Brand Model: ABB AI610
Product Name: Analog Input Module (SD Series I/O)
Warranty: 1 year
Size: 190 mm (depth) x 118 mm (height) x 34 mm (width)
Weight: 0.25 kg
Origin: Sweden
Inventory: Available (contact local distributors for stock levels)
Delivery Time: 3–5 business days for standard models; 3–5 weeks for custom configurations

Get a Quote
Category: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

The ABB AI610 is a high-performance analog input module designed for industrial automation systems, particularly as part of ABB’s Symphony Plus and 800xA distributed control systems (DCS). It is engineered to handle a wide range of analog signals with precision and reliability, making it ideal for applications requiring real-time data acquisition in harsh industrial environments. Below is a comprehensive overview based on verified technical insights and industry context:

Product Overview

The ABB AI610 (Hardware ID: AI610, Order Code: 1SFL577001R7011) is categorized as an SD Series I/O module within the Symphony Plus platform. It supports 32 individually configurable channels for voltage (±10 V DC), current (4–20 mA), and temperature (RTD/thermocouple) inputs, enabling seamless integration with various sensors and transmitters 2324. Key applications include oil & gas, power generation, chemical processing, and manufacturing, where high accuracy and environmental resilience are critical.



This module features group isolation (1×32 channels) with 1500 V galvanic isolation to protect against electrical noise and surges. Its hot-swappable design allows maintenance without system downtime, while IP20-rated protection safeguards against dust and accidental contact. The AI610 interfaces with ABB’s Symphony Plus and 800xA control platforms, as well as third-party systems via PROFIBUS DP and Modbus RTU for distributed I/O integration 326.

Technical Specifications

Parameter Name Parameter Value
Product Model ABB AI610 (1SFL577001R7011)
Manufacturer ABB
Product Type Analog Input Module (SD Series I/O)
Input Channels 32 (individually configurable for ±10 V DC, 4–20 mA, RTD/thermocouple)
Resolution 16-bit with polarity
Accuracy ±0.1% of full-scale range (FSR)
Sampling Rate 1 ms per channel (multiplexed)
Isolation 1500 V galvanic isolation (field to logic), 1×32 group isolation
Power Supply 24 VDC ±10% (68 mA typical, 76 mA max)
Operating Temperature -20°C to +70°C
Storage Temperature -40°C to +85°C
Dimensions 190 mm (depth) x 118 mm (height) x 34 mm (width)
Weight 0.25 kg
Environmental Compliance IP20, IEC 61000-6-4 (EMC), ISA-S71.04 G3
Safety Certification CE, UL 508, RoHS
Mounting 35 mm DIN rail (horizontal/vertical orientation)

Key Features and Advantages

High Precision and Reliability:



  • 16-bit resolution ensures accurate measurement of analog signals, critical for applications like chemical reactor monitoring and power grid stabilization 23.
  • Automatic calibration eliminates manual adjustments, reducing setup time and errors.
  • Open circuit detection (≤5 seconds) and noise rejection (-70 dB normal mode, -90 dB common mode) enhance signal integrity in noisy environments 24.



Flexible Configuration:



  • 32 independent channels support mixed signal types (e.g., voltage, current, RTD) in the same module, minimizing hardware complexity 23.
  • Hot-swappable design allows module replacement without disrupting operations, improving system uptime 3.
  • Multi-protocol compatibility (PROFIBUS DP, Modbus RTU) enables integration with third-party PLCs and SCADA systems 26.



Robust Industrial Design:



  • Wide temperature range (-20°C to +70°C) and ISA-S71.04 G3 corrosion resistance make it suitable for extreme environments, such as offshore platforms and mining sites 29.
  • IP20 protection and vibration/shock resistance (IEC 60068-2-6/27) ensure reliability in rugged industrial settings.



Efficient Maintenance:



  • Front-panel LEDs provide real-time status monitoring (RUN/FAULT), simplifying troubleshooting.
  • Mini USB interface allows local configuration and diagnostics without additional tools.
  • Reduced downtime through proactive diagnostics and modular design, minimizing maintenance costs.

Application Areas

  1. Oil & Gas:
    • Monitoring pressure/flow in pipelines and controlling compressor stations. PROFIBUS DP integration enables real-time diagnostics of smart transmitters in offshore platforms 26.
  2. Power Generation:
    • Optimizing steam turbine control and boiler management. The module’s high accuracy supports precise energy output regulation 24.
  3. Chemical & Petrochemical:
    • Controlling reactor processes and distillation units. Corrosion-resistant design ensures stability in chemical plants 23.
  4. Water & Wastewater:
    • Regulating pump stations and water treatment systems. Analog inputs interface with flow meters and pH sensors, while HART communication enables remote calibration.
  5. Manufacturing:
    • Managing robotics and conveyor systems in automotive production. High-speed sampling supports synchronization with PLCs and SCADA systems 24.

Related Products

  1. HBS01-FPH/VBS01-EPD Mounting Bases: Required for physical installation of the AI610, providing power and signal connections 21.
  2. PM864AK02 Processor Module: Complementary controller for Symphony Plus, enabling real-time data processing.
  3. DI02 High-Voltage Digital Input Module: Supports 125 VDC/120 VAC signals with SOE functionality for safety-critical applications.
  4. Symphony Plus DCS Platform: ABB’s integrated control system fully compatible with the AI610.
  5. Freelance Engineering Software: Configures the module’s parameters and diagnostics for optimized performance.

Installation and Maintenance

Installation:



  • Mounting: Secure on a 35 mm DIN rail using M4 screws, ensuring proper airflow. Use HBS01-FPH or VBS01-EPD bases for power and signal connections 21.
  • Wiring: Connect 24 VDC power and route shielded cables for analog inputs. Use TB801A terminal blocks for reliable signal termination.
  • Configuration: Use ABB Freelance Engineering to assign I/O addresses and select signal types. Enable diagnostics via the module’s front-panel LEDs.



Maintenance:



  • Routine Checks: Inspect terminal connections quarterly for tightness and corrosion. Clean dust from vents using compressed air.
  • Firmware Updates: Regularly update firmware via Freelance Engineering to access new features and security patches.
  • Redundancy Testing: For mission-critical systems, pair with redundant processor modules (e.g., PM864AK02) and perform annual failover tests.
  • Spare Parts Management: Maintain inventory of critical modules (e.g., AI610) to reduce downtime. ABB offers expedited delivery for urgent replacements.

Product Assurance

The ABB AI610 is backed by a 1-year warranty covering defects in materials and workmanship. ABB provides global technical support, including access to certified engineers and comprehensive documentation (e.g., datasheets, installation manuals). For mission-critical applications, ABB offers extended warranties (up to 5 years) and proactive maintenance plans, including annual system health checks to ensure compliance with safety standards 29.

HS:8443919090
