Description
BENTLY 3500/05-02-04-00-00-00
Product Overview
The BENTLY 3500/05-02-04-00-00-00 is a 19-inch full-size system rack designed for Bently Nevada’s 3500 series machinery protection systems. As the foundational infrastructure for the 3500 platform, it provides a modular enclosure for housing monitoring modules, power supplies, and communication interfaces, ensuring seamless integration and reliable operation in industrial environments. This rack supports 14 module slots and is optimized for applications requiring high-density monitoring, such as power generation, oil & gas, and chemical processing .
Engineered with a rugged steel construction, the 3500/05-02-04-00-00-00 features a half-height form factor and IP54-rated enclosure, making it suitable for harsh conditions with dust, moisture, and vibration resistance. Its design aligns with API 670 standards for machinery protection systems, ensuring compliance with industry safety requirements. While compatible with legacy 3500 modules, it also supports newer iterations like the 3500/22M Transient Data Interface Module for enhanced connectivity .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | BENTLY 3500/05-02-04-00-00-00 |
| Manufacturer | Bently Nevada |
| Product Type | 19-inch full-size system rack for 3500 Series |
| Module Slots | 14 slots (Slots 1–2 reserved for power supply and RIM) |
| Dimensions | 482.6 x 241.3 x 304.8 mm (19.0 x 9.5 x 12.0 inches) |
| Weight | 3.6 kg (7.9 lbs) |
| Mounting Type | 19-inch EIA rack-mount with wall-mount adapter option |
| Power Requirements | 24V DC (via BENTLY 3500/15 power supply module) |
| Environmental Rating | IP54 (dust and water splash protection) |
| Compliance | API 670, CE, CSA |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95% non-condensing |
Key Features and Advantages
Modular Expandability:
The 3500/05-02-04-00-00-00 supports up to 14 modules, including vibration monitors (e.g., 3500/42M), tachometers (e.g., 3500/50M), and relay modules (e.g., 3500/33). Slots 1 and 2 are dedicated to the 3500/15 power supply and 3500/20 or 3500/22M Rack Interface Module (RIM), ensuring centralized power distribution and communication .
The 3500/05-02-04-00-00-00 supports up to 14 modules, including vibration monitors (e.g., 3500/42M), tachometers (e.g., 3500/50M), and relay modules (e.g., 3500/33). Slots 1 and 2 are dedicated to the 3500/15 power supply and 3500/20 or 3500/22M Rack Interface Module (RIM), ensuring centralized power distribution and communication .
Redundant Architecture:
By accommodating dual 3500/15 power supplies, the rack enables redundant power configuration, critical for continuous operation in mission-critical applications. The RIM slot supports triple modular redundancy (TMR) setups, enhancing system reliability in environments like offshore platforms .
By accommodating dual 3500/15 power supplies, the rack enables redundant power configuration, critical for continuous operation in mission-critical applications. The RIM slot supports triple modular redundancy (TMR) setups, enhancing system reliability in environments like offshore platforms .
Industrial-Grade Durability:
Constructed with corrosion-resistant materials, the rack withstands extreme temperatures, EMI/RFI interference, and mechanical vibrations. Its IP54 rating allows deployment in unprotected industrial settings without additional enclosures .
Constructed with corrosion-resistant materials, the rack withstands extreme temperatures, EMI/RFI interference, and mechanical vibrations. Its IP54 rating allows deployment in unprotected industrial settings without additional enclosures .
Legacy Compatibility:
Fully backward-compatible with existing 3500 series modules, the 3500/05-02-04-00-00-00 serves as a cost-effective upgrade path for retrofitting older systems. It seamlessly integrates with legacy communication protocols like TDXNET and DDIX while supporting newer Ethernet-based interfaces via the 3500/22M .
Fully backward-compatible with existing 3500 series modules, the 3500/05-02-04-00-00-00 serves as a cost-effective upgrade path for retrofitting older systems. It seamlessly integrates with legacy communication protocols like TDXNET and DDIX while supporting newer Ethernet-based interfaces via the 3500/22M .
Ease of Maintenance:
Tool-less module installation and front-accessible connectors simplify field servicing. The rack’s diagnostic LEDs provide real-time status updates, reducing downtime during troubleshooting .
Tool-less module installation and front-accessible connectors simplify field servicing. The rack’s diagnostic LEDs provide real-time status updates, reducing downtime during troubleshooting .
Applications
The BENTLY 3500/05-02-04-00-00-00 is ideally suited for industries requiring scalable, reliable machinery protection systems:
- Power Generation: Monitoring steam turbines and generators with modules like 3500/42M for vibration analysis and predictive maintenance .
- Oil & Gas: Configuring compressor trains in offshore platforms using 3500/40M vibration monitors and 3500/53M overspeed detectors .
- Chemical Processing: Supporting TMR setups for agitators and pumps with redundant power supplies and RIMs .
- Metallurgy: Centralizing data from rolling mill vibration sensors (e.g., 3500/44M) for process optimization .
- Mining: Enabling remote monitoring of conveyor belts and crushers via 3500/92 Modbus TCP/IP gateways .
For example, in a petrochemical plant, the 3500/05-02-04-00-00-00 might host 3500/42M proximity probes, 3500/50M tachometers, and 3500/33 relays to coordinate real-time vibration analysis and safety shutdowns .
Related Products
- BENTLY 3500/15-05-05-00: Universal AC/DC power supply module providing redundant power to the rack .
- BENTLY 3500/22M-01-01-00: Next-generation RIM with Ethernet/IP connectivity, replacing legacy 3500/20 modules .
- BENTLY 3500/33-01-01-00: 16-channel relay module for alarm activation and shutdown sequences .
- BENTLY 3500/92-01-01-00: Modbus TCP/IP gateway for integrating 3500 systems with legacy DCS platforms .
- BENTLY 3500/06-01-00-00-00-00: Protective cover for the rack, enhancing environmental protection in hazardous zones .
Installation and Maintenance
Pre-Installation Preparation:
- Verify the rack’s physical dimensions (19-inch EIA) and mounting requirements (wall-mount adapter optional).
- Install 3500/15 power supply in Slot 1 and 3500/22M RIM in Slot 2.
- Ensure input power cables comply with 24V DC requirements and include surge protection .
Maintenance Recommendations:
- Monthly Inspections: Clean dust from vents and check LED indicators for module status.
- Quarterly Testing: Simulate power failures to verify redundant power switching.
- Annual Calibration: Recalibrate module outputs using Bently Nevada’s diagnostic tools.
- Firmware Updates: Regularly update RIM firmware via 3500 Framework Configuration Software for compatibility with newer modules .
Product Warranty and Support
The BENTLY 3500/05-02-04-00-00-00 comes with an 18-month warranty covering defects in materials and workmanship. Bently Nevada’s global support network provides technical assistance for system integration, including compatibility guidance and troubleshooting. For mission-critical applications, expedited replacement services are available, though customers are advised to transition to the BENTLY 3500/05-03 for long-term reliability .
HS:7326909000
