capability: Modules can be replaced without system shutdown, enabling maintenance during live operations. This feature is critical for industries requiring 24/7 uptime, such as water treatment and manufacturing 6.
- Compact and Rugged Design: DIN rail mounting and IP20 protection make the CI854BK01 suitable for harsh environments. Its G3 corrosion resistance ensures long-term reliability in chemically aggressive settings 6.
Application Areas
- Power Generation: Manages turbine control, generator monitoring, and grid synchronization in thermal and renewable energy plants. The CI854BK01 ensures real-time communication between DCS systems and protective relays, enhancing grid stability 6.
- Oil and Gas: Optimizes wellhead pressure control, pipeline monitoring, and refinery processes. Its PROFIBUS DP-V1 connectivity facilitates integration with flow meters, safety systems, and distributed I/O, ensuring compliance with environmental regulations 6.
- Water Treatment: Controls pump and valve operations in wastewater treatment plants. The CI854BK01’s redundancy features minimize downtime during filtration and disinfection processes 6.
- Manufacturing: Drives CNC machines, conveyor belts, and robotic arms in automotive and electronics production. Its high-speed data transfer ensures precise motion control and synchronization, improving production efficiency 6.
- HVAC Systems: Monitors temperature, humidity, and airflow in smart buildings. The CI854BK01 supports integration with building automation systems for energy-efficient climate control 6.
Related Products
- ABB CI854B: Similar PROFIBUS-DP/V1 interface module with dual-port redundancy and hot-swap capability, ideal for large-scale industrial applications 6.
- ABB TP854: Baseplate for the CI854BK01, providing mechanical support and power distribution 6.
- ABB LD800P: PROFIBUS PA linking device for connecting fieldbus instruments to the CI854BK01, expanding system compatibility with Foundation Fieldbus devices 6.
- ABB AC 800M Controller: Central control platform for distributed systems, compatible with the CI854BK01 for advanced logic processing and data analytics 6.
- ABB S800 I/O Series: Modular I/O system for scalable automation solutions, supporting seamless integration with the CI854BK01 for analog/digital signal acquisition 6.
- ABB 800xA Extension Modules: Enhance system capabilities in ABB’s distributed control framework, enabling integration with the CI854BK01 for advanced process optimization 6.
Installation and Maintenance
Installation:
- Mount the CI854BK01 on a DIN rail using the TP854 baseplate, ensuring proper grounding. Connect 24 V DC power and PROFIBUS cables using terminal blocks, securing tight connections to prevent signal loss. Configure the module using ABB’s Automation Builder software to set communication parameters and enable redundancy features 6.
Maintenance:
- Regularly inspect the module for physical damage and clean dust from the enclosure. Use ABB’s diagnostic tools to monitor PROFIBUS communication status and perform quarterly firmware updates. Replace faulty modules with ABB-approved spares to maintain system reliability. For critical applications, consider ABB’s extended warranty plans for priority support and replacement services 6.
Product Guarantee
ABB guarantees the CI854BK01 against defects in materials and workmanship for 1 year from the date of purchase. ABB’s global service network provides 24/7 technical support, including remote troubleshooting, on-site maintenance, and firmware updates. Extended warranty plans (up to 5 years) are available for mission-critical applications, covering parts, labor, and priority service 6.
Brand Model: ABB CI854BK01
Product Name: PROFIBUS-DP/V1 Communication Interface Module
Warranty: 1 year
Size: 59 mm (W) x 185 mm (H) x 127.5 mm (D)
Weight: 700 g
Origin: Sweden
Inventory: Spot/Futures
Delivery Time: Goods in stock will be dispatched within 3 days after payment
Order Time: Goods will be dispatched within one month after payment
Product Name: PROFIBUS-DP/V1 Communication Interface Module
Warranty: 1 year
Size: 59 mm (W) x 185 mm (H) x 127.5 mm (D)
Weight: 700 g
Origin: Sweden
Inventory: Spot/Futures
Delivery Time: Goods in stock will be dispatched within 3 days after payment
Order Time: Goods will be dispatched within one month after payment
