Description
Product Overview
The ABB ACU‑01 is a dedicated air control unit for ABB industrial painting robots. It executes closed‑loop regulation of shaping air and atomizing air for spray guns, monitors real‑time air pressure and flow parameters via built‑in sensors, and exchanges data with robot main controller through industrial bus. It ensures stable and repeatable painting parameters for automotive and general‑industry coating applications. This unit is widely used as spare‑part replacement for legacy ABB painting robot systems to maintain coating quality and production uptime.
Series
ABB Robot Painting Air Control Unit Series. This series includes ACU‑01 and upgraded ACU‑01B variants, designed for ABB IRB5400, IRB5500 and other painting robot models. The unit connects to robot controller, spray gun pneumatic circuit and plant compressed‑air supply to complete full‑automatic spraying‑air parameter adjustment.
Product Features
- Precise closed‑loop control for atomizing air and shaping‑air pressure & flow of robot spray guns
- Integrated pressure and flow sensors for real‑time pneumatic‑parameter monitoring
- Industrial bus communication for seamless data interaction with ABB robot controller
- Multiple independent pneumatic control channels for multi‑gun painting configuration
- Rugged metal housing, high protection grade, adapts to painting‑shop dusty & humid environment
- Built‑in hardware self‑diagnosis, detects air‑supply anomaly and internal module fault
- Front‑panel LED status indicators for fast on‑site troubleshooting
- Supports recipe‑based air‑parameter switching for different painting processes
Product Parameters
| Item | Parameter |
|---|---|
| Power Supply | 24 VDC |
| Communication Interface | CAN bus / Ethernet for robot controller |
| Pneumatic Supply Pressure | 5‑10.3 bar |
| Flow Sensor Measuring Range | 0‑1000 NI/min |
| Control Accuracy | ±2% of full scale |
| Protection Class | IP54 / IP65 option |
| Operating Temperature | 0°C ~ +55°C |
| Storage Temperature | -40°C ~ +70°C |
| Operating Humidity | 5‑95% RH, non‑condensing |
Product Specifications
- Unit Model：ACU‑01, part number 3HNA013719‑001
- Brand：ABB Robotics
- Series：Painting Robot Air Control Unit
- Weight：Approx.3.5 kg
- Dimension：160 × 125 × 200 mm (including pipe fittings)eero
Function
- Receive spraying‑air parameter commands from ABB robot controller
- Real‑time closed‑loop adjustment of atomizing air and shaping‑air pressure and flow
- Collect pneumatic sensor data and feed back real‑time status to robot system
- Detect compressed‑air supply failure and internal hardware fault, trigger alarm signal
- Store multiple groups of painting‑process air‑parameter recipes
- Provide stable pneumatic output for robot spray guns to guarantee coating‑surface quality
Purpose
Serve as pneumatic control core for ABB painting robots; replace defective original unit to restore normal spraying‑air adjustment function, guarantee stable painting quality and reduce paint‑material waste.
Application Fields
Automotive body painting workshop, auto‑parts coating, aerospace component spraying, general‑industry surface finishing, legacy ABB painting robot maintenance & retrofitting.
