Description
Product Overview
The ABB AI895 is a high-performance 8-channel analog input module designed for industrial automation systems, specifically engineered for applications requiring precise signal conditioning and HART communication capabilities. Belonging to ABB’s S800 I/O series, this module serves as a critical component in distributed control systems (DCS) and process automation platforms, enabling seamless integration with controllers such as the AC 800M. Its core function is to convert analog signals from field devices (e.g., pressure transmitters, temperature sensors) into digital data for real-time monitoring and control .
Key to the ABB AI895’s value is its dual-mode signal handling—supporting both 4–20 mA current loops and voltage inputs while maintaining HART protocol compatibility. This allows it to interface with 2-wire transmitters in hazardous areas, providing power to the device while simultaneously acquiring measurement data. The module’s intrinsic safety certification (ATEX/IECEx) ensures safe operation in explosive environments, making it ideal for oil & gas, chemical, and pharmaceutical industries .
With 12-bit resolution and ±0.1% accuracy, the ABB AI895 delivers reliable measurements even in high-noise environments. Its configurable input filter (0–140 ms rise time) and diagnostic capabilities (over/undervoltage detection, open-circuit monitoring) minimize false alarms and reduce downtime. The module’s compact form factor (45 mm width) and DIN rail mounting further enhance its suitability for space-constrained installations .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | ABB AI895 |
| Manufacturer | ABB |
| Product Type | 8-channel Analog Input Module with HART Interface |
| Input Signal Types | 4–20 mA, ±10 V, thermocouples (B/E/J/K/N/R/S/T), RTDs (PT100/PT200/PT500/PT1000) |
| Resolution | 12 bits |
| Accuracy | ±0.1% of full scale |
| Communication Protocol | HART (via built-in modem), supports Profibus DP/Modbus TCP via optional modules |
| Isolation | 500 V AC RMS (channel-to-ground) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Power Supply | 24 VDC ±10% |
| Dimensions (WxHxD) | 45 mm x 119 mm x 102 mm |
| Weight | 0.2 kg |
| Certifications | ATEX/IECEx (Zone 2), CE, UL 508, RoHS |
Key Features and Advantages
HART-Enabled Smart Sensing:
The ABB AI895 integrates a HART modem for bidirectional communication with smart transmitters, allowing remote configuration, calibration, and diagnostic data retrieval without disrupting the process. This feature reduces maintenance costs by enabling predictive analytics and proactive fault resolution .
The ABB AI895 integrates a HART modem for bidirectional communication with smart transmitters, allowing remote configuration, calibration, and diagnostic data retrieval without disrupting the process. This feature reduces maintenance costs by enabling predictive analytics and proactive fault resolution .
Rugged Design for Harsh Environments:
With ATEX/IECEx certification, the module withstands extreme temperatures (0°C to +55°C) and corrosive conditions (ISA-S71.04 G3), ensuring reliable operation in offshore platforms, refineries, and other hazardous locations. Its vibration/shock resistance (IEC 60068-2-6/27) further enhances durability in high-vibration environments .
With ATEX/IECEx certification, the module withstands extreme temperatures (0°C to +55°C) and corrosive conditions (ISA-S71.04 G3), ensuring reliable operation in offshore platforms, refineries, and other hazardous locations. Its vibration/shock resistance (IEC 60068-2-6/27) further enhances durability in high-vibration environments .
Flexible Configuration:
The module supports user-configurable input ranges (e.g., 4–20 mA, ±10 V) and programmable filters, adapting to diverse sensor types and application requirements. It also allows redundant power supply connections for mission-critical systems, ensuring continuous operation in the event of a power failure .
The module supports user-configurable input ranges (e.g., 4–20 mA, ±10 V) and programmable filters, adapting to diverse sensor types and application requirements. It also allows redundant power supply connections for mission-critical systems, ensuring continuous operation in the event of a power failure .
Easy Integration:
As part of the S800 I/O series, the ABB AI895 seamlessly integrates with ABB’s 800xA DCS and third-party controllers via industry-standard protocols like Profibus DP and Modbus TCP. Its plug-and-play compatibility with TU890/TU891 terminal units simplifies installation, reducing commissioning time by up to 30% .
As part of the S800 I/O series, the ABB AI895 seamlessly integrates with ABB’s 800xA DCS and third-party controllers via industry-standard protocols like Profibus DP and Modbus TCP. Its plug-and-play compatibility with TU890/TU891 terminal units simplifies installation, reducing commissioning time by up to 30% .
Application Areas
Process Industries:
In oil & gas refineries and chemical plants, the ABB AI895 monitors pressure, temperature, and flow rates from field transmitters, enabling precise control of reactors, distillation columns, and pipelines. Its HART capability supports real-time diagnostics of smart devices, optimizing maintenance schedules and minimizing unplanned downtime .
In oil & gas refineries and chemical plants, the ABB AI895 monitors pressure, temperature, and flow rates from field transmitters, enabling precise control of reactors, distillation columns, and pipelines. Its HART capability supports real-time diagnostics of smart devices, optimizing maintenance schedules and minimizing unplanned downtime .
Power Generation:
For steam turbines and power substations, the module interfaces with RTDs and thermocouples to monitor temperature gradients, ensuring efficient energy production and compliance with safety standards. Its intrinsic safety features make it suitable for gas turbine control systems in explosive environments .
For steam turbines and power substations, the module interfaces with RTDs and thermocouples to monitor temperature gradients, ensuring efficient energy production and compliance with safety standards. Its intrinsic safety features make it suitable for gas turbine control systems in explosive environments .
Pharmaceutical and Food Processing:
In cleanroom environments, the ABB AI895 measures critical parameters like pH and conductivity, ensuring product quality and regulatory compliance. Its compact design allows easy integration into modular processing skids, supporting batch-to-batch traceability .
In cleanroom environments, the ABB AI895 measures critical parameters like pH and conductivity, ensuring product quality and regulatory compliance. Its compact design allows easy integration into modular processing skids, supporting batch-to-batch traceability .
Water/Wastewater Treatment:
The module monitors dissolved oxygen levels and pump performance in wastewater treatment plants, enabling predictive maintenance and energy-efficient operations. Its wide temperature range (-40°C to +70°C) ensures reliable performance in outdoor and submersible applications .
The module monitors dissolved oxygen levels and pump performance in wastewater treatment plants, enabling predictive maintenance and energy-efficient operations. Its wide temperature range (-40°C to +70°C) ensures reliable performance in outdoor and submersible applications .
Related Products
-
TU890/TU891 Terminal Units:
Required for physical installation, these units provide signal termination and power distribution for the ABB AI895, with TU890 designed for hazardous areas and TU891 for general use . -
PM864AK02 Processor Module:
A complementary controller for Symphony Plus DCS systems, enabling real-time data processing and integration with the ABB AI895 . -
AI830A Analog Input Module:
A cost-effective alternative for non-hazardous areas, offering 8 channels for RTD and thermocouple inputs without HART functionality . -
AO895 Analog Output Module:
Works in tandem with the ABB AI895 to provide closed-loop control, supporting 4–20 mA outputs with HART compatibility . -
CI857 Communication Interface Module:
Enables Profibus DP connectivity for the ABB AI895, expanding its integration capabilities with legacy PLC systems .
Installation and Maintenance
Installation:
- Mounting: Secure the ABB AI895 on a 35 mm DIN rail using M4 screws, ensuring alignment with TU890/TU891 terminal units. Connect shielded cables for analog inputs and HART signals, adhering to IEC 61850 cabling standards .
- Configuration: Use ABB Freelance Engineering Software to set input ranges, filter parameters, and HART communication settings. Verify module status via front-panel LEDs (Fault, Run, Warning) .
- Power Supply: Connect 24 VDC power to the module and terminal unit, ensuring proper polarity and fuse protection (1.5 A fast-blow) .
Maintenance:
- Routine Checks: Inspect terminal connections quarterly for corrosion and tightness. Clean dust from vents using compressed air to maintain thermal performance .
- Firmware Updates: Periodically update firmware via ABB System 800xA to access new features and security patches, ensuring compatibility with evolving industry standards .
- Redundancy Testing: For critical applications, pair the ABB AI895 with redundant processor modules (e.g., PM864AK02) and perform annual failover tests to validate system resilience .
Product Assurance
The ABB AI895 is backed by a 1-year warranty covering defects in materials and workmanship. ABB’s global network of authorized service centers provides expedited repairs and replacements, supported by 24/7 technical support for urgent issues. For mission-critical applications, ABB offers extended warranties (up to 5 years) and proactive maintenance plans, including annual system health checks to ensure compliance with safety standards .
As part of ABB’s zero-tolerance quality policy, the ABB AI895 undergoes rigorous testing to meet IEC 61508 SIL2 and UL 508 certifications, guaranteeing reliability in safety-critical environments. Customers benefit from prepaid shipping labels and express replacement programs, minimizing downtime and operational disruptions .
