ABB CI570 3BSE001440R1 | AF100 Communication Interface for Advant Controller 400

Description

1. Product Overview

The ABB CI570 (3BSE001440R1) is a high-performance Communication Interface Module designed for the Advant OCS control system. It serves as the primary gateway for Advant Fieldbus 100 (AF100) communication, enabling the Advant Controller 400 (AC 450 and AC 410) to exchange data with remote I/O stations (S800 or S100 I/O) and other Advant controllers.

The CI570 module is critical for maintaining high-speed, deterministic data transmission in complex industrial environments. Its robust design ensures that process control signals and diagnostic data are delivered with microsecond precision, making it a cornerstone for large-scale power plants, chemical refineries, and metal processing facilities.

Key Applications:

• Distributed Control Systems (DCS): Establishing reliable communication backbones for Advant OCS platforms.
• Remote I/O Management: Connecting central AC 450 controllers to distributed S800 I/O clusters via AF100.
• System Redundancy: Often used in redundant pairs to ensure zero-downtime communication for critical process loops.
• Industrial Network Upgrades: A vital component for extending the life of existing Advant Controller 400 installations.

2. Data Sheet

导出到 Google 表格

3. Procurement Process

1. Technical Matching: We verify the CI570 3BSE001440R1 hardware version to ensure it is compatible with your Advant OCS software revision.
2. Formal Quotation: Receive a detailed quote including competitive pricing, current stock status, and global express shipping rates.
3. Order Confirmation: Finalizing quantities and any required certifications (e.g., Certificate of Origin, COO).
4. Sales Agreement: Issuance of a Proforma Invoice (PI) for secure transaction management.
5. Secure Payment: Payment accepted via T/T (Bank Wire Transfer).
6. Quality Inspection: 100% verification of ABB factory seals, serial numbers, and physical connector integrity.
7. Professional Packaging: Anti-static and shock-proof packaging designed for safe international air freight.
8. Global Distribution: Fast worldwide shipping via DHL, FedEx, or UPS to your facility in the UAE, Kazakhstan, Bahrain, and beyond.

4. Products Showcase (Photos & Video)

5. Related Models

• ABB CI531 (S100 I/O Bus Communication)
• ABB PM450 / PM410 (AC 400 Series Processor Modules)
• ABB CI522 / CI522A (Modbus Communication Interface)
• ABB TC512 / TC516 (AF100 Bus Modems)
• ABB S800 I/O Series (Compatible Remote I/O Modules)

6. Warranty & After-Sales

• 12-Month Global Warranty: Full 1-year coverage against any manufacturing or functional defects.
• 100% Authenticity Guaranteed: We supply only genuine, factory-new ABB parts; no refurbished or high-copy units.
• Expert Support: Professional guidance for hardware replacement and AF100 bus termination troubleshooting.

7. FAQ

Q: Can the CI570 be hot-swapped?

While the Advant Controller 400 is robust, it is generally recommended to follow the system-specific “Hot-Swap” procedure outlined in the ABB Advant OCS manual to prevent any communication interruptions on the AF100 bus.

Q: What is the difference between CI570 and CI522?

The CI570 is dedicated to AF100 fieldbus communication (connecting controllers and I/O), while the CI522 is typically used for Modbus serial communication with third-party devices.

Q: Does this module require a separate power supply?

No, the CI570 draws its operational power directly from the Advant Controller 400 backplane (submodule slot).
