ABB 3BSE023316R1002 is a high-precision analog input module specifically engineered for seamless integration with ABB’s AC800M control system and System 800xA automation platform, serving as a critical component for real-time acquisition of continuous process data in industrial environments. This advanced module converts analog signals (such as 4-20 mA current or 0-10 V voltage) from sensors, transmitters, and transducers into digital data usable by central control systems, making ABB 3BSE023316R1002 an essential link between field-level measurement devices and supervisory control platforms. As a flagship offering in ABB’s analog I/O portfolio, ABB 3BSE023316R1002 delivers exceptional signal accuracy and reliability, ensuring precise monitoring of critical process variables like temperature, pressure, flow, and level. Its design prioritizes compatibility with ABB’s engineering tools and control systems, simplifying integration into both new installations and legacy upgrades, solidifying ABB 3BSE023316R1002 as a trusted solution for industries requiring precise analog data capture.
Technical Specifications
Parameter Name
Parameter Value
Product Model
ABB 3BSE023316R1002
Manufacturer
ABB
Product Type
High-Precision Analog Input Module
Number of Input Channels
8 isolated channels (configurable per channel)
Input Signal Types
4-20 mA (current), 0-10 V (voltage), ±10 V (differential)
Precision Data Acquisition: ABB 3BSE023316R1002 offers 16-bit resolution (0.0015% full scale) and low noise performance, ensuring accurate capture of even minor variations in analog signals—critical for applications where process precision directly impacts product quality or operational safety. This high accuracy eliminates measurement errors, enabling reliable control decisions and compliance with strict industry regulations.
Configurable Channel Flexibility: Each of the 8 isolated channels in ABB 3BSE023316R1002 can be independently configured for current or voltage inputs, supporting a wide range of field devices such as pressure transmitters, temperature sensors, and flow meters. This flexibility eliminates the need for multiple specialized modules, reducing system complexity and hardware costs while adapting to diverse application requirements.
Robust Isolation and Protection: ABB 3BSE023316R1002 features 500 VAC isolation between channels and ground, protecting the module and central control system from voltage spikes, electromagnetic interference, and cross-channel contamination common in industrial environments. Compliance with NAMUR NE 43 standards ensures compatibility with fault-tolerant sensor designs, enhancing system reliability.
Seamless ABB Ecosystem Integration: Designed exclusively for ABB’s AC800M control system and System 800xA platform, ABB 3BSE023316R1002 integrates seamlessly with ABB’s engineering tools (e.g., Control Builder M) and communication protocols. This compatibility simplifies configuration, calibration, and troubleshooting, reducing installation time and lowering operational costs for system integrators and plant operators.
Advanced Diagnostic Capabilities: ABB 3BSE023316R1002 provides real-time channel-level diagnostics, including open-circuit detection, overrange/underrange alerts, and sensor fault monitoring. These diagnostics enable proactive maintenance, rapid fault identification, and minimized downtime, ensuring continuous process visibility and operational continuity.
Application Fields
ABB 3BSE023316R1002 is a versatile analog input module tailored for industries where precise monitoring of continuous process variables is critical. In process manufacturing (chemical, pharmaceutical, and food and beverage), ABB 3BSE023316R1002 captures data from temperature, pressure, and pH sensors in batch reactors, mixing systems, and fermentation processes, ensuring adherence to production recipes and quality standards. The module’s high accuracy and noise immunity make it ideal for oil and gas facilities, where it monitors pipeline pressure, wellhead temperature, and flow rates in offshore platforms, refineries, and storage terminals.
In power generation facilities (coal-fired, gas, nuclear, and renewable), ABB 3BSE023316R1002 plays a key role in monitoring boiler steam pressure, turbine oil temperature, and generator output, enabling efficient energy production and grid stability. Water and wastewater treatment plants rely on ABB 3BSE023316R1002 to measure flow rates, dissolved oxygen levels, and chemical dosage concentrations, ensuring compliance with environmental regulations and optimal treatment efficiency.
Manufacturing industries, including automotive, aerospace, and semiconductor production, use ABB 3BSE023316R1002 to monitor machine tool vibrations, hydraulic pressure, and material thickness in precision manufacturing processes, supporting quality control and process optimization. Its configurable channels and seamless ABB integration make it a valuable asset for any application requiring reliable, high-precision analog data acquisition.
Related Products
ABB AC800M Controller (3BSC980004R784): Central processing unit optimized to interface with ABB 3BSE023316R1002 for real-time data processing and control.
ABB 3BSE004197R1 (DI810): 16-channel digital input module, complementary to ABB 3BSE023316R1002 for mixed analog/digital data acquisition in ABB control systems.
ABB 3BSE004199R1 (AO810): 8-channel analog output module, paired with ABB 3BSE023316R1002 to enable closed-loop control of actuators and valves.
ABB TU830V1 3BSE013234R1: I/O termination unit, designed to simplify wiring and provide surge protection for ABB 3BSE023316R1002 in distributed control setups.
ABB Control Builder M Software: Engineering tool specifically designed for configuring, calibrating, and diagnosing ABB 3BSE023316R1002 and associated ABB control system components.
ABB 3BSE030220R1: Surge protection module, enhancing ABB 3BSE023316R1002’s resilience to voltage transients in high-interference environments.
ABB 3BSE028142R1 (AI820): 16-channel analog input module, offering expanded capacity for large-scale applications requiring more channels than ABB 3BSE023316R1002.
ABB System 800xA I/O Base Unit (3BSE020556R1): Remote I/O base unit, enabling ABB 3BSE023316R1002 to be deployed in field locations for distributed data acquisition.
