Brand model: BENTLY 3500/93-03-01-00 Product Name: Display Interface I/O Module Warranty: 1 year Size: 241.3 mm x 24.4 mm x 99.1 mm Weight: 0.82 kg Origin: United States Inventory: Spot Delivery time: 3 days after payment
Many products are not yet available—feel free to contact us for more options.
If there is a discrepancy between the product model and the displayed image, the model shall take precedence. For specific product photos, please reach out to us, and we will arrange on-site warehouse shots to confirm details.
With an extensive global warehouse network, there may be occasions where it takes a few hours to provide an accurate response. We appreciate your understanding, and rest assured we’ll address your inquiries as promptly as possible.
Product Overview The BENTLY 3500/93-03-01-00 is a high-performance display interface I/O module designed for the BENTLY Nevada 3500 machinery protection system. As a critical component of the 3500 series, this module integrates real-time data visualization with configurable input/output capabilities, enabling seamless interaction between operators and rotating equipment such as turbines, compressors, and pumps. It supports API 670 compliance and interfaces with industrial control systems via protocols like Modbus RTU, CANopen, and DeviceNet.
Key functions include local/remote monitoring of machinery health parameters (vibration, temperature, speed), protocol conversion, and alarm management. The module features a rugged design with redundant power inputs and failsafe mechanisms, ensuring reliable operation in harsh environments (-40°C to 85°C). Its modular architecture allows for easy expansion, while advanced signal processing capabilities enable precise diagnostics and predictive maintenance strategies.
Equipped with a high-resolution LCD interface and configurable I/O channels, the BENTLY 3500/93-03-01-00 provides actionable insights through intuitive data visualization. This empowers operators to optimize maintenance schedules, reduce downtime, and enhance overall system efficiency.
Technical Specifications
Parameter Name
Parameter Value
Product Model
BENTLY 3500/93-03-01-00
Manufacturer
BENTLY Nevada
Product Type
Display Interface I/O Module
Power Supply
24V DC ±10%
Communication Protocols
Modbus RTU, CANopen, DeviceNet
Physical Dimensions
241.3 mm x 24.4 mm x 99.1 mm (H x W x D)
Weight
0.82 kg
Operating Temperature
-40°C to 85°C
Installation Method
19″ rack-mounted or panel-mounted
Input/Output Channels
4 analog inputs, 4 digital outputs
Redundancy Support
Dual power supply
Compliance
API 670, CE, ATEX
Main Features and Advantages Multi-Protocol Connectivity: The BENTLY 3500/93-03-01-00 supports industry-standard protocols, ensuring compatibility with diverse control systems. This flexibility simplifies integration into existing infrastructure, reducing implementation costs.
High Reliability: Built with redundant power paths and self-diagnostic capabilities, the module minimizes downtime and ensures continuous operation. Its rugged construction withstands extreme temperatures, vibrations, and electromagnetic interference.
User-Friendly Interface: The high-resolution LCD display provides real-time data visualization, while remote access via Ethernet allows for configuration and troubleshooting without physical intervention. This enhances operational efficiency and reduces maintenance efforts.
Scalable I/O Configuration: With 4 analog inputs and 4 digital outputs, the module accommodates sensor integration and control signaling. Its modular design supports expansion through additional I/O modules, making it suitable for both small-scale and large industrial applications.
Application Areas The BENTLY 3500/93-03-01-00 is widely used in industries requiring precise machinery monitoring:
Oil & Gas: Monitoring turbines, compressors, and pumps in offshore platforms and refineries.
Power Generation: Ensuring reliable operation of steam turbines, generators, and hydroelectric systems.
Manufacturing: Optimizing performance of conveyor systems, motors, and industrial robots.
Mining: Protecting crushers, conveyors, and milling equipment from excessive wear.
Its ability to interface with DCS and PLC systems makes it a versatile solution for process automation. By integrating with condition monitoring software, the module enables predictive maintenance strategies, extending equipment lifespan and reducing operational risks.
These products complement the BENTLY 3500/93-03-01-00 to form a comprehensive machinery protection system.
Installation and Maintenance Installation Preparation: Ensure the 3500 rack is securely grounded and powered. Connect the BENTLY 3500/93-03-01-00 to the designated slot using shielded cables to minimize interference. Verify power supply compatibility (24V DC) and configure communication parameters via the 3500 rack configuration software.
Maintenance Recommendations: Regularly inspect module status indicators for faults. Clean dust from vents to maintain optimal cooling. Perform firmware updates periodically to access new features and security patches. Replace worn cables as needed and ensure redundant power supplies are operational.
Product Warranty The BENTLY 3500/93-03-01-00 comes with a 1-year warranty covering defects in materials and workmanship. A dedicated technical support team provides 24/7 assistance for configuration, troubleshooting, and system integration. Spare parts are available for immediate dispatch, ensuring minimal downtime in case of component failure.
