Description
Product Overview
The ABB 1SAJ520000R0101 UMC100-FBP.0 B3 is a high-performance universal motor controller designed for industrial applications requiring precise motor protection and control. Part of ABB’s UMC100 series, this compact device combines advanced motor protection features with flexible configuration options, making it ideal for applications in manufacturing, water treatment, and process industries. The UMC100-FBP.0 B3 supports motor currents up to 63 A and operates on a 24 V DC power supply, ensuring compatibility with a wide range of industrial motors.
Key to its functionality is the FBP (FieldBus Plug) interface, which enables seamless integration with fieldbus systems like PROFIBUS DP and Modbus RTU, allowing centralized monitoring and control12. The controller includes six 24 V DC digital inputs, three relay outputs, and one analog output, providing versatile connectivity for sensors, actuators, and HMIs. Its modular design supports expansion via DX122 I/O modules (e.g., 1SAJ622000R0101), which add 8 AC digital inputs and 4 relay outputs for complex automation setups12.
Engineered for reliability, the UMC100-FBP.0 B3 offers comprehensive motor protection, including phase failure detection, overload protection, and thermal monitoring. Its LCD operator panel (optional UMC100-PAN) allows local parameter adjustment and real-time diagnostics, while the AssetVision Basic configuration tool enables remote setup and firmware updates12. With an IP20-rated enclosure and wide temperature range (-20°C to 60°C), the controller withstands harsh industrial environments, ensuring long-term operational stability.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | ABB 1SAJ520000R0101 UMC100-FBP.0 B3 |
| Manufacturer | ABB |
| Product Type | Universal Motor Controller |
| Rated Current | 0.24–63 A (adjustable) |
| Power Supply | 24 V DC ±10% |
| Control Voltage | 24 V DC |
| Interfaces | 6 × Digital Inputs (24 V DC), 3 × Relay Outputs (230 V AC/1 A), 1 × Analog Output (0–10 V) |
| Fieldbus Support | PROFIBUS DP, Modbus RTU |
| Physical Dimensions | 70 mm (W) × 106 mm (H) × 107 mm (D) |
| Weight | 275 g |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Protection Class | IP20 |
| Certifications | CE, UL 508, IEC 60947-4-1/5-1 |
| Expansion Modules | DX122 (8 AC inputs, 4 relay outputs), VI150/VI155 (voltage protection) |
Key Features and Advantages
Comprehensive Motor Protection: The UMC100-FBP.0 B3 provides advanced protection against phase loss, overload, and thermal stress. Its adjustable trip classes (5E/10E/20E/30E/40E) allow customization for different motor types, while the remaining cooling time counter optimizes maintenance schedules12.
Flexible Connectivity: With FBP interface compatibility, the controller integrates with multiple fieldbus systems, simplifying integration into existing automation networks. The modular design supports expansion via AI111 analog input modules (up to 6 channels) for temperature monitoring using PT100 sensors12.
User-Friendly Configuration: The AssetVision Basic software enables remote parameter adjustment and diagnostics, while the optional LCD panel provides local access to real-time data, including motor current and fault history. This dual-mode operation enhances troubleshooting efficiency.
Rugged Design: Built with a IP20-rated enclosure and conformal coating, the controller resists dust, humidity, and electromagnetic interference. Its wide temperature range ensures reliable performance in extreme industrial environments.
Cost-Effective Operation: The UMC100-FBP.0 B3 reduces downtime through predictive maintenance features and supports energy-efficient motor control, aligning with Industry 4.0 initiatives.
Applications
The ABB 1SAJ520000R0101 UMC100-FBP.0 B3 is widely used in industries requiring reliable motor control and protection:
- Manufacturing: Managing conveyor systems, pumps, and compressors by integrating with PLCs and HMIs for centralized monitoring.
- Water/Wastewater: Controlling pumps and agitators in treatment plants, ensuring compliance with environmental standards through real-time flow and pressure monitoring.
- Oil & Gas: Protecting motors in offshore platforms and refineries by detecting abnormal conditions (e.g., vibration, temperature spikes) and triggering shutdowns.
- Food & Beverage: Ensuring hygienic operation of motors in packaging and processing lines through precise speed control and overload protection.
In each application, the UMC100-FBP.0 B3 acts as a critical component, balancing safety, efficiency, and operational continuity.
Related Products
- ABB UMC100.3-DC (1SAJ530000R0200): A newer version with ATEX certification, replacing the UMC100-FBP.0 B3 for hazardous environments.
- ABB DX122-FBP.0 (1SAJ622000R0101): An I/O expansion module adding 8 AC digital inputs and 4 relay outputs for complex control scenarios.
- ABB VI150-FBP (1SAJ622000R0201): A voltage protection module for grounded systems, enhancing safety in high-voltage applications.
- ABB AI111-FBP (1SAJ622000R0301): An analog input module supporting PT100 sensors for temperature monitoring in motors and processes.
- ABB UMC22-FBP (1SAJ510000R0100): A compact motor controller for smaller motors (up to 22 A), ideal for light-duty applications.
Installation and Maintenance
Installation Preparation:
Mount the UMC100-FBP.0 B3 on a 35 mm DIN rail in a well-ventilated enclosure. Connect the 24 V DC power supply and fieldbus cables, ensuring proper grounding. Use shielded cables for analog inputs to minimize interference. Configure parameters via AssetVision Basic or the optional LCD panel, setting motor current and trip class according to load requirements12.
Mount the UMC100-FBP.0 B3 on a 35 mm DIN rail in a well-ventilated enclosure. Connect the 24 V DC power supply and fieldbus cables, ensuring proper grounding. Use shielded cables for analog inputs to minimize interference. Configure parameters via AssetVision Basic or the optional LCD panel, setting motor current and trip class according to load requirements12.
Maintenance Recommendations:
- Firmware Updates: Regularly update firmware via AssetVision Basic to access new features and bug fixes.
- Sensor Calibration: Annually verify temperature sensors (e.g., PT100) using the controller’s diagnostics tools.
- Connection Checks: Inspect terminal connections quarterly for looseness or corrosion, tightening as needed.
- Environmental Checks: Clean dust from the enclosure and ensure ambient temperature remains within -20°C to 60°C.
Product Warranty and Support
The ABB 1SAJ520000R0101 UMC100-FBP.0 B3 comes with a 1-year warranty covering manufacturing defects. ABB’s global support network offers 24/7 technical assistance, including remote diagnostics and on-site repairs. Customers can access firmware updates, user manuals, and application notes through ABB’s online portal.
For mission-critical applications, extended warranties and maintenance contracts are available, providing priority service and replacement modules to minimize downtime. ABB-certified technicians also offer training on motor control configuration and safety compliance, ensuring optimal system performance.
Brand Model: ABB 1SAJ520000R0101 UMC100-FBP.0 B3
Product Name: Universal Motor Controller
Warranty: 1 year
Size: 70 mm (W) × 106 mm (H) × 107 mm (D)
Weight: 275 g
Origin: Sweden
Inventory: Spot
Delivery Time: Goods in stock will be dispatched within 3 days after payment
Order Time: Goods will be dispatched within one month after payment
Product Name: Universal Motor Controller
Warranty: 1 year
Size: 70 mm (W) × 106 mm (H) × 107 mm (D)
Weight: 275 g
Origin: Sweden
Inventory: Spot
Delivery Time: Goods in stock will be dispatched within 3 days after payment
Order Time: Goods will be dispatched within one month after payment
