Product Summary

Attribute Value
Brand Model 1TGB302004R5003
Product Name Frequency Converter Module
Warranty 1 year
Size 91.44 mm × 243.84 mm × 190.5 mm
Weight 2.09 kg
Origin Switzerland / China
Inventory Spot
Delivery Time 3 days after payment
Get a Quote
Category: Tags: Brand:
  • Need Help?
  • +86 18030182217
  • +86 18030182217
  • sandydcsplc@gmail.com
库存图标
100,000+ Models in Stock
保修图标
One-Year Warranty
响应图标
24h Fast Response

Description

Many products are not yet available—feel free to contact us for more options.

If there is a discrepancy between the product model and the displayed image, the model shall take precedence. For specific product photos, please reach out to us, and we will arrange on-site warehouse shots to confirm details.

With an extensive global warehouse network, there may be occasions where it takes a few hours to provide an accurate response. We appreciate your understanding, and rest assured we’ll address your inquiries as promptly as possible.

1TGB302004R5003 is a high-performance frequency converter module designed for industrial automation applications. As part of ABB’s ACS800 series, this compact yet powerful device delivers precise motor control and energy efficiency in demanding environments. Its advanced features and robust construction make it ideal for applications requiring reliable speed regulation, such as pumps, fans, and conveyor systems across industries like chemical processing, power generation, and water treatment.

Technical Specifications

Parameter Value
Product Model 1TGB302004R5003
Manufacturer ABB
Product Type Frequency Converter Module
Rated Current 2000 A
Rated Voltage 690 V AC
Weight 2.09 kg
Physical Dimensions 91.44 mm (depth) × 243.84 mm (height) × 190.5 mm (width)
Protection Level IP20
Operating Temperature -20°C to +70°C
Connection Capacity Supports up to 7 S800 cluster modems, each with 12 S800 I/O modules
Communication Interface Modbus RTU/TCP for Symphony Plus controller integration
Current Rating 30 A
Voltage Class 400 V AC
Modular Expansion Scalable I/O configuration for flexible system integration

Key Features and Advantages

High-Speed Processing: Equipped with a dual-core processor, the 1TGB302004R5003 ensures rapid response times for dynamic motor control, reducing energy consumption by up to 30% in variable-speed applications. Its advanced algorithms optimize torque and speed regulation, making it suitable for high-inertia loads like compressors and extruders.



Modular Design: The compact form factor (91.44 × 243.84 × 190.5 mm) allows easy installation in confined spaces, while the modular architecture supports field upgrades for additional I/O or communication protocols. This flexibility minimizes downtime during system expansions or retrofits.



Comprehensive Protection: Built-in safeguards against overcurrent, short circuits, and ground faults enhance operational safety, while the IP20-rated enclosure protects against dust and debris in harsh industrial environments. Redundant power supplies further ensure uninterrupted operation.



Multi-Protocol Connectivity: Native Modbus compatibility enables seamless integration with ABB’s Symphony Plus DCS and third-party systems, simplifying interoperability in multi-vendor setups. This reduces integration costs and streamlines maintenance workflows.



Energy Efficiency: By adjusting motor speed to match process demands, the 1TGB302004R5003 lowers energy consumption and extends equipment lifespan. Its regenerative braking capability recovers kinetic energy, further improving sustainability in applications like elevators and cranes.

Application Areas

The 1TGB302004R5003 excels in industries requiring precise motor control and energy optimization:



  • Water Treatment: Manages pump systems for filtration and wastewater processing, ensuring consistent flow rates while reducing energy costs.
  • Chemical Processing: Controls agitators and mixers in reactors, maintaining process stability and compliance with safety standards.
  • Power Generation: Regulates turbine auxiliary systems, enhancing grid synchronization and reducing wear on mechanical components.
  • Mining and Minerals: Drives conveyor belts and crushers, adapting speed to material flow and minimizing downtime.
  • HVAC Systems: Optimizes fan and chiller performance in commercial buildings, balancing comfort and energy efficiency.

Related Products

  1. ACS880-01-0014A-3: A next-generation drive with advanced diagnostics for complex industrial processes.
  2. 1TGB302004R5001: A lower-current variant (1000 A) for smaller-scale applications.
  3. 3AUA0000001379: A communication module for integrating the 1TGB302004R5003 with ABB’s industrial IoT platform.
  4. ACS580-01-01A3-4: A general-purpose drive for simple motor control in light manufacturing.
  5. 1TGB302004R5005: A high-voltage version (1000 V) for heavy-duty industrial environments.
