Description
ABB 5SHY3545L0002 IGCT Module – Product Datasheet
Product Overview
Truth be told, the ABB 5SHY3545L0002 – a high-performance asymmetric Integrated Gate-Commutated Thyristor (IGCT) module – is a true standout in ABB’s premium 5SHY series of power semiconductor devices. It adopts advanced integrated gate-commutated technology, integrating GTO chips, anti-parallel diodes and gate drive circuits into a single highly integrated package. Boasting robust hard turn-off capability and snubberless turn-off characteristics, it excels in critical, high-performance scenarios such as high-power inverters, motor drives and traction systems.
This module is built on HiPak (High Power Package) technology, featuring a rugged yet compact structure. With dimensions of 439mm × 173mm × 41mm and a weight of 3.4kg, it maintains stable and consistent operation even under extreme electrical and thermal stress conditions. It is a true embodiment of ABB’s advanced technologies in the power semiconductor sector, masterfully combining the low on-state losses of thyristors with the stable turn-off capability of transistors to deliver an efficient solution for high-power applications. What’s more, its built-in SPT (Soft Punch Through) technology further optimizes electrical performance, ensuring consistent operation across a wide range of demanding industrial environments.
As an important member of the 5SHY series, the ABB 5SHY3545L0002 is specifically designed for high-voltage, high-current applications, laying a stable and reliable foundation for power control in various demanding industrial settings.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 5SHY3545L0002 |
| Manufacturer | ABB |
| Product Type | IGCT Module |
| Module Type | Asymmetric |
| Voltage Rating | 650V |
| Current Rating | 2000A |
| Mounting Force | 40kN |
| Snubberless Turn-Off | Yes |
| Technology Type | SPT (Soft Punch Through) |
| Package Type | HiPak (High Power Package) |
| Dimensions (L×W×H) | 439mm × 173mm × 41mm |
| Weight | 3.4kg |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP20-IP67 |
Key Features and Advantages
The ABB 5SHY3545L0002 stands out in high-power applications thanks to a host of impressive technical features. Its high power density design is a major highlight – within a compact footprint, it achieves a voltage handling capability of 650V and a current rating of 2000A, fully meeting the demands of the most rigorous high-power applications. Its snubberless turn-off technology directly addresses industry pain points, eliminating the need for complex snubber circuits, reducing the number of peripheral power components and significantly boosting system reliability.
High-efficiency performance is another core competitive advantage. Leveraging advanced SPT technology and a low-inductance connection design, the module achieves both low conduction losses and fast switching characteristics, directly driving a substantial improvement in overall system energy efficiency. The integrated gate drive design further optimizes switching performance, minimizing power loss during energy conversion and delivering clear advantages over traditional GTO devices.
What’s particularly commendable is its reliability-focused engineering. The module employs robust HiPak packaging technology and an optimized thermal management solution, enabling it to withstand harsh operating conditions such as high temperatures and humidity. This not only extends equipment service life but also ensures continuous, stable system operation. Its built-in hardware fault self-diagnosis function is a thoughtful addition, issuing timely alarm signals when faults occur to help maintenance personnel quickly locate and resolve issues.
Application Fields
The ABB 5SHY3545L0002 finds applications across multiple key areas of industrial automation and power systems. In the industrial drives sector, it serves as a core component in high-power inverters, motor drive systems and traction systems, providing stable and reliable power control solutions for equipment such as large motors, pumps, compressors and conveyor belts.
The power energy industry is also a key application area for this module. It plays a vital role in conversion, inversion and circuit-breaking systems for high-voltage power transmission, distribution stations and substations. Its high-reliability design makes it particularly suitable for critical infrastructure applications such as power grids.
In the renewable energy sector, it is ideally suited for high-power conversion systems in wind power generation and photovoltaic inverters, facilitating the efficient conversion and grid integration of clean energy. In addition, it excels in precision power control scenarios for high-power electric arc furnaces and heating furnaces in the metallurgical, chemical and steel industries, and also supports traction inversion and energy feedback systems in rail transit and marine applications, demonstrating diverse application potential.
Related Products
- 5SHY3545L0010: IGBT module in the same series, with high-voltage and high-current tolerance, suitable for frequency converters, inverters and other equipment
- 5SHY3545L0014: High-power IGCT module, rated voltage 4.5kV, rated current 3.5kA, suitable for medium-to-high voltage, high-current power systems
- 5SHY55L4500: ABB press-pack encapsulated IGCT, rated parameters 4.5kV/4kA, used for ultra-high voltage direct current transmission projects
- 5SHY3545L0009: Thyristor-type IGCT module in the same series, focused on power conversion and control applications
- 5SHY3545L0016: High-performance IGCT module, rated voltage 3500V, featuring TO-247 packaging
Installation and Maintenance
Pre-installation Preparation
Before installing the ABB 5SHY3545L0002, it is essential to ensure that the working environment meets the required conditions. The temperature and humidity of the control room should be maintained within a reasonable range, the stability of the power supply voltage must be carefully checked, and crucially, the module’s rated parameters must be fully matched with system requirements – this step should never be taken lightly. Installation personnel must possess relevant professional qualifications, be familiar with the operating procedures for high-voltage equipment, and use the correct tools and instruments during construction.
Installation Guidelines
Adopt standard rail or panel mounting methods, and sufficient heat dissipation space must be reserved around the module to avoid heat accumulation that could impact operation. Electrical wiring should use busbars or terminal blocks matching the rated voltage and current. Always confirm that the power supply is completely disconnected before wiring to prevent electric shock hazards. For systems requiring water cooling, properly connect the cooling circuit and ensure that the mounting force is strictly controlled within the 40kN range.
Maintenance Recommendations
Regularly monitor the module’s operating status, keep a close eye on the working temperature, and periodically check for loose terminals to avoid faults caused by poor contact. It is recommended to conduct a comprehensive functional test on the module every 12 months, replacing aging gate drive modules promptly when necessary. If the module needs to be stored for an extended period, it should be placed in a dry, dust-free environment and subjected to regular power-on testing to ensure it remains in good working condition at all times.
Product Assurance
ABB provides comprehensive quality assurance and after-sales service support for the 5SHY3545L0002. The product comes with a 12-month warranty from the date of manufacture, covering free repair or replacement for quality issues arising under normal usage conditions. Every module leaving the factory undergoes rigorous testing in compliance with international standards, ensuring that its performance and reliability meet the high standards required for industrial applications.
With a sound technical support system, ABB can provide customers with professional technical consultation and after-sales service, ensuring that customer inquiries are addressed and resolved promptly. Suppliers typically also commit to providing brand-new original products, safe and timely delivery guarantees, and professional after-sales technical support, comprehensively safeguarding the continuous and stable operation of customers’ systems.
