Description
1. Product Overview
The ABB AI810 is a highly versatile 8-channel Analog Input Module designed for the S800 I/O distributed system. It provides a reliable interface between field sensors and the controller, typically used with the ABB AC 800M series.
Each of the 8 channels can be independently configured to measure either current (0/4…20 mA) or voltage (0…5/10 V), making it suitable for a wide range of industrial sensors like pressure transmitters, flow meters, and level gauges. The module features robust interference suppression and high-accuracy A/D conversion, ensuring precise data acquisition even in electrically noisy industrial environments.
Key Applications:
- General Process Control: Monitoring analog variables in chemical, pharmaceutical, and water treatment plants.
- Oil & Gas Operations: Real-time data collection from remote wellheads and processing facilities.
- Power Generation: Accurate measurement of turbine and boiler parameters.
- Factory Automation: Seamless integration of analog field devices into a centralized control architecture.
2. Data Sheet
| Feature | Technical Specification |
|---|---|
| Number of Channels | 8 Channels (Single-ended) |
| Input Signal Types | 0…20 mA, 4…20 mA, 0…5 V, 0…10 V |
| A/D Resolution | 12 bits |
| Input Impedance | 250 Ω (Current), >1 MΩ (Voltage) |
| Accuracy | Typ. ±0.1% of full scale |
| Isolation | Group-wise isolation from the I/O bus |
| Power Dissipation | Max 1.9 W |
| Mounting Requirement | Requires TU810, TU812, or TU814 Termination Unit |
3. Procurement Process
- Technical Validation: We confirm the AI810 (3BSE008516R1) revision to ensure full compatibility with your S800 I/O station.
- Formal Quotation: Receive a detailed quote featuring competitive pricing, lead time, and global shipping rates.
- Order Confirmation: Finalizing quantity and any required export documentation (e.g., Certificate of Origin).
- Sales Agreement: Issuance of a Proforma Invoice (PI) for secure transaction management.
- Secure Payment: Payment accepted via T/T (Bank Wire Transfer).
- Quality Inspection: 100% verification of factory seal, serial numbers, and physical integrity of the connector pins.
- Secure Packaging: Anti-static and shock-proof packaging designed for international transit.
- Global Distribution: Expedited shipping via DHL, FedEx, or UPS for minimal downtime.
4. Products Showcase (Photos & Video)
5. Related Models
- ABB AI625 (16-Channel Analog Output Module)
- ABB DI810 (16-Channel Digital Input Module 24V)
- ABB DO810 (16-Channel Digital Output Module 24V)
- ABB TU810 / TU812 (S800 Compact/Extended Termination Units)
- ABB CI801 / CI840 (Fieldbus Communication Interfaces)
6. Warranty & After-Sales
- 12-Month Global Warranty: Full replacement or repair coverage against manufacturing defects for one year.
- Guaranteed Originality: We only supply 100% brand-new, original ABB parts—no refurbished or used units.
- Expert Technical Support: Guidance on module configuration and troubleshooting within the ABB Compact Control Builder environment.
7. FAQ
Q: Can the AI810 power the 2-wire transmitters?
No, the AI810 does not provide transmitter power. The field sensors must be powered externally or through the power terminals on the corresponding termination unit (e.g., TU810).
Q: What is the difference between AI810 and AI815?
The AI810 has 8 channels, while the AI815 is a higher-density 8-channel module designed for HART communication. If you require HART pass-through for diagnostics, you should opt for the AI815 or AI845.
Q: Is the module hot-swappable?
Yes, the S800 I/O system supports Hot Configuration in Run (HCIR). The AI810 can be replaced while the system is powered, provided that the “Modulebus” is correctly configured and safety protocols are followed.
